Always use pipe-joint compound made for
use with NATURAL GAS and L.P. GAS
between pressure regulator D and NPT
adaptor C and between pressure regulator
D and pipe E. If a flexible metal conductor
is used, make sure that the tubing is not
kinked.
Use only pipes (E) conforming to standard
regulations in force, inserting gasket B
(supplied) between fitting A and adaptor C.
Always apply a suitable sealing substance
(such as Teflon tape) between pressure
regulator D and adaptor C and between
pressure regulator D and pipe E.
WARNING: The tightening torque
of adaptor (C ) must not be greater
than 36 ozf - 10 Nm.
Installation
Due to problems of overall dimensions at
the back, screw in the pressure regulator so
that it is sloped at 45° vs the wall at the
back of the appliance.
19
