Summary of Contents for Antal XT40EH
- Page 1 X T 4 8 E H X T 5 2 E H X T 6 2 E H Antal srl unipersonale, Via del Progresso, 10, 35127, Padova, Italy. Tel. +39 049 8701265. Fax: +39 049 760906. web: www.antal.it Technical service: antal@antal.it...
-
Page 2: Table Of Contents
Need the exploded view drawing of your XT Winch? Download the full Installation and maintenance manual from www.antal.it Contacts Antal srl unipersonale, Via del Progresso, 10, 35127, Padova, Italy. Tel. +39 049 8701265. Fax: +39 049 760906. web: www.antal.it Technical service: antal@antal.it... -
Page 3: Important Information
2 Speed Electrical XT winches and you are therefore advised to read it carefully before using the product. The present manual gives technical information for the installation and the maintenance of the following XT winch models: XT40EH, XT44EH, XT48EH, XT52EH, XT62EH. In case of technical queries, contact antal@antal.it. -
Page 4: Electric System
Installation and Maintenance XT40EH, XT44EH, XT48EH, XT52EH, XT62EH 2. Electric System Breaker The thermal switches indicated in the following table have dimensions calculated to break the circuit in case of exceptional overload; it is possible to consider thermal relays with a setting at a lower level. - Page 5 Installation and Maintenance XT40EH, XT44EH, XT48EH, XT52EH, XT62EH Electric System The electric system must be installed by specialised personnel, in compliance with the regulations in force; some general information is given below. For the electric diagram directions included in the control box should be consulted.
-
Page 6: Table Of Overall Dimensions
Installation and Maintenance XT40EH, XT44EH, XT48EH, XT52EH, XT62EH 3. Table of overall dimensions Deck Model Motor Speed - m/min Weight Screws Watt No. x Ø XT40EH 18.0 17.9 5 x 8 XT44EH 12.0 20.6 6 x 8 XT48EH 1000 22.4... -
Page 7: Installation
Ø=120 mm Fix the Motor: Thus, fix the flange F on the deck with 6 anchoring screws F3 from above (not supplied by Antal). Finally Install the Motor Unit screwing in the F2 screws. Motor Unit... - Page 8 Drill the deck (Ø = 120 mm) reduction-gear motor unit through. Fix the Motor: Thus, fix the flange F on the deck with 5 anchoring screws F3 from underneath (not supplied by Antal). Finally Install the Motor Unit screwing in the F2 screws. Motor Unit...
- Page 9 During assembly all the steel screws and washers must be generously greased to avoid corrosion phenomena in the areas in contact with aluminium parts. Antal supplies a special grease for marine applications: HDR in 150 gr packs. This product is an excellent lubricant and ensures lasting protection of...
-
Page 10: Maintenance Of The Winch
Antal Grease, it also protects the aluminum parts from galvanic corrosion, too. Thus we advise to put a thin layer of HDR Antal Grease; not only to lubricate all moving parts, but also to protect the aluminum surfaces in contact with s.steel parts, e.g. screws. -
Page 11: Warranty
XT40EH, XT44EH, XT48EH, XT52EH, XT62EH 6. Warranty Antal guarantees its equipment to be free of defects in material and workmanship for 3 years from the date of purchase. During this period defective parts will be repaired or replaced by Antal. Warranty does not cover: products incorrectly installed;...
