Geobrugg GBE-100A-R Product Manual

Rockfall barrier
Hide thumbs Also See for GBE-100A-R:
Table of Contents

Advertisement

Quick Links

Download this manual
European Technical
Assessment ETA 15/0304
ETAG 027: Category A
Energy class 0: ≥100 kJ
Installation height:
2.0 – 2.5 m
Test Certificate No. S 14-6
Federal Office for the
Environment FOEN
Switzerland
Attending testing institute:
Swiss Federal Institute for
Forest, Snow and Landscape
Research WSL
Birmensdorf, Switzerland
Date: 24.05.2018
Edition: 08
© Geobrugg AG
CH-8590 Romanshorn
Product Manual
GBE-100A-R
ROCKFALL BARRIER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GBE-100A-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Geobrugg GBE-100A-R

Summary of Contents for Geobrugg GBE-100A-R

  • Page 1 Test Certificate No. S 14-6 Federal Office for the Environment FOEN Switzerland Attending testing institute: Swiss Federal Institute for Forest, Snow and Landscape Research WSL Birmensdorf, Switzerland Product Manual GBE-100A-R ROCKFALL BARRIER Date: 24.05.2018 Edition: 08 © Geobrugg AG CH-8590 Romanshorn...
  • Page 2 Page 2/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 3 Page 3/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 4 This document makes no claim as to its completeness. It is designed for general standard applications and does not consider project-related parameters. Geobrugg cannot be held liable for any additional costs that may be in- curred in special cases. Contact the manufacturer if anything is unclear. The General Terms and Conditions of Geobrugg AG apply.
  • Page 5 ETA (European Technical Assessment) as well as a Swiss test certificate from the Swiss Federal Office for the Environment (FOEN). This system, the GBE-100A-R, has the approval no. ETA – 15/0304 and the test certificate no. S 14-6.
  • Page 6 Geobrugg can help in protecting against the influences of greater deviations from the standard and specific situa- tions and provide suggestions for feasible solutions. However, Geobrugg cannot guarantee behavior that will be the same as in the 1:1 rockfall tests.

  • Page 7: Table Of Contents

    INSTALLATION STEPS FOR SUPERSTRUCTURE ............25 ASSEMBLY DETAILS ....................... 28 SUPPORT ROPE SEPARATION WITH INTERMEDIATE ANCHOR ROPE ......40 SPECIAL SOLUTIONS IN ADDITION TO THE STANDARD ..........43 FINAL CHECKS........................ 44 Page 7/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 8: Hazard Warnings

    Ropes are under tension. Ensure that no one is standing in the danger zone while the ropes are being in- stalled and pre-tensioned. RELEASING PARTS UNDER TENSION Avoid releasing or disconnecting components under tension wherever possible. If, however, this is nec- essary, please exercise the extreme caution. Page 8/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 9: Tools For Installing Rockfall Barriers

    • At least 2 tension belts • Cable winch hoist, e.g. LUG-ALL ® • Chain hoist or HABEGGER ® wire rope hoist, min. 1.5 t (15 kN) • Auxiliary ropes Page 9/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 10: Using The Wire Rope Clips

    , where t is the width of the clamping jaws. The loose rope end has to be 3 x e at a minimum. Geobrugg recommends looping up the remaining free section and fixing it directly behind the last wire rope clip on the tightened rope.
  • Page 11 Undamaged wire rope clips could be reused. Especially the threads and clamping jaw have to be checked. Wire rope clips always have to be installed and used with the required tensioning torque. Page 11/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 12: Stake-Out Depending On The Terrain

    The base plates of the foundation must be laid so that the lower support rope is kept as close to the ground as possible. The base plates must be placed so that the lower support rope is routed along the edges of the foundation and does not damage them. Page 12/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 13 > 1.50 m > 2.00 m Mesh must be adapted When the height difference is greater than specified in table 2, contact Geobrugg so that the correct net length can be determined Page 13/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland...

  • Page 14: Stake-Out Geometry

    If Geobrugg is informed of the variations, a suitable solution can be found together quickly. Page 14/48 ©...
  • Page 15 Table 3 2.00 3.00 0.30 1.00 2.50 3.75 0.30 1.25 3.00 4.50 0.30 1.50 ROPE ANCHOR FOR INTERMEDIATE ANCHOR Length See table 3 See table 3 Anchor point Intermediate anchor Page 15/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 16 15°<y<25° Anchor point Intermediate anchor When a change in alignment downslope is greater than 15°, intermediate anchors must be arranged whereby the downslope anchor is not necessary Page 16/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 17 Intermediate anchor When a change in alignment upslope is greater than 30°, an intermediate anchor must be attached to the post upslope. The maximum change in alignment upslope is 40°. Page 17/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 18: Rope Anchor - Placement

    “gap filling nets” (additional mesh between the terrain and bottom part of the mesh). The anchor holes are drilled in the pulling direction, with a minimum angle of > 15° to the horizontal. Page 18/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 19: Anchoring The Posts And Rope Anchors

    10 must be attached on both sides of the base plate • Fill in the concrete foundation 111 • Tighten the fastening nuts 10 to a preload force of approx. 30 kN Page 19/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 20 You can find further information on anchoring posts on the anchor data sheet. The forces that occur during a rockfall event are not to be underestimated. The civil engineering and in- stallation work must therefore be carried out by professionals. Page 20/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 21: Preparing The Meshes And Posts

    X: If there are greater height differences, it is easier to pull the mesh down from the higher post to the lower post. Geobrugg will supply the bundle position according to customer specification at time of order. Page 21/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland...
  • Page 22 The shackle for lifting the post is later used for the vertical rope The shackle for lifting the post is later used for the upper support rope 30.2 / 240 31.2 / 241 Page 22/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 23 The height of the topmost row of diamonds 203 or the guide profiles 202 for the upper support rope is slightly greater than the height of the pre-installed shackle for the upper support rope. Page 23/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 24: Installation By Crane Or Helicopter

    INSTALLATION BY CRANE OR HELICOPTER Securely fasten the mesh bundles with tape 204. Use the middle 5/8" shackle 83 at the top of the post to lift the post. Page 24/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 25: Installation Steps For Superstructure

    Please exercise extreme caution in the danger zone while the posts can still tip forward or to the side. • Install lateral anchors and any intermediate anchors • Install the post top rope Page 25/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 26 • Attach the vertical ropes to the border posts and connect the mesh to the left vertical rope using a helix. • Open the meshes, hoist them, connect them to each other, and connect them to the other vertical rope using a helix. Page 26/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 27 • Tension the lower support rope • Close the flex zones Page 27/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 28: Assembly Details

    For the bottom 3 shackles 83, screw in the threaded bolt upslope using the bolt head so that the mesh or the horizontal helix springs do not catch on the bolt head. Page 28/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 29 Mount the vertical ropes 69 on the side facing the lateral anchors. Structure height of 2.5 m and 3 m The post profile is an HEA 140 Page 29/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 30 For the bottom 2 shackles 83, screw in the threaded bolt upslope using the bolt head so that the mesh or the horizontal helix do not catch on the bolt head. Page 30/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 31 Structure height of 2.5 m and 3 m The post profile is an HEA 140 Page 31/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 32 LATERALANCHOR ROPE, UPPER AND LOWER SUPPORT ROPE ON THE LEFT ROPE AN- CHOR 1 pc. Lateral anchor rope 1 pc. Lower support rope 1 pc. Upper support rope 2 pcs. 3/4" shackle 3 pcs. 9/16” wire rope clip Page 32/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 33 Lateral anchor rope 1 pc. Lower support rope 1 pc. Upper support rope 3 pcs. 9/16” wire rope clip per rope 4 pcs. NG16 wire rope clamp per rope Page 33/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 34 - Structure height of 2.5 m: 1 pc. Helix 3500 x 64/4 - 100, cut to a length of 2800 on site - Structure height of 3 m: 1 pc. Helix 3500 x 64/4 - 100, cut to a length of 3300 on site Page 34/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 35 The topmost and the third topmost diamond of the adjacent meshes are also each connected with a 3/8" shackle 80 in addition to the helix. Page 35/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 36 The bottommost and the third bottommost diamonds of the adjacent mesh are also each connected with a 3/8" shackle 80 in addition to the helix. Page 36/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 37 The topmost and the third topmost diamond or the bottommost and third bottommost diamond of the edge of the mesh are connected to a vertical rope with a 3/8" shackle 80 in addition to the helix. Page 37/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 38 In this exceptional case to be prevented if possible, the vertical helix 302 must be hooked into the sec- ond-last coil at the top end 212. Page 38/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 39 DOWNSLOPE ANCHOR ROPE 2 pcs. Spiral rope anchor 2 pcs. Downslope Anchor rope 2 pcs. 5/8" shackle in addition 3 pcs. 7/16” wire rope clip per rope Page 39/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 40: Support Rope Separation With Intermediate Anchor Rope

    SUPPORT ROPE SEPARATION WITH INTERMEDIATE ANCHOR ROPE 2 pcs. Intermediate anchor rope 2 pcs. Upper support rope 2 pcs. Lower support rope 2 pcs. Post top rope 4 pcs. 5/8" shackle in addition Page 40/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 41 2 pcs. Spiral rope anchor 2 pcs. Intermediate anchor rope 2 pcs. Lower support rope 2 pcs. 3/4" shackle 3 pcs. 9/16” wire rope clip per rope Page 41/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 42 The topmost and the third topmost diamond or the bottommost and third bottommost diamond of the edges of the mesh are each connected to one another with a 3/8" shackle 80 in addition to the helix. Page 42/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 43: Special Solutions In Addition To The Standard

    If there is insufficient space for staking out the lateral anchors as standard, you can consult with Geobrugg AG to develop a strut solution. ROCK CONNECTION If standard stake-out is not possible, you can consult with Geobrugg AG to develop a rock connection var- iant. GULLY SOLUTION Larger openings between the ground and the lower support rope may form on steep mountain slopes with mountain torrents.

  • Page 44: Final Checks

    Are the mesh panels connected correctly to one another? Have the mesh panels been correctly attached to the border posts? Is the sag of the upper support rope less than 3% of the post distance? Page 44/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...

  • Page 45: Geobrugg Ag, Ch-8590 Romanshorn, Switzerland Gbe-100A-R

    Page 45/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 46 Page 46/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 47 Page 47/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
  • Page 48 EXCERPT FROM THE FOEN TEST CERTIFICATE NO. S 14-6 Page 48/48 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-100A-R / 08...
