OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
TV2521DV7B / TV2520SV7J / TV2519SV7J / TV2519SV7V / TV2519DV7B /
TV2518DV7B / TV2520DV7B
MFL68780985
Rev.04_071924
Copyright © 2022-2024 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG TV2520DV7B
Summary of Contents for LG TV2520DV7B
- Page 1 Leave these instructions near the product after installation for future reference. ENGLISH TV2521DV7B / TV2520SV7J / TV2519SV7J / TV2519SV7V / TV2519DV7B / TV2518DV7B / TV2520DV7B www.lg.com MFL68780985 Rev.04_071924 Copyright © 2022-2024 LG Electronics. All Rights Reserved...
-
Page 2: Table Of Contents
Preparing the Wash Load ................15 Adding Detergents, Softeners and Bleaches..........17 Control Panel ....................19 Programme Table ....................22 Extra Options and Functions ................25 SMART FUNCTIONS LG ThinQ Application ..................30 Smart Diagnosis ....................32 MAINTENANCE Cleaning after Every Wash ................34 Cleaning the Appliance Periodically ..............34 TROUBLESHOOTING... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. -
Page 4: Maximum Capacity
Maximum Capacity The maximum capacity in some cycles for dry clothes to be washed is: TV2519SV7J / TV2520SV7J / TV2521DV7B TV2519SV7V / TV2518DV7B TV2520DV7B TV2519DV7B 21 kg 20 kg 19 kg 18 kg Installation • Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. - Page 5 SAFETY INSTRUCTIONS • Do not plug the appliance into multiple outlet sockets or an extension power cable. • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician.
- Page 6 • In case of a water leak from the appliance, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
- Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 8: Installation Parts And Specifications
INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View *1 This feature is only available on some models. Accessories *1 The included accessories vary depending on the model you purchased. -
Page 9: Specifications
INSTALLATION Specifications TV2521DV7B / TV2520SV7J / TV2519SV7J / TV2519SV7V Model / TV2519DV7B / TV2518DV7B / TV2520DV7B Power Supply 220 V~, 50 Hz Product Weight Approx. 45 kg Dimension(mm) D’ H’ 1040 1355... -
Page 10: Installation Place Requirements
Repairs carried out by with movable home or house. inexperienced persons may cause injury or serious malfunctioning. Contact your local authorised LG repairer. • The power plug must be plugged into an appropriate outlet socket that is installed and... -
Page 11: Connecting The Water Inlet Hoses
INSTALLATION Connecting the Hose to the grounded/earthed in accordance with all local codes and ordinances. Water Tap Connecting Screw-Type Hose to Tap with Thread Screw the hose connector onto the water supply Connecting the Water Inlet tap. Hoses Before connecting the water inlet hose to the water tap, check the hose fitting type and follow the instructions for that hose fitting. - Page 12 INSTALLATION Push the inlet hose vertically upwards so Pull the connector latch plate down, push that the rubber seal within the hose can adhere the inlet hose onto the adapter, and release the completely to the tap and then tighten the connector latch plate.
-
Page 13: Installing The Drain Hose
INSTALLATION Installing the Drain Hose • The outlet of the drain hose should not be submerged in water. Before connecting the drain hose, check your drain hose model and follow the instructions for that model. Installing the Drain Hose in a Floor Drain Push the elbow end of the hose onto the drain outlet on the back of the appliance. - Page 14 INSTALLATION • Turn the adjustable feet clockwise to raise or Insert the anti-rat cover to the assembling turn the adjustable feet counterclockwise to bracket from the back of the appliance. lower the appliance. NOTE • Do not insert pieces of wood etc. under the feet. •...
-
Page 15: Operation Operation Overview
OPERATION OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will Using the Appliance sound. Immediately remove your clothing from the appliance to reduce wrinkling. Before the first wash, select the Normal programme and add a half amount of detergent. NOTE Start the appliance without clothes. - Page 16 OPERATION Checking the Fabric Care Label • Wash delicates (stockings, underwired bras) in a wash net. This will tell you about the fabric content of your • Close zippers, hooks and strings to make sure clothes and how it should be washed. that these items do not snag other clothes.
-
Page 17: Adding Detergents, Softeners And Bleaches
OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, • Detergent should be selected according to fabric discoloured. - Page 18 OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. Add a fabric softener to the maximum fill line. • Mix powdered bleach with water to a liquid • If the softener is concentrated, then it should be consistency and pour it into the bleach diluted.
-
Page 19: Control Panel
• To use an extra option and function with asterisk, press and hold the button for 3 seconds. Remote Start With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS. - Page 20 OPERATION Wi-Fi Press and hold the Water button for 3 seconds to initiate the connection of the appliance to the LG ThinQ application. START/PAUSE Button • Press this button to start or pause the washing progarmme. NOTE • If the START/PAUSE button is not pressed within a certain time, the appliance will shut off and all settings will be lost.
- Page 21 OPERATION Icons on the Display This icon lights up when the Strong Wave option is activated. This icon lights up when the Scent + option is activated. (for Steam Models Only) This icon lights up when the programme starts and the door is locked. This icon lights up when the Tub Clean option is activated.
-
Page 22: Programme Table
OPERATION Programme Table Washing Programme Wash programmes are designed for the best wash performance for different types of clothes. • Press the washing programme button to select the desired programme. • When you select a wash programme, the light for the corresponding wash programme will turn on. Normal Description Use this programme to wash normal laundry. - Page 23 OPERATION Allergy Care (for Steam Models Only) Description This programme is specifically designed for reducing certain allergens at a powerful, high temperature. • Stains that can be easily removed with this programme are coffee, soda, juice, soy sauce etc. • If only cold water is connected, it takes longer washing time as heating time lengthens.
- Page 24 OPERATION Duvet Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
-
Page 25: Extra Options And Functions
OPERATION Extra Options NOTE • Delay End option can be selected for every washing programme in the table below except the Delicates programme. • All extra options cannot be selected at the same time in the Normal programme. • : Available / X: Not available For Steam Models Programme Steam... - Page 26 OPERATION required and recommended to avoid linting and NOTE unbalanced errors when the load is bulky but lightweight. • If the water pressure of tap water is less than 100 • Press Water option until the desired water level kPa, water does not come out from the JetSpray is selected.
- Page 27 OPERATION • Strong Wave: Press and hold TurboWash minutes. The soak time is indicated on the button for 3 seconds to select the Strong display. Wave option. Setting Press the START/PAUSE button. Child Lock Use Child Lock function to disable the controls. This function can prevent children from changing Using Basic Options programmes or operating this appliance.
- Page 28 OPERATION Unlocking the Control Panel Turn on the power. Press and hold the AI Wash and Spin buttons simultaneously for 3 seconds to deactivate this function. • When this function is deactivated, a beeper will sound and the remaining time for the current cycle will reappear on the display.
-
Page 29: Manual Washing
OPERATION Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the POWER button. Press the Rinse Press the Spin Press the Rinse Press the Wash button. -
Page 30: Smart Functions
SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone. NOTE LG ThinQ Application Features •... - Page 31 Remote Start wireless router manual. To start the washing programme remotely in the • LG ThinQ is not responsible for any network LG ThinQ application, set the Remote Start connection problems or any faults, function. You can also monitor your cycle operation malfunctions, or errors caused by network so you know how much time is left in the cycle.
-
Page 32: Smart Diagnosis
If you experience a problem with your Wi-Fi equipped appliance, it can transmit troubleshooting data to a smartphone using the LG ThinQ application. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application. - Page 33 SMART FUNCTIONS Press the POWER button to turn on the appliance. • Do not press any other buttons. Place the mouthpiece of your smartphone close to the POWER button. Press and hold the Normal button for 3 seconds or longer while holding the smartphone mouthpiece to the POWER button until the data transfer is complete.
-
Page 34: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. -
Page 35: Cleaning The Water Inlet Filter
MAINTENANCE • For models without a lint filter, the lint is WARNING discharged when the water drains during washing. • Leave the door open to dry the drum interior but • Washing small loads regularly (less than half a only if it is safe and any children are supervised. tub). -
Page 36: Cleaning The Lint Filter
MAINTENANCE Cleaning the Lint Filter Wash the filter with a soft brush. The filter is an important part for an efficient washing performance result, so take a special care. Clean the filter regularly. CAUTION • Clean the lint filter after at least 2 - 3 washes. •... -
Page 37: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 38 TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS ERROR • Turn off the appliance and then press the POWER button. Press the Spin button without selecting a cycle to drain and spin the laundry. When the spin is complete, remove the clothes and then find and remove any objects caught in the pulsator gap.
- Page 39 TROUBLESHOOTING Symptoms Possible Cause & Solution A motor error has occurred. DRAIN MOTOR ERROR • Unplug the appliance and call for service. is not an error. This prevents children from changing cycles or operating the appliance. CHILD LOCK FUNCTION • Turn off the Child Lock function in the control panel. Vibration sensor malfunctions.
- Page 40 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not Appliance is unplugged. operate. • Make sure that the cord is plugged securely into a working outlet. Water supply is turned off. • Turn on the water supply tap completely. Controls are not set properly. •...
- Page 41 TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Drain hose has come out of drain or is not inserted far enough. • Tie drain hose to supply hose or standpipe to prevent it from coming out during drain. For smaller drain pipes, insert the drain hose into the pipe as far as the drain hose flange.
- Page 42 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance...
- Page 43 TROUBLESHOOTING Symptoms Possible Cause & Solution Your home appliance The wireless network name (SSID) is set incorrectly. and smartphone are • The wireless network name (SSID) should be a combination of English not connected to the letters and numbers. (Do not use special characters.) Wi-Fi network.
