StarTech.com DS52000 Quick Start Manual

5 Port 2.5G Unmanaged Multi-Gigabit Ethernet Switch
Product Diagram (DS52000)
Front Angle View
Rear Angle View
3
Side Angle View
5
Bottom Angle View
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
DS52000 o cerca il tuo prodotto tra le
1 2
4
6
migliori offerte di Switch
Port
1 Power LED • Green LED indicating Power is on
• Green LED Indicating Link Speed for the Ethernet
Port
2 Link Speed LEDs
• Connect the Ethernet Enabled Network Device to
3 Ethernet Ports
the Ethernet Switch
• Connect the Universal Power Adapter to the
4
DC Power Input
Ethernet Switch
5 • Connect a K-Slot Lock to the Ethernet Switch
K-Slot
6 Wall Mount Connectors • Connect the Wall Mounts to the Ethernet Switch
Product Information
For the latest product information, technical specifications, manuals, and Declarations
of Conformance please visit: www.StarTech.com/DS52000
Package Contents
• Ethernet Switch x 1
• Universal Power Adapter x 1
• Wall Mounting Kit x 1
• Quick-Start Guide x 1
Hardware Installation
Mounting the Ethernet Switch (optional)
1. Attach the Wall Mounts to the Ethernet Switch by matching the Keying on the
Wall Mounts to the Keying of the Wall Mount Connectors and slide the Wall
Mounts towards the center of the Ethernet Switch to lock the Wall Mounts in
place.
2. Mount the Ethernet Switch by screwing it to the Mounting Location using
Appropriate Screws (not included) for the Mounting Surface Material.
Connecting the Ethernet Switch
1. Connect the Ethernet Switch to a Power Outlet using the Universal Power
Adapter
2. Connect up to 5 Ethernet Enabled Network Devices to the Ethernet Switch using
Ethernet Cables (Cat5e or better).
StarTech.com
Quick-Start Guide
Function
Top Row - 10/100/1000Mbps Link Speed
•
• Bottom Row - 2.5Gbps Link Speed
Manual Revision: September 8, 2021
