On the C2SBA/C2SBA+/C2SBA+II/C2SBE Revision 1.2 Motherboard
The silk screen label for SATA Ports 0~3 on PCB Rev. 1.2 motherboards is shown below:
The correct silk screen label for these SATA ports should be as follows:
This silk screen label change applies to PCB Revision 1.2 motherboards only and has been cor-
rected in subsequent motherboard revisions.

An Important Note to the User

The Silk Screen Label for SATA Ports 0~3

3
I-SATA
2
I-SATA
1
I-SATA
0
I-SATA

PCB Revision 1.2

2
I-SATA
3
I-SATA
0
I-SATA
1
I-SATA

PCB Revision 1.2A

I-SATA4
I-SATA5
I-SATA4
I-SATA5
Addendum-C2SBA PCB Rev. 1.2-5/1/2008
