PLUMBING CONNECTION

Check local codes for minimum
run between Reionator Pro
Ulta unit and water heater
Conditioned
water in
Hot
Typical plumbing installation
Cold
Hot water heater
Raw water to
outside faucets
Raw
water in
Triton Bypass Valve
IMPORTANT:
Brass or Plastic yoke
assembly (not shown) is required to
connect piping to the bypass valve and
is available in either NPT or solvent.
4
