Parker SMOKEETER SE-40 Owner's Manual

Parker SMOKEETER SE-40 Owner's Manual

Commercial air cleaner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
Commercial Air Cleaner Smokeeter Models
:
®
SE-40/Variable Speed | SE-50/ 3 Speed

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMOKEETER SE-40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Parker SMOKEETER SE-40

Summary of Contents for Parker SMOKEETER SE-40

  • Page 1 Owner's Manual Commercial Air Cleaner Smokeeter Models ® SE-40/Variable Speed | SE-50/ 3 Speed...
  • Page 2 For quick future reference, fill in the system and filter information in the spaces below. Should you need assistance, call the Parker Hannifin customer service number shown below. To expedite your service, have the following information available when contacting Parker Hannifin.
  • Page 3 Owner's Manual: SMOKEETER® Electronic Air Cleaner Safety Precautions We have provided many important safety messages in this manual and on the SMOKEETER Electronic Air Cleaner. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and the word “DANGER”, “WARNING”, or “CAUTION”.

  • Page 4: Table Of Contents

    Owner's Manual: SMOKEETER® Electronic Air Cleaner Table of Contents IMPORTANT NOTICE _______________________________________________________________________________ 3 INSPECTION OF EQUIPMENT _______________________________________________________________________ 3 HOW YOUR AIR CLEANER OPERATES ________________________________________________________________ 3 3.1 COMPONENTS THAT MAKE IT WORK ____________________________________________________________ 3 INSTALLATION _____________________________________________________________________________________ 3 4.1 WALL MOUNTING ______________________________________________________________________________ 4 4.2 SUSPENSION __________________________________________________________________________________ 5 OPERATION _______________________________________________________________________________________ 5 CLEANING ________________________________________________________________________________________ 5...
  • Page 5 Owner's Manual: SMOKEETER® Electronic Air Cleaner SPECIFICATIONS POWER REQUIREMENTS AIR HANDLING CAPACITY MODEL SE 40 115 VAC, 60 HZ Low - 450 to 950 CFM* WEIGHT Hanging …… 113 lbs. (51 kg) 6.0 Amps (max.) Shipping …… 120 lbs. (54 kg) POWER CONSUMPTION DIMENSIONS 690 Watts (max.)
  • Page 6 Owner's Manual: SMOKEETER® Electronic Air Cleaner DIMENSIONS SE 40 SE 50...

  • Page 7: Important Notice

    Proper use of speed taps. The SE 50 is shipped from the factory with the equipment must be discussed with Parker Hannifin the switch wired to the low, medium and high speed or your local representative. Operating personnel must motor taps.

  • Page 8: Wall Mounting

    Owner's Manual: SMOKEETER® Electronic Air Cleaner 4.1 Wall Mounting Place the unit on a lifting device. Position the lifting device under the wall mounting cleat. Raise the unit into position Level and securely attach the mounting cleat to the wall, and engage the wall mounting cleat with the cleat mounted ensuring given dimension from ceiling to bolt centerline to the unit.

  • Page 9: Suspension

    Owner's Manual: SMOKEETER® Electronic Air Cleaner 5.0 OPERATION 4.2 Suspension For best results and to assure maximum air quality, Threaded rod, wire or eyebolts and chain may be used your SMOKEEETER unit should be started before the for hanging the unit. Four “knockouts”, located as shown air becomes contaminated.

  • Page 10: Cleaning

    Owner's Manual: SMOKEETER® Electronic Air Cleaner 6.2 Cleaning 2. Slide components from the cabinet. Major cleaning is confined to the prefilter, ionizer, collection cell and the inside cabinet. These should be cleaned periodically to assure continued efficiency. Cleaning may be required from once a month to once every four months depending on the air quality.

  • Page 11: Periodic Maintenance And Troubleshooting

    Owner's Manual: SMOKEETER® Electronic Air Cleaner 7.0 PERIODIC MAINTENANCE AND 4. Motor/Blower - draws in contaminated air and exhausts clean air through the outlet. TROUBLESHOOTING 7.2 How the High Voltage is Supplied to THE FOLLOWING SECTIONS ARE FOR THE USE OF the Components TRAINED SERVICE PERSONNEL ONLY.

  • Page 12: Checking The Power Supply Output

    Owner's Manual: SMOKEETER® Electronic Air Cleaner 7.6 Ionizer Voltage by placing the probe’s tip on the ionizer high voltage contact located on inside back wall of cabinet (follow Place the probe’s tip on the ionizer (refer to Figure 6) #8 wire). and measure the positive DC voltage.

  • Page 13: Checking Motor Capacitor

    When returning a defective part under warranty, 5. Read the VOM scale. The meter should deflect to 0 you must call Parker Hannifin for a customer return and slowly rise to infinity. authorization number (RMA). This number should NOTE: This indicates that the capacitor will charge appear on the package that is being returned.

  • Page 14: Troubleshooting Table

    5. Increase blower speed. 6. Placement of unit not creating a 6. Contact your local distributor or good air pattern. Parker Hannifin. 1. Determine loss of input voltage. 1. Loss of input 115 VAC. 2. Check for: 2. Ionizer/collection cell/unicell A.

  • Page 15: Illustrated Parts

    Owner's Manual: SMOKEETER® Electronic Air Cleaner 10.0 llustrated Parts SE 40 Final Assembly...
  • Page 16 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 40 Final Assembly Item No. Part No. Description Quantity 10-2820 MOTOR/BLOWER ACCESS DOOR (WG) 10-2821 COMPONENT ACCESS DOOR (WG) 02-2544 MOTOR/BLOWER ASSEMBLY + 02-1321 UNICELL ASSEMBLY + 02-2725 CENTER POST ASSEMBLY + 21-1218 POWER SUPPLY (GREY PLASTIC CONSTRUCTION) 03-1078 WIRE KIT HV...
  • Page 17 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 40 UNICELLULAR ASSEMBLY 02-1321...
  • Page 18 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 40 Unicellular Assembly 02-1321 Item No. Part No. Description Quantity 35-0067 CELL SPACER 35-0175 CELL ROD 10-1373 AIR FOIL CORNER CHANNEL 02-1318 CELL ROD TO CONTACT WIRE ASSEMBLY 10-1375 IONIZER SUPPORT 36-0004 IONIZER SPRING 03-0393 IONIZER WIRE ASSEMBLY, SET OF 5 10-1374...
  • Page 19 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 40 Motor/Blower Assembly 02-2544 Item No. Part No. Description Quantity 32-0083 BLOWER — DIRECT DRIVE 02-1327 MOTOR 20-0569 CAPACITOR 20-1298 CAPACITOR STRAP 30-0335 SCREW — HEX HD #8-32 X 1/2" SELF TAP 30-0077 SCREW —...
  • Page 20 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 40 Center/Post Assembly 02-2725 Item No. Part No. Description Quantity 10-2825 EXTRUSION, CENTER POST 02-1326 SWITCH — CONTROL VARIABLE SPEED 20-0229 LIGHT — PILOT, AMBER 20-0560 SWITCH — INTLK — DP NO 30-0164 RETAINER, SOUTHCO 30-0165 SCREW, WING HEAD...
  • Page 21 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 50 FINAL ASSEMBLY...
  • Page 22 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 50 Final Assembly Item No. Part No. Description Quantity 18-0800 CABINET WELDMENT 10-2823 COMPONENT ACCESS DOOR 10-2822 BLOWER ACCESS DOOR 02-10650-0001 MOTOR/BLOWER ASSEMBLY + 02-10651-0001 CENTER POST ASSEMBLY + 33-0039 DISCHARGE GRILL 21-1218 POWER SUPPLY 33-0001 MESH FILTER...
  • Page 23 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 50 Ionizer Assembly/Airfoil Ionizer 02-0089 Item No. Part No. Description Quantity 30-0030 1/4-20 LOCK NUT 30-0049 1/4" FLAT WASHER 35-0027 10-0465 CORNER CHANNEL 37-0004 INSULATOR 10-0570 IONIZER WIRE SUPPORT RAILS 30-0142 #8-32 X 1/2" PAN HEAD SCREW 30-0081 #8 FLAT WASHER 10-0420...
  • Page 24 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 50 Center/Post Assembly 02-10651-0001 Item No. Part No. Description Quantity 30-0030 1/4-20 LOCK NUT 37-0008 INSULATOR 10-0564 HANDLE 10-0559 COVER PLATE, HANDLE 10-0348 END PLATE 41-0330 WARNING LABEL 10-0157 HOT CELL PLATE 10-0158 GROUND CELL PLATE 35-0067 SPACER...
  • Page 25 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 50 Center/Post Assembly 02-10651-0001 Item No. Part No. Description Quantity 10-11706-001 CENTER POST 02-1231 SWITCH — CONTROL 3-SPEED 20-0229 LIGHT — PILOT, AMBER 20-0560 SWITCH — INTLK-DP NO 30-0164 RETAINER, SOUTHCO 30-0165 SCREW, WING HEAD 30-0301 SCREW —...
  • Page 26 Owner's Manual: SMOKEETER® Electronic Air Cleaner SE 50 Motor/Blower Assembly 02-10650-0001 Item No. Part No. Description Quantity 32-0085 BLOWER — DIRECT DRIVE 10-10 22-10018-0001 MOTOR, 5-SPEED 20-10090-0001 CAPACITOR, 5NF 20-1298 CAPACITOR MOUNTING BRACKET 30-0233 BOLT, HEX HD 1/4-20 X 1" L 30-0335 DRILL SCREW #8-32 X 1/2"...
  • Page 27 Owner's Manual: SMOKEETER® Electronic Air Cleaner 11.0 Wiring Diagram MODEL SE 40 41-2488 MODEL SE 50 41-10028...

  • Page 28: Product Warranty

    MCB, PNP, SDC, SFC, and SHM series will be free from defects in materials and workmanship for ten (10) years from the date of shipment from Parker. Subject to the terms and conditions hereof, warrants to the original...
  • Page 29 PRODUCT and its usage. Upon receipt of the claim, Parker IGFG will review and determine if the parts replaced need to be returned for quality evaluation and root cause investigation. If a part is required to be returned, Parker IGFG will issue a Return Material Authorization (RMA) to Return via email.
  • Page 30 Owner's Manual: SMOKEETER® Electronic Air Cleaner NOTES ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________...
  • Page 31 Owner's Manual: SMOKEETER® Electronic Air Cleaner NOTES ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________...
  • Page 32 Metamora, Ohio 419 644 4311 Arnhem, Netherlands +31 (0) 26 376 0376 © 2023 Parker Hannifin Corporation. Product names are trademarks or registered trademarks of their respective companies. Rev. A 072023 Parker Hannifin Corporation Industrial Gas Filtration and Generation Division 4087 Walden Avenue Lancaster, NY 14086 p: 800.343.4048...
