OWNER'S MANUAL

WASHING MACHINE

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

TV2521DV7B / TV2520SV7J / TV2519SV7J / TV2519SV7V / TV2519DV7B /

TV2518DV7B

MFL68780985

Rev.02_082622

Scan the QR code to see the manual.

www.lg.com

Table of Contents

Need help?

Do you have a question about the TV2521DV7B and is the answer not in the manual?

Questions and answers

Summary of Contents for LG TV2521DV7B

Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH TV2521DV7B / TV2520SV7J / TV2519SV7J / TV2519SV7V / TV2519DV7B / TV2518DV7B www.lg.com MFL68780985 Rev.02_082622...
Page 2: Table Of Contents
Preparing the Wash Load ................15 Adding Detergents, Softeners and Bleaches..........17 Control Panel ....................19 Programme Table ....................22 Extra Options and Functions ................25 SMART FUNCTIONS LG ThinQ Application ..................29 Smart Diagnosis ....................31 MAINTENANCE Cleaning after Every Wash................33 Cleaning the Appliance Periodically ..............33 TROUBLESHOOTING...
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
Page 4 • The inlet water pressure must be between 50 and 800 kPa. Maximum Capacity The maximum capacity in some cycles for dry clothes to be washed is: TV2519SV7J / TV2521DV7B TV2520SV7J TV2519SV7V / TV2518DV7B TV2519DV7B...
Page 5 SAFETY INSTRUCTIONS • Do not plug the appliance into multiple outlet sockets or an extension power cable. • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician.
Page 6 • In case of a water leak from the appliance, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
Page 8: Installation Parts And Specifications
INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Accessories *1 The included accessories vary depending on the model you purchased. Cold Water Inlet Hoses Drain Hose Anti-Rat Cover Screw for Anti-Rat Cover Door...
Page 9 INSTALLATION Specifications TV2521DV7B / TV2520SV7J / TV2519SV7J / TV2519SV7V Model / TV2519DV7B / TV2518DV7B Power Supply 220 V~, 50 Hz Product Weight Approx. 45 kg Dimension(mm) D’ H’ 1040 1355...
Page 10: Installation Place Requirements
Contact your local 2 cm 2 cm 10 cm authorised LG repairer. • The power plug must be plugged into an WARNING appropriate outlet socket that is installed and • This appliance must only be used for domestic...
Page 11: Connecting The Water Inlet Hoses
INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and follow the tap.
Page 12 INSTALLATION completely to the tap and then tighten the connector latch plate. Make sure the adapter hose by screwing it to the right. locks into place. Connecting One Touch Type Hose to Tap Without Thread Unscrew the adapter ring plate and loose NOTE the 4 fixing screws.
Page 13: Installing The Drain Hose
INSTALLATION Installing the Drain Hose • The outlet of the drain hose should not be submerged in water. Before connecting the drain hose, check your drain hose model and follow the instructions for that model. Installing the Drain Hose in a Floor Drain Push the elbow end of the hose onto the drain •...
Page 14 INSTALLATION • Turn the adjustable feet clockwise to raise or Insert the anti-rat cover to the assembling turn the adjustable feet counterclockwise to bracket from the back of the appliance. lower the appliance. NOTE • Do not insert pieces of wood etc. under the feet. •...
Page 15: Operation Operation Overview
OPERATION OPERATION Operation Overview • When the cycle is finished, a melody will sound. Immediately remove your clothing from the appliance to reduce wrinkling. Using the Appliance NOTE Before the first wash, select the Normal programme and add a half amount of detergent. •...
Page 16 OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type •...
Page 17: Adding Detergents, Softeners And Bleaches
OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, • Detergent should be selected according to fabric discoloured.
Page 18 OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. Add a fabric softener to the maximum fill line. • If the softener is concentrated, then it should be diluted. • Mix powdered bleach with water to a liquid consistency and pour it into the bleach •...
Page 19: Control Panel
• To use an extra option and function with asterisk, press and hold the button for 3 seconds. Remote Start With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS.
Page 20 OPERATION Wi-Fi Press and hold the Water button for 3 seconds to initiate the connection of the appliance to the LG ThinQ application. START/PAUSE Button • Press this button to start or pause the washing progarmme. NOTE • If the START/PAUSE button is not pressed within a certain time, the appliance will shut off and all settings will be lost.
Page 21 OPERATION Icons on the Display This icon lights up when the Strong Wave option is activated. This icon lights up when the Scent + option is activated. (for Steam Models Only) This icon lights up when the programme starts and the door is locked. This icon lights up when the Tub Clean option is activated.
Page 22: Programme Table
OPERATION Programme Table Washing Programme Wash programmes are designed for the best wash performance for different types of clothes. • Press the washing programme button to select the desired programme. • When you select a wash programme, the light for the corresponding wash programme will turn on. Normal Description Use this programme to wash normal laundry.
Page 23 OPERATION Allergy Care (for Steam Models Only) Description This programme is specifically designed for reducing certain allergens at a powerful, high temperature. • Stains that can be easily removed with this programme are coffee, soda, juice, soy sauce etc. • If only cold water is connected, it takes longer washing time as heating time lengthens.
Page 24 OPERATION Duvet Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
Page 25: Extra Options And Functions
OPERATION Extra Options NOTE • Delay End option can be selected for every washing programme in the table below except the Delicates programme. • All extra options cannot be selected at the same time in the Normal programme. • : Available / X: Not available For Steam Models Programme Steam...
Page 26 OPERATION required and recommended to avoid linting and NOTE unbalanced errors when the load is bulky but lightweight. • If the water pressure of tap water is less than 100 • Press Water option until the desired water level kPa, water does not come out from the JetSpray is selected.
Page 27 OPERATION Using Basic Options NOTE Delay End • Once this function is set, all buttons are locked Use this function to delay ending time. The except the POWER button. appliance will start automatically and finish after a • When the controls are locked, and the specified time interval.
Page 28 OPERATION Beeper • Press and hold the Quick Wash buttons for 3 Use this option to adjust the volume of the sound seconds to adjust the volume of the sound and and turn the beeper off or on. turn the beeper off or on. Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually.
Page 29: Smart Functions
SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone. NOTE LG ThinQ Application Features •...
Page 30 To start the washing programme remotely in the wireless router manual. LG ThinQ application, set the Remote Start • LG ThinQ is not responsible for any network function. You can also monitor your cycle operation connection problems or any faults, so you know how much time is left in the cycle.
Page 31: Smart Diagnosis
If you experience a problem with your Wi-Fi equipped appliance, it can transmit troubleshooting data to a smartphone using the LG ThinQ application. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application.
Page 32 SMART FUNCTIONS Place the mouthpiece of your smartphone close to the POWER button. Press and hold the Normal button for 3 seconds or longer while holding the smartphone mouthpiece to the POWER button until the data transfer is complete. • Keep the smartphone in place until the data transfer has finished.
Page 33: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish.
Page 34 MAINTENANCE Cleaning the Water Inlet Filter NOTE Water inlet filter collects lime or any small objects • For models without a lint filter, the lint is that may be in water supplied to the appliance. discharged when the water drains during Clean the water inlet filter regularly.
Page 35 MAINTENANCE • Be careful not to get your fingernails caught in Close the lid and then insert the lower part of the filter when you handle the filter. the filter into the wash drum. Press the top of the filter until you hear a click sound. •...
Page 36: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting.
Page 37 TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS ERROR • Turn off the appliance and then press the POWER button. Press the Spin button without selecting a cycle to drain and spin the laundry. When the spin is complete, remove the clothes and then find and remove any objects caught in the pulsator gap.
Page 38 TROUBLESHOOTING Symptoms Possible Cause & Solution A motor error has occurred. DRAIN MOTOR ERROR • Unplug the appliance and call for service. is not an error. This prevents children from changing cycles or operating the appliance. CHILD LOCK FUNCTION • Turn off the Child Lock function in the control panel. Vibration sensor malfunctions.
Page 39 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not Appliance is unplugged. operate. • Make sure that the cord is plugged securely into a working outlet. Water supply is turned off. • Turn on the water supply tap completely. Controls are not set properly. •...
Page 40 TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Drain hose has come out of drain or is not inserted far enough. • Tie drain hose to supply hose or standpipe to prevent it from coming out during drain. For smaller drain pipes, insert the drain hose into the pipe as far as the drain hose flange.
Page 41 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance...
Page 42 TROUBLESHOOTING Symptoms Possible Cause & Solution Your home appliance The wireless network name (SSID) is set incorrectly. and smartphone are • The wireless network name (SSID) should be a combination of English not connected to the letters and numbers. (Do not use special characters.) Wi-Fi network.
Page 43 Memo...

This manual is also suitable for:

Tv2520sv7j Tv2519sv7j Tv2519sv7v Tv2519dv7b Tv2518dv7b
