HS2LED/HS2ICON(P)(RF)X/HS2LCD(P)(RF)X V1.1
Installation Instructions
WARNING: Please refer to the System Installation Manual for information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer.
NOTE: These instructions shall be used in conjunction with the system Installation Manual of the Control Panel with which this equipment is intended to be used.
Advertisement
Table of Contents
Related Manuals for DSC HS2LCDPROE6
Summary of Contents for DSC HS2LCDPROE6
- Page 1 HS2LED/HS2ICON(P)(RF)X/HS2LCD(P)(RF)X V1.1 Installation Instructions WARNING: Please refer to the System Installation Manual for information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. NOTE: These instructions shall be used in conjunction with the system Installation Manual of the Control Panel with which this equipment is intended to be used.
-
Page 2: Specifications
Table 1: Compatible Devices Mount and Wire Keypad Introduction Wireless PG smoke detector PGx926UL The HS2LED/HS2ICN(P)(RF)x/HS2LCD(RF)(P)x keypads are Wireless PG smoke and heat detector PGx916UL compatible with the PowerSeries Neo HS2016/32/64, HS2016-4* Wireless PG CO detector PGx913 and HS2128 panels. The RF keypads combine a wireless trans- ceiver with the respective HS2 keypad. -
Page 3: Program The Keypad
09 = Finnish 19 = Hungarian 29 = Slovenian (such as DSC model RM-1 or RM-2) or buzzer or other DC oper- [902][101] Unenroll Keypads Enroll the Keypad ated device may be connected between the positive supply voltage 1. -
Page 4: Program Labels (Lcd Keypads)
2. Use the [<][>] keys to scroll to either Bright Control, Contrast Control, or Buzzer Control. Program Labels (LCD keypads) 3. Press [*] to select one of the following settings: 1. Press [*][8][Installer Code]. Brightness/LED Bar Control -15 backlighting levels available. 2. -
Page 5: Keypad Symbols
[011] Keypad Input/Output Programming [101]-[228] Door Chime for Zones Zone / PGM Number Default 000 |_____|_____|_____| Default: 01 |_____|_____| The keypad can be programmed to make up to four different chime sounds for individual zones. [012] Local PGM Output Pulse Activation Time (e.g., for Zone 1, enter section [101], for Zone 2 enter section [102]). -
Page 6: Proximity (Prox) Tags Support (Hs2Icnp/Hs2Icnrfp/Hs2Lcdp)
4. Scroll through the available selections, key in a number or enter text as appropriate. Proximity (Prox) Tags Support 5. Press [*] to accept and move to the next option. 6. Once all options are configured, the system prompts to enroll the next device. (HS2ICNP/HS2ICNRFP/HS2LCDP) 7. - Page 7 Table 8: Wireless Supervisory Window Options [804][901]-[905] Delete Wireless Devices Enabled/Disabled To delete wireless devices: After 1 Hour 1. Enter Installer Programming section [804] then select one of the following sub-sections: After 2 Hour Table 11: Module Label Sub-Sections After 4 Hour Sub-Section Description After 8 Hour...
-
Page 8: Troubleshooting
The device must be located where consistent “Good” results are obtained. If several devices [904] Placement Testing Wireless Devices (LCD keypads only) show “Poor” results, or if panic pendants and wireless keys operate inconsistently, move the This test is used to determine RF signal status for wireless devices and can be performed at a system receiver. -
Page 9: Word Library
Word Library Item # Text Item # Text Item # Text Item # Text Item # Text Item # Text Item # Text Aborted Closed Feature Library Pool Tamper Closet Fence Light Porch Temperature Access Closing Fire Lights Power Test Active Code First... - Page 10 The Model HS2LED, HS2LCD (P), HS2ICN (P), HS2LCDRF(P) 8, HS2ICNRF (P)8 Keypads have fication of any previous arrangement or contract. If You do not agree to the terms of this EULA, DSC is REQUIREMENTS OR THAT OPERATION OF THE SOFTWARE WILL BE been certified by Telefication according to EN50131-1:2006 + A1:2009, EN50131- 3:2009 for Grade 2, unwilling to license the Software Product to You, and You have no right to use it.
