DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.whirlpool.eu/register
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
7
8
9
11
Service:
0000 000 00000
12
CONTROL PANEL
1. On-Off/Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light
4. Turbo button with indicator light / Key lock
5. Eco program indicator light
6. Key lock indicator light
7. Display
8. Program number and remaining time indicator
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
3T121 X
o cerca il tuo prodotto tra le
1
2
3
4
5
migliori offerte di Lavastoviglie
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
http://docs.whirlpool.eu and following the Instructions
on the back of this booklet.
1
1.Upper rack
2. Foldable flaps
3.Upper rack height adjuster
2
4.Upper spray arm
5.Lower rack
6.Cutlery basket
7.Lower spray arm
3
8.Filter Assembly
9.Salt reservoir
4
10.Detergent and Rinse Aid dispensers
11.Rating plate
5
12.Control panel
6
10
6
7 8
9
10
1112
13
9. Tablet (Tab) indicator light
10. Closed water tap indicator light
11. Salt refill indicator light
12. Rinse Aid refill indicator light
13. Power Clean button with indicator light / Tablet (Tab)
14. Sani Rinse button with indicator light / Tablet (Tab)
15. Delay button with indicator light
16. Start/Pause button with indicator light / Drain out
Whirlpool WFO
14
15
16
EN
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WFO 3T121 X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Whirlpool WFO 3T121 X

Summary of Contents for Whirlpool WFO 3T121 X

  • Page 1 Lavastoviglie DAILY REFERENCE GUIDE THANK YOU FOR BUYING A WHIRLPOOL PRODUCT. You can download the Safety Instructions and the Use In order to receive a more complete assistance, please and Care Guide, by visiting our website register your appliance on: http://docs.whirlpool.eu and following the Instructions...

  • Page 2: First Time Use

    FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER After installation, remove the stoppers from the racks and the retaining Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be filled elastic elements from the upper rack.

  • Page 3: Programs Table

    PROGRAMS TABLE Detergent Duration of Water con- Energy con- container Program Available options wash program sumption sumption (h:min) (litres/cycle) (kWh/cycle) 1. Eco 50° 3:10 0.83 2. 6 50°-60° 1:25-3:00 7.0-14.0 0.9-1.40 Sense 3. Intensive 65° 2:50 14.0 1.50 4. Daily 50°...

  • Page 4: Multi Zone

    OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding TABLET (Tab) button (see CONTROL PANEL). This setting allows you to optimize the performance of the program according to the type of detergent used. If an option is not compatible with the selected program see Press the TABLET button (the indicator and PROGRAMS TABLE, the corresponding LED flashes rapidly 3 times corresponding symbol will light up) if you use combined...

  • Page 5: Daily Use

    DAILY USE 1. CHECK WATER CONNECTION MODIFYING A RUNNING PROGRAM Check that the dishwasher is connected to the water supply and that If a wrong program was selected, it is possible to change it, provided the top is open. that it has only just begun: press and hold the ON/OFF button, the 2.

  • Page 6: Loading The Racks

    LOADING THE RACKS UPPER RACK LOWER RACK For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids Load delicate and light dishes: glasses, cups, saucers, low salad bowls. should ideally be placed at the sides to avoid interferences with the spray arm.

  • Page 7: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water.

  • Page 8: Troubleshooting

    • After-Sales Service; phone number see in warranty booklet. right side inside the door of the • download from website: http://docs.whirlpool.eu dishwasher. The phone number is listed • use QR code: in the warranty booklet or on the website: http://www.whirlpool.eu...
