GBE-100A
GBE-100A-R
GBE-500A
GBE-500A-R
GBE-1000A
GBE-1000A-R
GBE-2000A
GBE-3000A
RXE-500
RXE-500-LA
RXE-1000
RXE-2000
RXE-3000
RXE-5000
RXE-8000
RXE-10000
ROCCO-1000
ROCCO-2000
ROCCO-3000
ATT-20
ATT-40
ATT-60
ATT-80
Date: 12.01.2023
Issue: 13
© Geobrugg AG
8590 Romanshorn
Maintenance Manual
GBE-, RXE-, ROCCO
and ATT-series
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Geobrugg ROCCO Series
Summary of Contents for Geobrugg ROCCO Series
- Page 1 GBE-100A GBE-100A-R GBE-500A GBE-500A-R GBE-1000A GBE-1000A-R GBE-2000A GBE-3000A RXE-500 RXE-500-LA RXE-1000 RXE-2000 RXE-3000 RXE-5000 RXE-8000 RXE-10000 ROCCO-1000 ROCCO-2000 ROCCO-3000 ATT-20 ATT-40 ATT-60 ATT-80 Maintenance Manual GBE-, RXE-, ROCCO and ATT-series Date: 12.01.2023 Issue: 13 © Geobrugg AG 8590 Romanshorn...
- Page 2 No claims are made that this document is complete. It is designed for general standard applications and does not take into account project-specific parameters. Geobrugg cannot be held liable for any extra costs that may be incurred for special cases. In the event of uncertainty, please contact the manufacturer. The General Terms of Business of Geobrugg AG apply.
- Page 3 AREA OF APPLICATION This maintenance manual applies for the Geobrugg rockfall barrier systems of the GBE, RXE, ROCCO and ATT series. Reference is made to the corresponding system drawings: GBE-100A (100 kJ) System drawing GS-1218 GBE-100A-R (100 kJ) System drawing GS-1131...
- Page 4 Geobrugg can assist with estimating the influence of larger deviations and special situations and can offer recom- mendations for feasible solutions. Geobrugg cannot, however, guarantee the same behaviour as in the 1:1 rockfall tests.
-
Page 5: Table Of Contents
CLEARING THE BARRIER ....................12 Breaking stones down ..........................12 TOOLS FOR SERVICING ROCKFALL BARRIERS ............. 14 USE OF WIRE ROPE CLIPS ....................15 Page 5/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... - Page 6 8.11 Replacing a base plate ..........................30 8.12 Replacing base plate anchors ........................30 8.13 Replacing spiral rope anchors ........................30 FINAL CHECK ........................31 Page 6/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
-
Page 7: Hazard Notes
RELEASING TENSIONED PARTS Releasing or separating tensioned parts should be avoided wherever possible. If this is necessary, how- ever, please exercise the utmost caution. Page 7/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 8: Lifespan
If the functional efficiency or load-bearing capacity of the components is reduced as a result of damage or corrosion, such that the minimum required safety factors can no longer be fulfilled, the components must be replaced. Page 8/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 9: Inspections
These should be carried out before the onset of winter or after the end of winter. Digital monitoring devices on the flexible safety structures, such as the GUARD from Geobrugg AG, provide 24/7 access to the most important information about the current condition of the barrier, and any necessary maintenance measures can be reliably defined. -
Page 10: Criteria For Repair And Replacement
This is what the CONSIS expert course offered by Geobrugg AG teaches. More information on the requirements for participation and registration at https://www.geobrugg.com/en/Training-for-experts-... -
Page 11: Rocco
If the anchor is pulled out of the ground by more than 3 cm, it must be replaced, since under certain circumstances its load-bearing capacity may no longer be sufficient. Page 11/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 12: Clearing The Barrier
(e.g. that manufactured by Betonamit) and water is added. After about one day, the stone is bro- ken and can be cleared away. Page 12/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... - Page 13 If a crane is available, the stones can be fitted with a haulage anchor and brought down to the valley safely. Fitting the block with haulage hooks Lifting the block out with the aid of a crane Page 13/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
-
Page 14: Tools For Servicing Rockfall Barriers
• Inclinometer • Cutting-Off wheel • Two rope clamps, small 8 – 16 mm • Four rope clamps, large 14 – 26 mm Page 14/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 15: Use Of Wire Rope Clips
Wire rope clips have to be retightened biannually until the settlement behaviour has finished. In 2016 Geobrugg switched from wire rope clip EN 13411-5 type 1 to type FF-C-450 type 1 class 1. It is important to use the correct installation details. -
Page 16: Type Ff-C-450 Type 1 Class 1 (New Type)
2 x t , where t is the width of the clamping jaws. The loose rope end has to be 3 x e at a minimum. Geobrugg recommends looping up the remaining free section and fixing it directly behind the last wire rope clip on the tightened rope. - Page 17 A visible contusion of the wire ropes positively indicates that the wire rope clips have been tightened to the required tightening torque. Page 17/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
- Page 18 Undamaged wire rope clips could be reused. Especially the threads and clamping jaw have to be checked. Wire rope clips always have to be installed and used with the required tensioning torque. Page 18/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
-
Page 19: Repairing And Replacing Components
If this is no longer possible, a technically acceptable solution must be agreed with Geo- brugg. The correct geometrical arrangement of the individual components can be found in the product manual. Tightening sagging ropes Page 19/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 20: Replacing Ropes
• Release the wire rope clips of the rope and remove them. • Fit the new rope. • Tighten the wire rope clips for the new rope with the required tightening torque. Page 20/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 21: Replacing U-Brakes
• Release the cable pulley device so that the tensile force is transferred to the U-brake rope. • Detach the cable pulley device. Page 21/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 22: Repairing Nets And Meshes
If the mesh loops of a smaller mesh area have been pulled along in sympathy, a correspondingly small mesh can be laid over the damaged area and fastened to the intact mesh loops with wire binders. Page 22/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 23: Replacing Nets And Meshes
Connect the new mesh to the intact adjacent meshes with a TECCO spiral (or with shackles). Connect the eyelets of the two TECCO spirals with a shackle and remove the strain relief. Page 23/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 24: Spider : Replacing A Net Field
(or with shackles). Relieve the strain on the outermost spiral of the damaged area Cut open the eyelet connection of the outermost spiral Page 24/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... - Page 25 Fasten the mesh loops of the new net to the support ropes with shackles. Connect the new net to the intact adjacent nets with a spiral (or with shackles). Page 25/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
- Page 26 Connect the eyelets of the two spirals with a shackle and remove the strain relief. Page 26/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
-
Page 27: Rocco: Replacing Individual Rings
The easiest way to replace individual rings is by fitting a replacement ring into the net with shackles. Cor- responding prefabricated rings can be obtained via Geobrugg. The new ring is fastened to the adjacent rings with four shackles before the damaged ring is cut out. -
Page 28: Rocco: Replacing A Net Field
Take care to ensure that the correct number of rings is fastened to the right and left of the post, not on the support ropes, but on the U-Ropes. Detailed information can be found in the corresponding product manual. Page 28/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 29: Wire Mesh: Replacing A Length Of Mesh
8.9.1. If this is not possible, a certain number of fields or the entire barrier must first be laid securely facing up the mountain until the edge post can be replaced. Page 29/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 30: Replacing The Hinge Bolt Between Post And Base Plate
To replace a rope anchor, it must first be relocated in a suitable location nearby in accordance with the product manual and the anchor forces sheet. Page 30/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... -
Page 31: Final Check
Have the border nets been fastened to the vertical ropes correctly? Is the slack of the top support rope less than 3% of the post spacing? Page 31/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13... - Page 32 4.2 / 4.3 > 1 m 4.2 / 4.3 Elongated brakes Up to 30 cm > 30 cm > 60 cm > 80 cm Page 32/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
- Page 33 H) Wire rope clips All wire rope clips have the right torque Remarks / Notes / Sketches: Name of validator: ………………………………………………………………………………………………….. Date: ……………………………… Signature: ………………………………………………………………. Page 33/33 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland Maintenance manual GBE, RXE, ROCCO and ATT / 13...
