NRS Healthcare NUVO User Instructions

S05883
General Safety Warning
Please make sure that you read and follow these
instructions carefully. Keep these instructions in
a safe place for future reference.
1. INTENDED USE
To assist those who have difficulty in lowering onto, or rising from a standard toilet. They can also be used
in conjunction with a raised toilet seat. An optional floor fixing kit is also available (P63989).
2. SAFETY
WARNING: The maximum user weight must not be
more than 190 kg (30 st).
MAKE SURE the floor surface is level and even to
avoid rocking.
MAKE SURE all legs are set at the same height to
avoid rocking.
DO NOT use if the rubber feet are damaged.
Inspect the product at regular intervals for signs of
wear or damage.
3. UNPACKING
Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
1
4
NUVO OPEN BACK TOILET FRAME
NUVO Open Back Toilet Frame
2
3
5
USER INSTRUCTIONS
3.1 Contents:
1. RH Side Frame Assembly x 1
2. LH Side Frame Assembly x 1
3. Connecting Crossbars x 2
4. E-clips x 8
5. Legs Extensions x 4
4. ASSEMBLY
4.1 Fitting the Connecting Crossbars
1. Connect the 2 x connecting crossbars to the
side frame assemblies and set to the correct
width for the toilet and user.
2. Align the holes and secure with the 4 x E-clips.
Note: Make sure that the side frames have been set
to the same width and the E-clips are fully secure.
1
Maximum User Weight
30st
190kg
