Installation Instructions
CS1326 Y
en - CA
Installation, repair and maintenance work should be performed by
a Miele authorized service technician in accordance with national
and local safety regulations and the provided installation instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS1326 Y and is the answer not in the manual?

Questions and answers

Summary of Contents for Miele CS1326 Y

  • Page 1 Installation Instructions CS1326 Y en - CA Installation, repair and maintenance work should be performed by a Miele authorized service technician in accordance with national and local safety regulations and the provided installation instructions.
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Correct usage WARNING- When using your Only use the Tepan Yaki for appliance follow basic residential cooking, and for the precautions, including the purposes described in this manual. following: Other uses are not permitted and can be dangerous. The manufacturer will Read all instructions before not be held liable for damage caused installation or use to prevent...
  • Page 3 Install the appliance so that the power cord does not come into contact Installation, repair and maintenance with any portion of the appliance which work should be performed by a Miele may become hot during use. authorized service technician. Work by unqualified persons could be Before servicing, disconnect the dangerous and may void the warranty.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS Safety Never cover the appliance with a cloth. A fire may result. The appliance is hot during use and remains so for some time after being Be aware of loose fitting or hanging switched off. Be careful not to touch the garments when operating the appliance if it may still be hot.
  • Page 5: Safety Instructions For Installation

    The minimum distances given in installation in these applications. Please these Installation Instructions must contact the Miele Technical Service be observed in order to ensure safe Department with specific requirements. operation. Failure to do so increases The electrical connection should be the risk of fire.
  • Page 6 SAFETY INSTRUCTIONS FOR INSTALLATION Safety distances above the If there is more than one appliance appliance beneath a hood (e.g. wok burner and electric cooktop), and they have different minimum safety distances always observe the greater distance. The minimum safety distance given by the hood manufacturer must be maintained between the cooktop and the hood above it.
  • Page 7 SAFETY INSTRUCTIONS FOR INSTALLATION Safety distances to the sides of the appliance The appliance should only be installed as shown in the illustrations, while 2 " (50 mm) maintaining the required safety distances shown. Do not install the appliance between two tall cabinets, this is a fire hazard.
  • Page 8: Installation

    Installation Safety distance when installing the appliance near a wall with trim or a back splash A minimum distance of 2" (50 mm) between the trim or back splash and the countertop cut-out if required. This distance is only necessary if these items are made of combustible materials e.g.
  • Page 9 Installation Installation dimensions a Spring clips b Appliance front c Installation height d Power supply box with connection cable, L = 78 " (2000 mm)
  • Page 10 Installation Cut out If during installation the seal around ^ Make the worktop cut-out for one or the frame does not sit flush with the more appliances as applicable. countertop in the corners, the corner Remember to maintain a minimum radius, maximum "...
  • Page 11: Installation Of Multiple Appliances

    Installation Installation of multiple appliances When installing more than one combiset appliance, a support bar b must be installed between the appliances. Countertop cut-out Countertop cut-out two appliances three appliances 6 " 6 " For the installation of three appliances For the installation of two appliances the width of the countertop cut-out D is the width of the countertop cut-out D is...
  • Page 12 Installation Sample calculations for a countertop cut-out for three appliances appliance width appliance width appliance width Countertop minus " (8 mm) minus " (8 mm) cut-out 11" " 11" " (280 mm) (280 mm) (848 mm) (288 mm) 11" 15" "...
  • Page 13 Installation " 3 / 1 6 1 " - 1 0 m m ( 2 5 - 3 2 " 2 " ( 5 0 m ( 5 0 m 2 " 2 " " 3 / 1 6 ( 5 0 m ( 5 0 m 6 "...
  • Page 14: Attach The Spring Clips And Support Bars

    Installation Attach the spring clips and support bars Wood or solid surface countertops Granite countertop " 3 / 1 6 " 3 / 1 6 1 " - 1 1 " - 1 0 m m 0 m m ( 2 5 - 3 ( 2 5 - 3 ^ Place the supplied spring clips a ^ Position and attach the spring clips...
  • Page 15 Installation ^ Coat the edges of the spring clips a, ^ and the space d between the strips b and the countertop with silicone (supplied).
  • Page 16: Installing The Appliance

    Installation Installing the appliance ^ Feed the power cord down through the cut-out. ^ Then place the front side of the appliance in the countertop cut-out. ^ Then with a hand on each side of the appliance press down evenly on the edges until it clicks into position.
  • Page 17: Tiled Surfaces

    Installation Sealing Tiled surfaces The grouting a and shaded area under The appliance must not be permanently sealed into the countertop when the appliance frame must be flat and installed. The sealing strip under the even, so that the frame will lie evenly and the sealing strip under the edge of edge of the appliance provides a sufficient seal for the countertop.
  • Page 18: Electrical Connection

    Electrical connection Power supply CAUTION: Before installation or ^ Be sure your electrical supply servicing, disconnect the power matches the data plate. supply by either removing the fuse, shutting off the main power supply The combiset is equipped with a or manually "tripping"...
