Snell CVR700 Operator's Manual

Sd & hd sdi standards converter with synchronizer, up, down and cross conversion

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

CVR700 Standards Converter

SD & HD SDI Standards Converter with Synchronizer, Up, Down

Snell & Wilcox Ltd., Southleigh Park House, Eastleigh Road, Havant, Hants, PO9 2PE, United Kingdom.

For General Enquiries contact:

For Technical assistance contact: Tel: +44 (0) 2392 489058

and Cross Conversion

Tel: +44 (0) 2392 489000

Web:

http://www.snellwilcox.com/support

Ftp:

ftp://ftp.snellwilcox.com/support

Operator's

Manual

Fax: +44 (0)23 9245 1411

Fax: +44 (0) 2392 489057

Table of Contents

Need help?

Do you have a question about the CVR700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Snell CVR700

Page 1 Cross Conversion Operator’s Manual © May, 2009 Snell & Wilcox Ltd., Southleigh Park House, Eastleigh Road, Havant, Hants, PO9 2PE, United Kingdom. For General Enquiries contact: Tel: +44 (0) 2392 489000 Fax: +44 (0)23 9245 1411 For Technical assistance contact: Tel: +44 (0) 2392 489058...
Page 2 Prise Attention si l'appareil a 2 alimentations, s'assurer que les cordons soient branchés sur la même phase. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 3 Varning! Om enheten har två huvudsakliga elförsörjningar, säkerställ att on liitettävä verkkopistorasioihin, joissa on sama vaiheistus. båda strömkablarna som är inkopplade i enheten arbetar från samma fas. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 4 Note that for equipment that is not fitted with a mains power switch, to comply with EN60950 Clauses 1.7.2 and 2.6.9, the power outlet supplying power to the unit should be close to the unit and easily accessible. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion ©...
Page 5 EMC Performance of Cables and Connectors Snell & Wilcox products are designed to meet or exceed the requirements of the appropriate European EMC standards. In order to achieve this performance in real installations it is essential to use cables and connectors with good EMC characteristics.
Page 6: About This Manual
Information in this manual and software are subject to change without notice and does not represent a commitment on the part of Snell & Wilcox Ltd. The software described in this manual is furnished under a license agreement and may not be reproduced or copied in any manner without prior agreement with Snell &...
Page 7: Table Of Contents
Operation via the Front Panel ........................17 Operation via the Web Interface ......................34 Appendix (Automated Aspect Ratio Control)..................47 Manual Revision Record...........................52 CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 8: Description
HD CVR700BD (5068020) Balanced AES & Analog Audio Order Codes • CVR700UD – FGACZ 5068010 CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 8...
Page 9: Technical Profile
(if same frequency) Encode L23, Video Index and SMPTE 2016-1 (AFD) and insert on output CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 10 DAC output Processed pairs A & B (fixed – source no control) 1 & 2 CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 10...
Page 11 Therefore the total delay in ARC mode will vary between 2 fields (minimum) and 4 fields + 1ms (maximum). CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 12: Installation
Clauses 1.7.2 and 2.6.9, the power outlet supplying power to the unit should be close to the unit and easily accessible. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 13 AES audio input is via the 25 way D-Type connector. Analogue Audio Analogue audio input is via the 25 way D-Type connector. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 13...
Page 14 Control Connections Ethernet Connection to a Web browser can be made via the 10/100 BaseT Ethernet connection. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 15 AES In Pair 1 ‘G’ GND8 Analog In Pair 1 left ‘G’ D-Type Connector (On Unit) CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 15...
Page 16 Audio A Control Audio 1 Audio Audio B Audio Audio 2 Audio Ethernet Remote control CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 16...
Page 17: Operation Via The Front Panel
These buttons provide access to the unit’s Video, Image, Genlock, Audio In and Audio Out menus, as well as to the More menu, which provides access to additional setup functions. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 18 625i • Back Output 525i • 720P50 Select -625i- • 720P59.94 • 1080i50 • 1080i59.94 CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 18...
Page 19 +6dB in 0.2dB steps. Back Color Saturation Preset will return the Chroma Gain to 0dB. Preset 0.0dB CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 19...
Page 20 This control is only effective if the input and output formats are Back Sync Mode identical. Enable CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 20...
Page 21 • Anti-Alias is designed to prevent objectionable aliases in the output pictures. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 21...
Page 22 This control Enables or Disables pair routing for Back Pair Routing B audio input pair B. Select Enabled CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 22...
Page 23 This control Enables or Disables pair routing for audio input pair D. Select De-embed ch 8 Back Pair Routing D Select Enabled CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 23...
Page 24 Tone Frequency between 100Hz and 10kHz in 100Hz steps. Preset 100Hz The preset value is 1000Hz. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 24...
Page 25 Rotate the knob to adjust the pair gain ±18dB in Preset 0.0dB 0.1dB steps. The preset value is 0dB. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 25...
Page 26 Preset 18.0 dBu DAC 2 outputs audio selected under the Audio B tab. The preset value is 18.0 dBu. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 27 Back Genlock Free run Output video is locked to an internal reference Select -Freerun- clock. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 27...
Page 28 93% of the effective picture height and Back Safe area marks width. Select CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 28...
Page 29 See “Operation via the Web interface” for more details. • • ETSI • Force • Delete CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 29...
Page 30 AFD are Enable blanked, or passed from the input if selected. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 31 16/9 centre • 16/9 top • >16/9 centre • 4:3 SP 14/9 • 16/9 FF CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 31...
Page 32 4:3 AFD 1 details. • 4/3 AFD 0 to 7 • 16:9 AFD 0 to 7 CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 32...
Page 33 In DHCP mode, it will display 0.0.0.0 when disconnected from the network. MAC Address This displays the unit’s MAC address. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 34: Operation Via The Web Interface
Operation via the Web Interface In addition to the unit front controls, the CVR700 can also be controlled by means of a Web interface accessed via the 10/100 BaseT Ethernet connection. Connection to the Web interface can either be made directly or via a DHCP network.
Page 35 3. Connect to the unit by entering the given address into your web browser, preceded by “http://” if necessary. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 36 Red indicates that the browser is not currently controlling the unit, while green indicates the connection is functioning normally. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 37 In DHCP mode, it will display 0.0.0.0 when disconnected from the network. MAC Address This displays the unit’s MAC address. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 38 This allows the video input source to be selected. Click the corresponding radio button to select either input A or input B. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 39 • 16:9 LB effective if the input and output formats are identical • 16:9 An CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 39...
Page 40 Normal provides the best compromise for typical input pictures. Anti-Alias is designed to prevent objectionable aliases in the output pictures. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 41 +32us and -32us in 37ns steps. Click the reset button to return the control to its preset value of 0us. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 42 VI data other than coded frame and AFD are blanked, otherwise, they are passed from the input if appropriate. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 43 L23 force bits: • Determines whether the L23 user bits set above are forced into the L23 output. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 44 The options on the Signalling 2 tab specify the output that will be forced if the corresponding Force option is selected on the Signalling 1 tab. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 45 8 is selected for Audio in A – Left the unit will automatically route ch 9 to Audio in A – Right. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell &...
Page 46 Tone Frequency Use the slider to adjust the tone frequency between 100Hz and 10kHz in 100Hz steps. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009...
Page 47: Appendix (Automated Aspect Ratio Control)
Appendix (Automated Aspect Ratio Control) Recognized Input Signalling The CVR700 can be configured to respond automatically to a variety of Aspect Ratio signalling standards, controlling both the ARC conversion that is performed, and the new signalling that can be inserted at the unit’s video outputs.
Page 48 16/9 AFD 7 Reserved 16/9 Anamorphic Normal 16/9 16/9 AFD 12 Reserved 16/9 Anamorphic Normal 16/9 CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 48...
Page 49 SD 16/9 16/9 AFD 8 Coded 16/9 16/9FF Anamorphic Anamorphic Anamorphic Frame AFD 0- Coded Frame CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 49...
Page 50 Product Support Procedure If you experience any technical or operational difficulties with a Snell & Wilcox product please do not hesitate to contact us or utilize our online form to request assistance. There is a lot of information you can give us that will enable us to diagnose your problem swiftly. Please read the following guidelines, as these suggestions will help us to help you.
Page 51 Eastleigh Road, Fax: +44 (0) 2392 489057 Havant, Hants, http://www.snellwilcox.com/support PO9 2PE. ftp://ftp.snellwilcox.com/support United Kingdom. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 51...
Page 52: Manual Revision Record
Corrected input/output pin 25/02/09 New issue. connections. 18/05/09 Added Throughput delays to the New issue. Technical Profile. CVR700 SD & HD SDI Standards Convertor with Synchronizer, Up, Down and Cross Conversion © Version 1 Issue 5 Snell & Wilcox 2009 Page 52...
