Lumena PROSOLAR SOLD3SS-D User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Pack Size: 1
Wattage: 3W
Lamp: 3W Epistar LED Chips SMD5050 12pcs (In-Built)
Colour: 3000K (Warm White) / 6000K (Daylight White)
Lumen Output: 210lm
LED Life Expectancy: up to 50,000 hours
Max Illumination Time at Full Charge: up to 2 nights
Sensor: Light Sensor
Battery Type: 2AH 3.7V Lithium Iron Phosphate 18650
Battery Charge Time: 6-8 hours
Solar Panel: 6V 0.6W Polycrystalline Silicon
IP Rating: IP67
IK Rating: IK08
Max. Tolerated Weight: 500KG (max speed 5mph)
Materials: Die-Cast Aluminium, Stainless Steel (304) and Tempered Glass
Weight: 570g (approx.) each
Working Temperature: -25˚C ~ 60˚C
Mounting: Recessed
Installed Height: 4mm
Functions: Dusk to Dawn (Auto) / Smart On/Off
Included: 1 x Light, 2 x M4 x 50mm Screws & Plugs, 3mm Allen Key
•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light, ensuring it is not a trip hazard.
•
The Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
•
Due to temperature difference in and outside the fitting, condensation may be present internally but will not affect use.
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface
dirt. To maintain efficiency, specifically clean the solar panel and LEDs on a regular basis. Also, keep the solar panel free of debris
and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could damage
the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

rd
If purchased from a 3 party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
THANK YOU FOR YOUR PURCHASE
Full product range & more information: www.lumenalights.com
Soldial In-Ground Solar Light

WARNINGS

Tel: +44 1327 871161
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
USER MANUAL
SOLD3SS-D / SOLD3SS-W
✔✔
2 YEAR
GUARANTEE
see website for
more details
Email: sales@lumenalights.com
