- Page 1 10/100 Fast Ethernet Dual Speed Hub Installation Manual DH5102E DH8100E DH16100E...
-
Page 2: Specifications
Introduction The StarTech.com Dual Speed Fast Ethernet desktop hubs are small in size but big in value. They provide 2 powerful modes of operation: dual speed mode, or extension mode. Extension mode allows the hub to cascade from up to 100m away, breaking the standard 10m hub distance limit of 100BaseT Ethernet. -
Page 3: Operating Humidity
8 port: 187 x 100 x 30 mm / 7.4 x 3.94 x 1.18 in. 16 port: 290 x 100 x 30 mm / 11.4 x 3.94 x 1.18 in. Weight: 5 port: 180g / 0.40lb. 8 port: 370g / 0.81lb. 16 port: 480g / 1.16lb. -
Page 4: Troubleshooting
2. Connect the other end of the cable to a numbered port on the hub (not to the uplink port). 3. Once the network cable is connected to both ends and the attached network device is powered on, the green LNK/ACT LED light should be lit.
