Water Tech SP Series Owner's Manual

Whole house water conditioner with triton electronic control valve
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNERS MANUAL
OWNERS MANUAL
Whole House Water Conditioner
Whole House Water Conditioner
With Triton Electronic Control Valve
With Triton Electronic Control Valve
Activate your warranty by registering
your product at watertech.com or
call 469-521-1180.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Water Tech SP Series

Summary of Contents for Water Tech SP Series

  • Page 1 OWNERS MANUAL OWNERS MANUAL Whole House Water Conditioner Whole House Water Conditioner With Triton Electronic Control Valve With Triton Electronic Control Valve Activate your warranty by registering your product at watertech.com or call 469-521-1180.

  • Page 2: Table Of Contents

    DEALER CONTACT AND PRODUCT INFORMATION Dealer Name: Dealer Phone Number: Installation Date: Model Number: Serial Number: TABLE OF CONTENTS General Information Do's and Dont's ................Displays and Programming ............. Plumbing Connection ..............Drain Line Connection ..............Bypass Valve Operation ..............Bypass Valve Illustrations ...............

  • Page 3: Do's And Dont's

    DO’S AND DONT’S DO ALWAYS check your state and local regulations regarding plumbing and electrical connections and placement of the system before installation. • install the system into the existing cold water supply line before the water heater and before any cold water outlet that requires treatment. •...

  • Page 4: Displays And Programming

    DISPLAYS & PROGRAMMING CLOCK / HOME RIGHT / NEXT LEFT / BACK INFO SET CLOCK Press CLOCK one time. The hours will begin to flash. to adjust the hour. The hours will cycle through AM and PM. Once the hour is set correctly, press one time to set the minutes.
  • Page 5 DISPLAYS & PROGRAMMING CLOCK / HOME RIGHT / NEXT LEFT / BACK INFO SETTING REGENERATION TIME Enter the Installer Screens by pressing and holding simultaneously for for 3-5 seconds. Once the display changes, press until you reach the “Regeneration Time” display. When on the “Regeneration Time”...

  • Page 6: Plumbing Connection

    PLUMBING CONNECTION Typical plumbing installation Raw water to outside faucets water in Check local codes for minimum run between unit and water heater Conditioned water in Triton Bypass Valve Cold IMPORTANT: Brass or Plastic yoke assembly (not shown) is required to connect piping to the bypass valve and is available in Hot water heater either NPT or solvent.

  • Page 7: Drain Line Connection

    DRAIN LINE CONNECTION Brine Drain line elbow line elbow Locking clip Locking clip Air gap CAUTION: Never connect drain line directly into drain, sewer line or trap. Always allow an air gap of at least 25mm (1 inch) or 2 pipe diameters between the drain line and waste water to prevent the possibility of sewage being back siphoned.

  • Page 8: Bypass Valve Operation

    BYPASS VALVE OPERATION The bypass valve is typically used to isolate the control valve from the plumbing system’s water pressure in order to perform control valve repairs or maintenance. The 1" full flow bypass valve incorporates four positions including a diagnostic position that allows service personnel to work on a pressurized system while still providing untreated bypass water to the facility or residence.

  • Page 9: Bypass Valve Illustrations

    BYPASS VALVE ILLUSTRATIONS FIGURE 1. FIGURE 2. NORMAL OPERATION BYPASS OPERATION Treated Supply Supply Supply water exits water enters water exits water enters FIGURE 3. FIGURE 4. DIAGNOSTIC MODE SHUT OFF MODE POSITION Supply Supply No water Supplywater is shut off water exits water enters exits...
  • Page 10 SYSTEM MAINTENANCE AND PROGRAMMING PAGES 9-11...

  • Page 11: Maintenance

    MAINTENANCE With minimal care, your system is designed to serve you for many years. While constant attention to your system is not necessary, the following suggestions will ensure your system’s performance and your convenience and satisfaction. MAINTENANCE Your system should be serviced every 1-2 years (or as needed) by a factory authorized service technician to ensure that all components and overall system are functioning properly.

  • Page 12: Starting Up The System

    STARTING UP THE SYSTEM Flushing, Conditioning and Sanitizing Did you connect the drain line securely to the valve? Did you connect the brine line securely to the valve? Step 1. Make sure the system is in the “Bypass” position before turning the main water back on.

  • Page 13: Starting Up The System

    STARTING UP THE SYSTEM Continue to press REGEN (wait for the motor to stop before pressing REGEN again) until you reach the SOFTENING position. Fill the brine tank with salt. Ensure that salt used is intended for water softners. Step 3. To ensure sanitary conditions in the mineral and brine tanks, pour 1.5 ounces common household bleach into the brine well (4”...
  • Page 14 SYSTEM MAINTENANCE AND PROGRAMMING PAGES 13-15...

  • Page 15: Maintenance

    MAINTENANCE With minimal care, your system is designed to serve you for many years. While constant attention to your system is not necessary, the following suggestions will ensure your system’s performance and your convenience and satisfaction. MAINTENANCE Your system should be serviced every 1-2 years (or as needed) by a factory autho- rized service technician to ensure that all components and overall system are functioning properly.

  • Page 16: Starting Up The System

    STARTING UP THE SYSTEM Flushing, Conditioning and Sanitizing Did you connect the drain line securely to the valve? Did you confirm the brine elbow is securely in place with air filter on end of tubing? Step 1. Make sure the system is in the “Bypass” position before turning the main water back on.
  • Page 17 STARTING UP THE SYSTEM Step 3. Make sure that the bypass valve is completely set in the “Normal Operation” position. Let the water in the taps of the building run for several minutes to purge the unconditioned water out of the pipes. Step 4.
  • Page 18 SYSTEM MAINTENANCE AND PROGRAMMING PAGES 17-18...
  • Page 19 MAINTENANCE With minimal care, your system is designed to serve you for many years. While constant attention to your system is not necessary, the following suggestions will ensure your system’s performance and your convenience and satisfaction. MAINTENANCE Your system should be serviced every 1-2 years (or as needed) by a factory authorized service echnician to ensure that all components and overall system are functioning properly.
  • Page 20 STARTING UP THE SYSTEM Flushing and Conditioning Did you connect the drain line securely to the valve? Step 1. Make sure the system is in the “Bypass” position before turning the main water back on. See page 7. Make sure the drain line provided is connected securely to the control valve and is properly located over a drain.
  • Page 21 NOTES...
  • Page 22 WaterTech Industries MAX Residential Series 5/10 Year Warranty Applicable to: DEEPMAX, FERROMAX, NEUMAX, NITROMAX, OXIMAX Air, SORBMAX,SORBMAX Air WaterTech Industries (WTI) hereby warrants said equipment, only to the original purchaser at the original installation location. THIS WARRANTY PERIOD BEGINS at the time of initial installation and use. The warranty becomes valid upon registration of the equipment.

  • Page 23: Warranty

    components. This warranty expressly excludes any system which has been damaged by accident, fire, flood, Act of God, abuse, neglect, freezing, excessive temperature (below 40° F or above 110° F.), inappropriate pressure (below 20 psi or above 100 psi), misuse, alteration of product in any way by owner or installing company, product identification tampering, misapplication, installation or operation not consistent with WTI instructions and installation outside of applicable plumbing codes and local regulations.
