Geobrugg GBE-3000A Product Manual

Rockfall barrier
Hide thumbs Also See for GBE-3000A:

Advertisement

Quick Links

European Technical
Assessment
ETA–10/0084
ETAG 027: Category A
Energy Class 6:
3000 kJ
Height: 5 – 6 m
Attending testing institute:
Swiss Federal Institute for
Forest, Snow and Landscape
Research WSL
Birmensdorf, Switzerland
Date: 24.05.2018
Edition: 16
© Geobrugg AG
CH-8590 Romanshorn
Product Manual
GBE-3000A
ROCKFALL BARRIER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GBE-3000A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Geobrugg GBE-3000A

  • Page 1 Energy Class 6: 3000 kJ ≥ Height: 5 – 6 m Attending testing institute: Swiss Federal Institute for Forest, Snow and Landscape Research WSL Birmensdorf, Switzerland Product Manual GBE-3000A ROCKFALL BARRIER Date: 24.05.2018 Edition: 16 © Geobrugg AG CH-8590 Romanshorn...
  • Page 2 Page 2/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 3 Page 3/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 4 It is designed for general standard applications and does not take into account any project-specific parameters. Geobrugg cannot be held liable for any additional costs which may arise in spe- cial cases. If anything is unclear, please contact the manufacturer. Geobrugg AG's general terms and conditions apply.
  • Page 5 • Anchoring conditions II QUALITY OF THE INDIVIDUAL SYSTEM COMPONENTS Geobrugg AG, formerly the Geobrugg Protection Systems division of Fatzer AG, Romanshorn, Switzerland, has been certified with registration number CH-34372 in accordance with the quality management system require- ments (ISO 9001:2008) since August 22, 1995. The certification body is the SQS (Swiss Association for Quality and Management Systems), which belongs to IQNet.
  • Page 6 Geobrugg can assist with estimating the influence of larger deviations and special situations, and can offer rec- ommendations for feasible solutions. Geobrugg cannot, however, guarantee the same behavior as in the one-to- one rockfall tests.
  • Page 7: Table Of Contents

    PREPARATION OF THE NETS AND POSTS ..............21 CRANE OR HELICOPTER INSTALLATION ............... 24 INSTALLING THE SUPERSTRUCTURE ................25 ASSEMBLY DETAILS ....................... 27 ADDITIONAL SOLUTION TO THE STANDARD ..............39 FINAL INSPECTION ......................40 Page 7/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 8: Hazard Warnings

    REMOVAL OF PARTS UNDER TENSION The removal or separation of components under tension is to be avoided whenever possible. Should such work be necessary, however, the utmost caution must be taken. Page 8/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 9: Tools For Installing Rockfall Barriers

    • Rope clamp – small 8-16 mm / large 14-26 mm (at least 2) • At least 2 tension belts • Cable winch hoist, e.g. LUG-ALL ® • Chain hoist or come-along, at least 1.5 tons (15 kN) • Auxiliary ropes Page 9/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 10: Using The Wire Rope Clips

    , where t is the width of the clamping jaws. The loose rope end has to be 3 x e at a minimum. Geobrugg recommends looping up the remaining free section and fixing it directly behind the last wire rope clip on the tightened rope.
  • Page 11 Undamaged wire rope clips could be reused. Especially the threads and clamping jaw have to be checked. Wire rope clips always have to be installed and used with the required tensioning torque. Page 11/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 12: Staking Out Subject To Terrain

    The baseplate must be positioned in such a way that the lower support rope is routed past the edges of the foun- dations without being damaged by them. Page 12/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 13 > 0.50m > 1.00m > 1.50m Net must be adjusted If the height difference is greater than in Tab.2 you must contact Geobrugg to enable the correct length of nets to be determined. Page 13/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland...
  • Page 14: Staking-Out Geometry

    Informing Geobrugg about the deviations enables you to work together to quickly find a solution that is adapted to your requirements.
  • Page 15 Tab.3 Anchor point Retaining rope 0°- 29° downslope anchor rope In a ground slope of less than 30°, the distance between the retaining rope is to be adapted. Page 15/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 16 In the case of a change in direction towards the mountain of more than 15°, an intermediate anchor rope must be installed and the valley-side anchoring is omitted. SEILANKER FÜR TRAGSEILTRENNUNG MIT ZWISCHENABSPANNUNG Page 16/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 17 In the case of a change in direction towards the valley of more than 30°, two additional retaining ropes (D) are mounted on the post. The change in direction towards the valley must not exceed 40°. Page 17/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 18: Rope Anchor - Installation

    The anchor holes are drilled in the pulling direction, with a minimum angle of > 15° to the horizontal. The anchors must be inserted into the holes up to the marking and mortared in a horizontal position of the anchor head: Page 18/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 19: Anchoring Of The Base Plate

    Prepare foundation 111; dimension and reinforcement of the concrete foundation 111 is set by the project engineer (rec- 0.2 m ommendation Geobrugg: 0.6 x 0.5 x 0.2 m) • Insert anchor 05, washer plate 09 und nuts 10, the calcula- 0.6 m...
  • Page 20 Further information about the anchoring of the base plate can be found on the anchor forces date sheet. The forces that occur during a rockfall event are not to be underestimated. The civil engineering and in- stallation work must therefore be carried out by professionals. Page 20/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 21: Preparation Of The Nets And Posts

    8 meshes on top and bottom of the SPIDER net are left free. The support ropes are only guided through the bundled and red marked meshes. Later each second free mesh will be attached to the support ropes with round clips. Page 21/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 22 The net bundle is placed on the mounting bracket and securely fastened with bands 204. It has to be taken into account that the right number of meshes next to the posts are left free (see page 31/32). Page 22/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 23 X: With larger height differences, it’s easier to pull down the panels from higher to the lower post. With appropriate ordering details Geobrugg provides the panel on the wished side of the post. Page 23/43 ©...
  • Page 24: Crane Or Helicopter Installation

    Fasten the mesh bundle using strips 204 so that it cannot fly away Use the centre 7/8" shackle 205 on the top of the post to lift the posts. Never use the rungs 203 Page 24/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 25: Installing The Superstructure

    • Install the U-Brake for the bottom support rope on the anchors. Fasten the bottom support rope to the base plates of the posts and tension the bottom support rope. The support ropes are guided through the relevant SPIDER meshes. Page 25/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 26 29. The TECCO rope is guided through the U-profile of the TECCO panel. • Install the vertical rope to the U-Brake. • Loose the U-profiles and open the panels. Connect the panels vertically. Page 26/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 27: Assembly Details

    ASSEMBLY DETAILS ROPE CONNECTION TO THE ANCHORS RETAINING ROPES ON THE UPSLOPE 1 pcs spirale rope anchor 2 pcs retaining rope wire rope clip 7/8” per rope 4 pcs Page 27/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 28 2 pcs bottom support rope 2 pcs Tecco rope 1 pcs shackle 5/8" shackle 7/8“ 1 pcs 3 pcs shackle 1" shackle 1 1/4“ 2 pcs 33,35,53,55 Page 28/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 29 In case of a support rope separation, the overturn securing rope 68 is installed temporary. It is a schematic illustration of the net bundle, make sure that the right number of meshes rest free. Page 29/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 30 2 pcs U-Brake U-300-R20 shackle 1“ 4 pcs 4 pcs shackle 1 1/4“ wire rope clip 7/8“ 4 pcs Wire rope clip 7/8“ for GEOBINEX rope 5 pcs Page 30/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 31 LATERAL ROPE ON THE ROPE ANCHOR 1 pcs spirale rope anchor 4 pcs wire rope clip 3/4" per rope Page 31/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 32 Mount 4 round clips on the left and 4 round clips on the right side of the post, start with the loop close to the post 8 loops free shackle 7/16“ per loop Page 32/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 33 Mount 4 round clips on the left and 4 round clips on the right side of the post, start with the loop close to the post. 11 loops free shackle 3/8“ per loop Page 33/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 34 Mount 4 round clips on the left and 4 round clips on the right side of the post, start with the loop close to the post. ( 8 loops free ) Vertical rope shackle 5/8“ per loop Page 34/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 35 Mount 4 round clips on the left and 4 round clips on the right side of the post, start with the loop close to the post. ( 11 loops free ) Vertical rope shackle 5/8“ each second loop Page 35/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 36 The TECCO® -mesh is fixed by the same 5/8“ shackles 83 like the SPIDER net is fixed to the vertical rope . That means every second TECCO mesh is fixed to the vertical rope 69. Page 36/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 37 A support rope separation always contains an intermediate rope suspension. In the case of an intermediate anchor rope without support rope separation, the two intermediate suspen- sion ropes at the centre hole are fastened with a 7/8" shackle. Page 37/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 38 INTERMEDIATE ROPE SUSPENSION VALLEY SIDE ANCHORING 1 pcs spirale rope anchor 1 pcs Downslope anchor rope shackle 1“ 1 pcs 4 pcs wire rope clip 3/4" Page 38/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 39: Additional Solution To The Standard

    If there is insufficient space for staking out the lateral anchors as standard, you can consult with Geobrugg AG to develop a strut solution. ROCK CONNECTION If standard stake-out is not possible, you can consult with Geobrugg AG to develop a rock connection var- iant. GULLY SOLUTION Larger openings between the ground and the lower support rope may form on steep mountain slopes with mountain torrents.
  • Page 40: Final Inspection

    Are the nets connected correctly? Are the end nets correctly fastened to the vertical ropes? Is the sag of the top support rope less than 3% of the distance between the posts? Page 40/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 41: Geobrugg Ag, Ch-8590 Romanshorn, Switzerland Gbe-3000A

    Page 41/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 42 Page 42/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
  • Page 43 Page 43/43 © Geobrugg AG, CH-8590 Romanshorn, Switzerland GBE-3000A / 16...
