European Technical

Assessments

ETA 17/0279

ETA 17/0283

ETAG 027: Category A

Energy class 0: ≥100 kJ

Installation height: 2 – 3.5 m

Rockfall Protection Net /

Product – Data Sheet

Federal Office for the

Environment FOEN

Switzerland

Energy class 0: 100 kJ

Installation height: 2 – 4.5 m

Attending testing institute:

Dynamic Test Center

Vauffelin / Biel, Switzerland

ISO 17025 accredited

ISO 9001 certified

Date: 08.10.2018

Edition: 06

CH-8590 Romanshorn

Product Manual

GBE-100A

ROCKFALL BARRIER

Page 1/41

GBE-100A / 06

Table of Contents

Need help?

Do you have a question about the GBE-100A and is the answer not in the manual?

Questions and answers

Summary of Contents for Geobrugg GBE-100A

Page 1 Attending testing institute: Dynamic Test Center Vauffelin / Biel, Switzerland ISO 17025 accredited ISO 9001 certified Product Manual GBE-100A ROCKFALL BARRIER Date: 08.10.2018 Edition: 06 © Geobrugg AG CH-8590 Romanshorn Page 1/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 4 It is designed for general standard applications and does not take into account any project-specific parameters. Geobrugg cannot be held liable for any additional costs which may arise in spe- cial cases. If anything is unclear, please contact the manufacturer. Geobrugg AG's general terms and conditions apply.
Page 5 European approval, known as ETA (European Technical As- sessment), as well as a Swiss inspection certificate from the Federal Office for the Environment (FOEN). The cur- rent system GBE-100A has the inspection certificate no. ETA 17/0279, ETA 17/0283 and Rockfall Protection Net / Product – Data Sheet...
Page 6: Geobrugg Gruppe, Ch-8590 Romanshorn, Switzerland Gbe-100A
Geobrugg is able to provide assistance when you are assessing the influence of significant anomalies and special situations, and offer suggestions for feasible solutions. However, Geobrugg cannot guarantee consistent perfor- mance of the type demonstrated in the rockfall tests under real-life conditions.
Page 7: Table Of Contents
ANCHORING THE BASE PLATE ..................20 ASSEMBLY DETAILS ....................... 24 SUPPORT ROPE SEPARATION (SRS) WITH INTERMEDIAT SUSPENSION ..... 34 ADDITIONAL SOLUTION TO THE STANDARD ..............37 FINAL INSPECTION ......................38 Page 7/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 8: Hazard Notes
RELEASING TENSIONED PARTS Releasing or separating tensioned parts should be avoided wherever possible. If this is necessary, how- ever, please exercise the utmost caution. Page 8/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 9: Tools For Installing Rockfall Barriers
• At least 2 tension belts • Cable winch hoist, e.g. LUG-ALL ® • Chain hoist or HABEGGER wire rope hoist, min. 1.5 t (15 kN) • Auxiliary ropes Page 9/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 10: Using The Wire Rope Clips
, where t is the width of the clamping jaws. The loose rope end has to be 3 x e at a minimum. Geobrugg recommends looping up the remaining free section and fixing it directly behind the last wire rope clip on the tightened rope.
Page 11 Wire ropes that have not been damaged can be used again, but the threads and the saddle, in particular, must be inspected for any damage. Page 11/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 12: Staking-Out In Accordance With The Terrain
The base plate must be positioned in such a way that the bottom support rope bypasses and is not damaged by the edges of the foundation. Page 12/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 13 > 1.00 m > 1.50 m Mesh must be adapted Table 2 When the height difference is greater than specified in table 2, contact Geobrugg so that the correct net length can be determined Page 13/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland...
Page 14: Staking-Out Geometry
To ensure that the barrier still functions properly in these cases, you may make several small adjustments to the cross-section or length of nets, ropes, posts, etc. If you inform Geobrugg of these deviations, we can work together to find a adapted solution quickly. Orientation of the foundations and base plates Base plate type 2 can be used on a concrete foundation with two parallel anchors as well as with a 45°...
Page 15 The distance of the upslope anchor rope 236  depends on the possible angle  and must be adjusted and the length of the upslope  anchor rope must be checked.  Page 15/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 16 With simple terrain conditions and suitable tools, we recommend a support rope separation after approximately 60 – 100 m. In Switzerland, a support rope separation is required after 60 m. In Austria, a support rope separation is recommended after 60 m. Page 16/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 17 For example in case of a change in direction of 35° the forces are 2.3 times higher than for 15°. Consultation with Geobrugg is recommended Page 17/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 18 With a change in direction towards the downslope with an angle of 30° - 40° an additional upslope anchor rope is needed in distance d. The maximum change in direction toward the downslope of 40° must not be exceeded. Page 18/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 19: Installing The Rope Anchor
(additional mesh between the terrain and bottom part of the mesh). The anchor holes are drilled in the pulling direction, with a minimum angle of > 15° to the horizontal. Page 19/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 20: Anchoring The Base Plate
Prepare the concrete foundation 111; the concrete foundation is di- mensioned and reinforced in accordance with the information from 0.15 m the project engineer (Geobrugg recommendation: 0.6 x 0.4 x 0.15 m) • Insert the anchor 05, spacers 09, and fastening nuts 10; the project 0.6 m...
Page 21 Position the base plate 29 • 09,10 Tighten the fastening nuts 10 with the spacers 09 to approx. 30 kN pretensioning force after the mortar has fully hardened 09,10 Page 21/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 22 Prepare the concrete foundation 111; the concrete foundation 111 is dimensioned and reinforced in accordance with the information from 0.15 m the project engineer (Geobrugg recommendation: 0.6 x 0.4 x 0.15 m) • Insert the anchor 05, spacers 09, and fastening nuts 10; the project engineer calculates the lengths of the anchors 0.6 m...
Page 23 You can find more information about anchoring the base plate in the anchor data sheet. The forces that may occur in the event of a rockfall event must not be underestimated. Civil engineering and installation work must therefore be carried out by experts. Page 23/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 24: Assembly Details
2 pcs hex nut M22 1 pc washer for M22 1 pc locking screw bar shackle 3/4“ 1 pc Install the locking screw bar 68 to securely install the posts. Page 24/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 25 1 pc. bottom support rope 5 pcs. shackle 3/4" shackle 1“ straight 2 pcs 3 pcs wire rope clip 3/4“ other side with rope loop 56, 57, 58 Page 25/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 26 1 pc top support rope 1 pc bottom support rope 4 pcs shackle 3/4" 2 pcs shackle 1“ straight 3 Stk. Drahtseilklemme 9/16“ andere Seite mit Seilschlaufe 56, 57, 58 Page 26/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 27 3 pcs UPSLOPE ANCHOR ROPE ON THE MIDDLE ROPE ANCHORS 66.2 1 pc spiral rope anchor 2 pcs upslope anchor rope wire rope clip 7/16“ per rope 3 pcs Page 27/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 28 LATERAL ANCHOR ROPES AND THE LOWER SUPPORT ROPE ON THE LATERAL ANCHORS 2 pcs spiral rope anchor 2 pcs lateral anchor rope 1 pc bottom support rope shackle 3/4“ 1 pc wire rope clipe 5/8“ per rope 3 pcs Page 28/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 29 - Structure height of 2.5 m: 1 pc. Helix 3500 x 64/4 - 100, cut to a length of 2800 on site - Structure height of 3 m: 1 pc. Helix 3500 x 64/4 - 100, cut to a length of 3300 on site Page 29/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 30 207: Two windings of the Helix 304.1 before and after the running wheel are not wounded into the support rope. The topmost and the third topmost diamond of the adjacent meshes are also each connected with a 3/8" shackle 80 in addition to the helix. Page 30/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 31 207: Two windings of the Helix 304.1 before and after the running wheel are not wounded into the support rope. The bottommost and the third bottommost diamonds of the adjacent mesh are also each connected with a 3/8" shackle 80 in addition to the helix. Page 31/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 32 The topmost and the third topmost diamond or the bottommost and third bottommost diamond of the edge of the mesh are connected to a vertical rope with a 3/8" shackle 80 in addition to the helix. Page 32/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 33 1 pc spiral rope anchor 1 pc downslope anchor rope schackle 3/4“ 1 pc wire rope clip 5/8“ 3 pcs Page 33/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 34: Support Rope Separation (Srs) With Intermediat Suspension
2 pcs intermediate suspension 1 pc overturn securing rope 1 pc top support rope 1 pc bottom support rope 3 pcs shackle 3/4" shackle 1“ 4 pcs 56, 57, 58 Page 34/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 35 UPSLOPE ANCHOR ROPES ON THE UPSLOPE ANCHORS 66.2 1 pc spiral rope anchor 2 pcs upslope anchor rope wire rope clip 7/16“ per rope 3 pcs Page 35/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 36 INTERMEDIATE SUSPENSION AND BOTTOM SUPPORT ROPE AT THE SRS ANCHORS 2 pcs spiral rope anchor 2 pcs intermediate suspension 1 pc bottom support rope shackle 3/4“ 1 pc 3 pcs wire rope clip 5/8“ per rope Page 36/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
Page 37: Additional Solution To The Standard
ROCK FACE CONNENCTION If it is not possible to use the standard staking-out procedure, an option for solid rock can be developed in consultation with Geobrugg AG. This also involves installing towing nets at the edges of the structure. GAP FILLING SOLUTION On steep mountain slopes with mountain torrents, there may be larger gaps between the ground and the lower support rope.
Page 38: Final Inspection
Are the nets connected correctly? Are the end nets correctly fastened to the vertical ropes? Is the sag of the top support rope less than 3% of the distance between the posts? Page 38/41 © Geobrugg Gruppe, CH-8590 Romanshorn, Switzerland GBE-100A / 06...
