StarTech.com DS16105 Spec Sheet

16 port desktop 10/100 fast ethernet switch

16 Port Desktop 10/100 Fast Ethernet Switch

StarTech ID: DS16105

Whether you need to mix 10Mbps and 100Mbps connections, or want to extend your network beyond your

current cabling length limitations, the StarTech.com full-duplex, 16-Port 10/100-Mbps Ethernet

switch will be an invaluable addition to your expanding network. Up to 16 Fast Ethernet hubs or

segments can be connected via RJ-45 ports and LED's for each port indicate network status at

a glance. The auto crossover feature allows you to cascade another switch from any port without the

need for a special crossover cable. This product replaces Switch DS16100, and Hubs 16PORT10BT, ED1516SX.

Applications and Solutions

> Connect 16 PCs at Full-Duplex 200Mbps speeds

> An easy way to expand your network by cascading from another backbone switch

> 2-year Warranty

> All RJ-45 ports support 10BaseT/100BaseTX and Full-Duplex/Half-Duplex Auto-negotiation function.

> Auto MDIX (crossover) function provides automatic crossover when cascading switches or

hubs - crossover cables or special uplink ports are no longer required

> Complies with IEEE 802.3 10BaseT Ethernet and 802.3u 100BaseTX Fast Ethernet standards

> IEEE 802.3x compliant flow control for full duplex and backpressure for half duplex

Table of Contents

Do you have a question about the DS16105 and is the answer not in the manual?

Page 1 StarTech.com full-duplex, 16-Port 10/100-Mbps Ethernet switch will be an invaluable addition to your expanding network. Up to 16 Fast Ethernet hubs or segments can be connected via RJ-45 ports and LED’s for each port indicate network status at a glance.
Page 2 > Simple and economical way to bridge 10BaseT and 100BaseTX networks and connect mixed speed devices > Sits on a desk/shelf or can be mounted on the wall. > Supports store-and-forward switching architecture Specifications > Auto MDIX Yes > Buffer Size 1 MB >...
