Comprehensive CCN-DH101 User Manual

Download this manual

CCN-DH101

USER MANUAL

Table of Contents

1.0 Introduction..........................................................................1

2.0 Specifications............................................................1

3.0 Package Contents......................................................2

4.0 Panel Descriptions.....................................................2

5.0 Connection and Operation..................................................3

C a b l e a n d C o n n e c t i v i t y C o m p a n y

Need help?

Do you have a question about the CCN-DH101 and is the answer not in the manual?

Page 1 CCN-DH101 USER MANUAL Table of Contents 1.0 Introduction................1 2.0 Specifications…………………………………….………..……1 3.0 Package Contents………………………………………….…..2 4.0 Panel Descriptions…………………………………….…….…2 5.0 Connection and Operation..........3 C a b l e a n d C o n n e c t i v i t y C o m p a n y...
Page 2 DVI + Audio to HDMI Converter DVI + Audio to HDMI Converter Dear Customer Thanks for your purchase of the DVI Audio to HDMI Converter. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
Page 3 DVI + Audio to HDMI Converter Connector HDMI Connector type A (19 pin) female DVI Connector DVI-I (29 pin) female (digital only) Audio Connector Toslink Audio and Digital Audio Operating Frequency Vertical Frequency Range 50/60Hz Video Amplifier Bandwidth 2.25Gbps/225MHz Resolutions(HDTV) Interlaced(50&60Hz) 480i,576i,1080i Progressive(50&60Hz)
