I n s t a l l a t i o n a n d M a n t a i n a n c e M a n u a l
Date 10/2019 Rev. 01
Antal srl
- Via del Progresso, 10 - 35127 Padova - Italy -
Tel. +39 049 8701265 / 8702655 - Fax: +39 049 760906 - antal@antal.it
X T W i n c h e s
MODELS
XT44/AL
XT44/CH
XT44R
XT48/AL
XT48/CH
XT48R
XT52/AL
XT52/CH
XT52/R
XT62/AL
XT62/CH
XT62R
www.antal.it

Advertisement

loading
Need help?

Need help?

Do you have a question about the XT44/AL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Antal XT44/AL

  • Page 1 MODELS XT44/AL XT44/CH XT44R XT48/AL XT48/CH XT48R XT52/AL XT52/CH XT52/R XT62/AL XT62/CH XT62R Antal srl www.antal.it - Via del Progresso, 10 - 35127 Padova - Italy - Tel. +39 049 8701265 / 8702655 - Fax: +39 049 760906 - antal@antal.it...
  • Page 2: Table Of Contents

    The present manual gives technical information for the installation and the maintenance of the following XT winch models: XT44/AL, XT44/CH, XT44R, XT48/AL, XT48/CH, XT48R, XT52/AL, XT52/CH, XT52R, XT62/AL, XT62/CH, XT62R In case of technical queries, contact antal@antal.it.
  • Page 3: About Xt Winches

    ABOUT XT WINCHES IMPORTANT CONCEPTS Power. Winches are distinguished by power values. The ratio between the force exerted on the handle and the power dispensed by the winch, is said power. For example: if a winch has power 66, it means that when I exert a force 1 on the handle, I get a power of recovery of 66 on the drum (theoretical value that disregards friction).
  • Page 4: Use

    INSTALLATION Installation is the responsibility of professional personnel. The installer must ensure the good state of the deck where the winch is to be installed. Antal assumes no responsibility for an incorrect installation of the winch. Warning: an incorrect installation of the winch may cause injuries or damages to things.
  • Page 5 Position of the winch on the deck. Before installing the winch you must choose a location on the deck that allows the maneuver which you intend to use, to reach the winch at an angle between 2 and 10 degrees. 2°...
  • Page 6 To install the winch, you will need: supplied key (K) for the opening of the upper ring (R), drill, sealant, screws, bolts and washers. Screws. Antal does not supply the anchoring screws needed to install the winch. The length of the screws depends on the thickness of the deck. Use screws, washers and bolts in stainless steel AISI 316.
  • Page 7 To determine the position of the holes, mark the deck using the winch’s skirt’s holes directly. Alternatively, you can download the drilling templates from the internet, at www.antal.it. Then drill the deck. order prevent water seepage, put sealant around the anchoring holes.
  • Page 8: Maintenance

    Antal Hydrolub Grease, it also protects the aluminum parts from galvanic corrosion, too. Thus we advise to put a thin layer of Antal Hydrolub Grease; not only to lubricate all moving parts, but also to protect the aluminum surfaces in contact with s.steel parts, e.g.
  • Page 9 The Antal Hydrolub Grease also serves the function of protection of the aluminum from the risk of galvanic corrosion.) Now, simply remove the center rod.
  • Page 10 For the dismantling of the gear section at the bottom of the center rod, proceed by removing parts of the exploded view drawing. Furthermore, open the gear section. The steel axels are isolated from the aluminum parts of the winch thanks to resin insulating gaskets shaped like a hat.
  • Page 11: Video And Warranty

    Much more information on the Series of Antal XT winches is available in this video. WARRANTY Antal guarantees its equipment to be free of defects in material and workmanship for 3 years from the date of purchase. During this period defective parts will be repaired or replaced by Antal.
  • Page 12 w w w . a n t a l . i t...
