Breathing Air Purifier
BAC-4015
User Guide
Original Language
EN
aerospace
climate control
electromechanical
filtration
fluid & gas handling
hydraulics
pneumatics
process control
sealing & shielding

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAC-4015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Parker BAC-4015

  • Page 1 Breathing Air Purifier climate control electromechanical BAC-4015 filtration User Guide fluid & gas handling hydraulics Original Language pneumatics process control sealing & shielding...
  • Page 3: Table Of Contents

    Table of Contents 1 Safety Information ......................................2 2 Description ........................................3 2.1 Technical Specification..................................3 2.2 Weights and Dimensions ..................................4 2.3 Receiving and Inspecting the Equipment ............................4 2.3.1 Unpacking the Equipment ................................4 2.3.2 Lifting and handling ..................................4 2.4 Overview of the Equipment .................................5 3 Connecting and Operating the Equipment..............................6 3.1 General Installation Requirements ..............................6 3.2 Operating the Equipment..................................6...
  • Page 4: Safety Information

    If the user employs an operating procedure, item of equipment or a method of working which is not specifically recommended by Parker Hannifin the user must ensure that the equipment will not be damaged or become hazardous to persons or property.
  • Page 5: Description

    The Parker domnick hunter BAC-4015 is a fully portable pneumatically controlled air purification system designed to provide breathing quality air to a higher level than specified in EN12021 for oil mist, vapour, odour and particulate removal. The BAC-4015 will also remove carbon monoxide (CO) and reduce carbon dioxide (CO2) to fully meet EN12021 and other international specifications.
  • Page 6: Weights And Dimensions

    If there are any signs of damage to the crate, or there are any parts missing please inform the delivery company immediately and contact your local Parker domnick hunter office. 2.3.1 Unpacking the Equipment The panels of the crate are secured using nails.
  • Page 7: Overview Of The Equipment

    2.4 Overview of the Equipment Description Description BAC-4015 Lockable door c/w keys G 3/8 Regulator Inlet adaptor Hours Run Meter Outlet manifold Inlet pressure gauge AC Grade filter Outlet pressure gauge HC Grade filter Audible warning device AIR PACK 2000 Dryer...
  • Page 8: Connecting And Operating The Equipment

    The three outlet connections are G1/4 BSPP internally threaded to IS0228 (BSPP) for use with parallel fittings. The BAC-4015 must be operated in a vertical position and must not be situated where it is able to tilt or be dislodged from its operating position.
  • Page 9: Safety Features

    3.3.2 Flow limiting orifice This device limits the outlet flow rate proportionally to the line pressure thus ensuring that the volumetric air flow rate of the BAC-4015 is not exceeded. The flow limiting orifice is located immediately after the outlet pressure regulator.
  • Page 10: Preventative Maintenance Kits

    4 Preventative Maintenance Kits 4.1 Service Intervals Description of Service Required Service recommended every: Component Operation Check for air leaks. Complete Assembly Check the pressure gauges during purging for excessive back Filtration pressure. See Note (1) Replace the adsorption filter elements - Activated Carbon Filtration Recommended Service See Note (2)
  • Page 11 Preventative Maintenance Kits Recommended upon detection of vapour, odour or taste - Maximum of 12 months Description Catalogue No. Contents Order Qty 015AC 015AC AC cartridge 015HC 015HC HC cartridge Recommended every 12 months Description Catalogue No. Contents Order Qty Exhaust Silencer 608200337 1/2”...
  • Page 12 Outlet Valve Kit Description Catalogue Number Contents Check valves Valve seats and guides Kit: Outlet Valve 608233674 Circlips Associated seals Exhaust Valve Kit Description Catalogue Number Contents 2/2 Isolator valve Exhaust barrel nipple Kit: Exhaust Valve DM012 - 040 608233677 elbow 1/8”...
  • Page 13 Replacing the Elements Ensure that the filter is isolated from the compressed air system and fully depressurised prior to carrying out any maintenance procedures which are to be done by qualified, trained authorised personnel only. Unscrew the filter bowls (1) and remove the used elements (2). Note.
  • Page 14 SUPPORT SERVICES Parker Support Services are the first port of call for customers in need of help or guidance. The fact that this team is responsible for the production of User Guides and Manuals gives you an insight into the level and detail of their parts and product knowledge.
  • Page 15 Declaration of Conformity Parker Hannifin Manufacturing Limited, domnick hunter Filtration and Separation Dukesway, TVTE, Gateshead, Tyne & Wear, NE11 0PZ. UK Breathing Air Purifier BAC-4015 Directives 97/23/EC Standards used Generally in accordance with ASMEVIII Div 1 : 2004. PED Assessment Route :...
  • Page 16 NOTES...
  • Page 17 NOTES...
  • Page 18 NOTES...
  • Page 20 (from AT, BE, CH, CZ, DE, EE, ES, FI, FR, IE, parker.fi nland@parker.com IL, IS, IT, LU, MT, NL, NO, PT, SE, SK, UK) © Parker Hannifin Corporation. All rights reserved. Catalogue: 176480300 Parker Hannifin Manufacturing Limited 11/13 Rev: -...
