DRAIN LINE CONNECTION

Drain line elbow
Locking clip
Locking clip
Air gap
CAUTION:
Never connect drain line directly into
drain, sewer line or trap. Always allow an air gap of at
least 25mm (1 inch) or 2 pipe diameters between the
drain line and waste water to prevent the possibility of
sewage being back siphoned.
5
