E8
(EC/ECS/SC/SCS/INTC)
Instructions for Use
Additional online content
Tap, click or scan the QR code to access
additional online resources.
There are video tutorials to help you
operate your E8.
jura.com/support-E8C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Jura E8

  • Page 1 (EC/ECS/SC/SCS/INTC) Instructions for Use Additional online content Tap, click or scan the QR code to access additional online resources. There are video tutorials to help you operate your E8. jura.com/support-E8C...
  • Page 2: Table Of Contents

    Setting up the machine ........................................6 Filling the bean container........................................ 6 Determining the water hardness ....................................6 First-time use ............................................. 6 Managing your E8 – the JURA Cockpit ..................................8 Connecting milk ..........................................8 Establishing a Wi-Fi connection ..................................... 8 4 Preparation ......................................9 Preparation with preselection (Speciality Selection) ..............................
  • Page 3: Control Elements

    Drip tray Coffee grounds container Mains cable (permanently connected or plug-in) (back of the machine) Water tank Water tank cover Service socket for optional JURA Wi-Fi Connect Filler funnel for ground coffee (removable) Cover Grinder adjustment switch Container for milk system cleaning...
  • Page 4: For Your Safety

    Never use a damaged machine or mains cable. This could result in fatal electric shock. In the event of signs of damage, disconnect the machine from the mains. To do this, first switch the E8 off with the On/Off button Q . Only then should you remove the mains plug from the power socket.
  • Page 5: Preventing Damage

    Do not put the E8 or any individual parts in the dishwasher. Before cleaning, switch the E8 off with the On/Off button Q . Always wipe the E8 with a damp cloth rather than a wet one, and protect it from prolonged exposure to water splash. The E8 must not be cleaned with a jet of water.
  • Page 6: Preparing And Using For The First Time

    3 Preparing and using for the first time Setting up the machine Choose a spot for your E8 which protects the machine against overheating. Ensure that the ventilation slots are not covered. Place the E8 on a horizontal surface that is not sensitive to water.
  • Page 7 Empty the drip tray and put it back into the machine. Place one receptacle under the coffee spout and another under the fine foam frother. ‘Machine is heating’ ‘Machine is rinsing’ ‘Milk system is being rinsed’ The start screen is displayed. Your E8 is ready for use.
  • Page 8: Managing Your E8 - The Jura Cockpit

    The optionally available JURA ® Wi-Fi Connect is inserted into the service socket of your E8. (After the JURA Wi-Fi Connect has been inserted, the E8 must be switched off and then on again.)
  • Page 9: Preparation

    Coffee tastes best served hot. A cold porcelain cup cools the beverage – and impairs the taste. We therefore recommend prewarming the cups. You can purchase a JURA cup warmer from your specialised dealer. Preparation with preselection (Speciality Selection) Press the button to open the Speciality Selection.
  • Page 10: Latte Macchiato, Cappuccino And Other Speciality Coffees With Milk

    Americano and lungo For the americano and lungo, the E8 blends the coffee with hot water using a special preparation method. This results in a full-bodied spe- ciality coffee which is particularly easy to digest. You can change the amount of this additional water (see chapter 4 ‘Preparation – Adjust- ing the product settings’).
  • Page 11: Hot Water

    4 Preparation Open the cover behind the bean container. Add the desired amount of ground coffee to the filler funnel (max. 2 level measuring spoons). E The amount of ground coffee determines the intensity and aroma of the beverage, so you can adjust it to your personal preferences. Close the cover.
  • Page 12: Adjusting The Product Settings

    Press the On/Off button Q. ‘Machine is rinsing’ Your E8 is switched on or off. E When the machine is switched off, the system is only rinsed if a speciality coffee has been prepared. E If milk has been prepared before switching off, you will be prompted to carry out milk system cleaning (‘Clean the milk...
  • Page 13: Filling The Water Tank

    Remove the water tank and rinse it with cold water. Fill the water tank with fresh, cold water and reinsert the tank. Maintenance actions Optimal coffee quality depends on many factors. One important prerequisite is regular maintenance of your E8. Carry out the following steps: Maintenance action...
  • Page 14: Machine Settings

    In the Cockpit of your E8, maintenance programmes that need to be carried out are shown in the form of messages with red backgrounds. Press the button that corresponds to the message to go straight to the maintenance programme.
  • Page 15: Rinsing The Milk System

    Rinsing the milk system After each milk preparation, the E8 prompts you to perform a milk system rinse. In the machine settings, you can set whether the milk system rinsing is to be initiated manually or automatically 15 minutes after prepara- tion (see chapter ‘6 Machine settings’).
  • Page 16: Dismantling And Rinsing The Fine Foam Frother

    Rinse all the parts under running water. If there are severely dried-on milk residues, firstly immerse the individual parts in a solution of 250 ml water and one dosing unit of JURA milk system cleaner. Then rinse the individual parts thoroughly.
  • Page 17: Inserting/Changing The Filter

    YouTube Once the filter cartridge stops working (depending on the water hardness setting), the E8 will prompt you to change the filter. E Your E8 no longer has to be descaled if you are using the CLARIS Smart filter cartridge.
  • Page 18: Descaling The Machine

    Tap, click or scan to watch the video tutorial on YouTube The E8 builds up deposits of limescale over time and automatically prompts you to descale it when necessary. The degree of calcification depends on the hardness of your water.
  • Page 19 ‘Agent in tank’ Remove and empty the water tank. Completely dissolve 3 JURA descaling tablets in a receptacle holding 500 ml of water. This may take several minutes. Pour the solution into the empty water tank and insert it into the machine.
  • Page 20: Descaling The Water Tank

    If you use a CLARIS Smart filter cartridge, remove this. Completely fill the water tank and dissolve 3 JURA descaling tablets in it. Leave the water tank with the descaling solution for several hours (e.g. overnight). Empty the water tank and rinse it thoroughly.
  • Page 21: Transport And Environmentally Friendly Disposal

    Contact customer support in your country (see chapter ‘13 JURA contact details / Legal information’). E If you were unable to solve the problem, contact customer support in your country (see chapter ‘13 JURA contact details / Legal information’). 10 Transport and environmentally friendly disposal Transport / Emptying the system...
  • Page 22: Technical Data

    CLARIS filter cartridge Smart (RFID technology) Frequency band 13.56 MHz Max. transmission power < 1 mW JURA Wi-Fi Connect (Wi-Fi connection) Frequency band 2.4 GHz Max. transmission power < 100 mW JURA type Information for testers (repeat test in accordance with DIN VDE 0701-0702): The central grounding point (CGP) is located on the underside of the machine, right next to the mains cable’s connection point.
  • Page 23 Technical data 22 Ground coffee 10 Interchangeable milk spout 22 Interchangeable milk spout 22 Milk system 22 Tel 24 Transport 21 JURA Troubleshooting 20 Contact details 24 Use, first time 6 Latte macchiato 10 Users 4 Lungo 10 Water hardness...
  • Page 24: Jura Contact Details / Legal Information

    Technical changes We reserve the right to make technical changes. The diagrams used in these instructions for use are for illustration purposes only and do not represent the original colours of the machine. Some details of your E8 may vary. /en/20230926_BA-Online...
