Remote control of LC300/LC350

Press the System shortcut button, then select Network->IP Configuration to choose between

Static or DHCP (default)

If static IP address has been selected, use each of the following menu items in turn to set the

required parameters

Enter IP address

Enter IP netmask

Enter IP gateway

Numerals are printed to the right of each shortcut button. Entering three digits into an address

field will automatically advance to the next field. Use leading zeros if the value in the field is less

than 3 digits.

Then select

Apply IP changes

Note that the new IP address, netmask and gateway will not take effect until the Apply IP changes

control is selected. Once IP connection is configured, you can use RollCall or SNMP to control

the device remotely.

With Java version 8 update 25 installed and Internet Explorer 11, it is possible to remotely control

the LC300/350 without using RollCall. Simply type the unit's IP address into the address bar of IE

then double click the "Control Applet" icon at the top of the screen. This will generate a user

interface which emulates the RollCall interface.

Detailed information is available in the user manual available at

http://www.snellgroup.com/support/product-handbooks/conversion_restoration

www.snellgroup.com

Table of Contents

Do you have a question about the LC300 and is the answer not in the manual?

Page 1 With Java version 8 update 25 installed and Internet Explorer 11, it is possible to remotely control the LC300/350 without using RollCall. Simply type the unit's IP address into the address bar of IE then double click the "Control Applet" icon at the top of the screen. This will generate a user interface which emulates the RollCall interface.
Page 2 Introduction LC300 and LC350 are single channel frame rate converters suitable for a range of applications including low cost international program distribution and multi-standard content handling. The converters are controlled via the easy-to-use front panel and via remote control using Snell's RollCall control and monitoring software, which is available from www.snellgroup.com.
