- Page 1 Model 4300 Digital Scale INSTRUCTION MANUAL DORAN SCALES, INC. 1315 PARAMOUNT PKWY. BATAVIA, IL. 60510 1-800-262-6844 FAX: (630) 879-0073 http://www.doranscales.com MANUAL REVISION: 4.0 MAN0166 12/26/2002 Made in USA...
-
Page 2: Table Of Contents
Table of Contents Table of Contents Introduction Unpacking Your Scale Quick Start User's Guide Fig. 1: Model 4300 Front Panel Layout Installation Electrical Connections Power Up Model 4300 Front Panel Button Operations ZERO UNITS PRINT OVER UNDER Basic Checkweighing Reference Guide Fig. -
Page 3: Print Buffer Address Menu
Motion Aperture Setup Menu Start Up Zero Setup Menu Latching Zero Request Setup Menu Latching Print Request Setup Menu Printer Data Output Setup Menu Output Formats Setup Menu Baud Rate Setup Menu Print Buffer Activation Menu Print Buffer Address Menu 1 Print Buffer Address Menu 2 Serial Data Handshaking Setup Menu Units Conversion Setup Menu... -
Page 4: Introduction
Introduction Introducing the Doran Scales, Inc. Model 4300 Digital Scale. This scale uses state of the art technology to provide you with a low cost solution to the most demanding weighing applications. With ease of use and setup in mind, the scale is simple to set up and ready to use. -
Page 5: Quick Start User's Guide
Quick Start User's Guide Fig. 1: Model 4300 Front Panel Layout INSTALLATION: The desired scale location should be flat, level and free of any obstructions, which might interfere with the operation of the scale platter. Remove the platter and locate the bubble level inside the base. Adjust the four scale feet so the bubble is centered and the platform is stable so it does not rock. -
Page 6: Model 4300
The 4300 is equipped with an optional "Zero on Demand" feature which holds "zero" requests until motion stops. This option may be activated during the scale setup procedure. Refer to the Parameter Setup section or your authorized Doran Scales dealer for details. UNITS button: The UNITS button allows the operator to change the scale units by pressing a button. -
Page 7: Print
The 4300 also has several automatic print options which may be used to simplify printer operation. These options may be activated during the scale setup procedure. Refer to the Parameter Setup section or your authorized Doran Scales dealer for details. OVER / UNDER button: The over and under buttons are used to enter the weight values needed for checkweighing applications. -
Page 8: Basic Checkweighing Reference Guide
Basic Checkweighing Reference Guide Fig. 1: Model 4300 Front Panel Layout Basic OVER, UNDER and ACCEPT Checkweighing Operation: 1) Remove all items from the scale platter. (If checkweighing to zero, place the target weight on the scale.) 2) Press ZERO to zero the scale. The weight indication should now be zero. 3) Place an item on scale platter and wait for the motion (MOT) indicator to turn off, indicating a stable weight. -
Page 9: Five Band Checkweighing Operation
Five Band Checkweighing Operation: (optional configuration)1 1) Remove all items from the scale platter. (If checkweighing to zero, place the target weight on the scale.) 2) Press ZERO to zero the scale. The weight display should now be zero. 3) Place an item on scale platter and wait for the motion (MOT) indicator to turn off, indicating a stable weight. -
Page 10: Quick Setup Guide
Quick Setup Guide Load Cell and Power Connections: Load cell connections are made through a connector (TB1) located at the bottom of the main PC Board (See Fig. 2). The power cord connects to a connector (J4) adjacent to the transformer. These connections are accessible by removing the rear cover. See the “Specifications and Interconnect Data”... -
Page 11: Capacity
CTS /RXD REMOTE SWITCH *GROUND Fig. 3: Serial Communications and Remote Push Button Connections *NOTE: Some 4300s have one less digital ground connection off the bottom Capacity: Capacity selection is performed by pressing and release the Calibration button (S1) to enter the calibrate mode. Press and release UNITS until "CAP 50"... -
Page 12: Calibration
Scales calibrated at 10% of capacity are more likely to have significant errors at full capacity than are scales calibrated at 25% or 50%. Doran Scales recommends that all scales be calibrated at full capacity whenever possible. 10% calibration should not be used when calibrating scales for legal for trade applications. -
Page 13: Analog Setup
Analog Setup: NOTE: Use this section only if you are curious about the load cell output. On scales with factory installed platforms, the zero and span will lie within permissible limits. There are no jumpers, pots, or switches to adjust. Raw counts are used to verify if a load cell will operate within specified limits. -
Page 14: Detailed Parameter Setup
Detailed Parameter Setup The Model 4300 has 26 setup and calibration parameters, which can be accessed through two setup modes. The Configuration mode will allow the user to change the scale configuration without accessing the scale calibration parameters or breaking the Weights and Measure seal. -
Page 15: Stepping Through The Menu Parameters
Stepping Through the Menu Parameters: Once the Calibration Setup Menu has been entered, you may step through the menus by pressing and releasing UNITS. A different display prompt will appear for each parameter in the menu. The parameter list on the following pages corresponds to the parameters available in the Calibration Setup Menu. -
Page 16: Setup Menus Explained (In Order Of Occurrence)
Setup Menus Explained (In order of occurrence) Capacity Setup Menu Capacity Select Menu Allows the selection of scale capacity. 5 pounds 6 pounds 10 pounds 15 pounds 2, 3 20 pounds 25 pounds 30 pounds 50 pounds 60 pounds 100 pounds 150 pounds 2, 3 200 pounds... -
Page 17: Calibration Menu
NOTE: "XXXXXX" will be the dialed in weight value. * NOTE: For maximum accuracy, Doran Scales recommends that all scales be calibrated at full capacity. When location or installation make it difficult to bring full capacity weights to the scale, calibration with as little 10% of capacity is possible. -
Page 18: Digital Filter Setup Menu
Digital Filter Setup Menu Averaging mode Determines the number of samples to average Stabil-izer auto averaging. All readings are © averaged. Display updates 10 times a second. Stabil-izer auto averaging. All readings are © averaged. Display updates 9 times a second. Stabil-izer auto averaging. -
Page 19: Motion Aperture Setup Menu
Motion Aperture Setup Menu m.A. * Motion aperture * Determines how many divisions consecutive readings must change before the scale is considered to be in motion. 1 division change must be seen to enter motion. 3 division change must be seen to enter motion. 5 division change must be seen to enter motion. -
Page 20: Printer Data Output Setup Menu
Printer Data Output Setup Menu ‡ d.o. Data Output Mode Determines when serial data will be sent. t.o.d. Transmit on demand. Print when the PRINT button is pressed. C.P. Continuous Print. Print when display is updated. A.P.1 Auto Print 1. Print once only when scale goes stable. A.P.2 Auto Print 2. -
Page 21: Print Buffer Activation Menu
Print Buffer Activation Menu ‡ bUF **** Buffer Status Enable or disable print buffer. (RS232 commands change when active.) (RAM needed) Buffer in on. Printer data is printed to memory. Buffer is dumped with the dump command Buffer is off. Print Buffer Address Menu 1 ‡... -
Page 22: Units Conversion Setup Menu
Units Conversion Setup Menu ‡ Convert Select Modes Determines which unit selections will be active. CA * Convert All. lb, kg, g, oz and lb-oz are active. lb, kg, g and oz are active. lb and kg are active. lb and oz are active. g and oz are active. -
Page 23: Remote Push-Button Configuration Menu
Remote Push-button Configuration Menu ‡ r.P.b. Remote Push Button Configures the remote switch to perform one of the three front panel functions. The remote switch is disabled. The remote switch functions as a PRINT button. The remote switch functions as a UNITS button. The remote switch functions as a ZERO button. -
Page 24: Legal For Trade Setup Menu
Precision mode (5000d typ.) Super precision mode (10,000d typ.) NOTE: For maximum accuracy, Doran Scales recommends that all scales be calibrated at full capacity. When location or installation make it difficult to bring full capacity weights to the scale, calibration with as little as 10% of capacity is possible. -
Page 25: Raw Counts Display Mode
Raw Counts Display Mode Displays the raw Analog to Digital converter Counts data. Press ZERO to exit Raw Counts. The raw counts utilizes the filter selected in the AVG set up menu. Configuration Mode Exit Menu ‡‡ donE Exit Configuration Menu. Do not exit menu. -
Page 26: Data Communications
Data Communications Introduction to Data Communications: In the Model 4300 data is sent to a printer or computer by using "asynchronous serial data communications." Data is broken up and sent one piece at a time to the printer or computer. In spite of this apparent simplicity, a basic understanding of serial data communications is needed when setting up the scale. -
Page 27: Rs485
stop bit signals the end of the data and permits the bit timer a chance to reset itself before the next data byte is sent. No parity bits are sent. In many cases, the receiving unit is a slow printer with limited memory. In these cases, more data may be sent than the printer can use. -
Page 28: Printer Modes
NOTE: When installing a 4300 on a RS485 system, it may be necessary to use termination resistors. The 4300 has three termination resistors built in the main board. Consult your authorized Doran Scales dealer or the factory for more details. -
Page 29: Data Output Format
Data Output Format: In order for the serial data sent from the scale to be useful, the data must be organized so that it is easy to read. To accomplish this, the scale arranges the displayed data with additional text to indicate the active units and to indicate the presence of motion during the reading. - Page 30 Command Scale output Response (TXD) Description (RXD) <STX><xxxx.xx><SP><uu><SP><MOT><LF><CR> “_ ” standard format, Prints current weight (hex 57) and units. <STX><xxxx.xx><SP><uu><SP><AUO><SP><MOT><L “_ ” enhanced format, Prints current weight F><CR> and units with Accept, Under, Over status. “_ ” dual print format, Prints current and kg <STX><xxxx.xx><SP><uu><SP><MOT><LF><CR>...
-
Page 31: Specifications And Interconnect Data
Specifications and Interconnect Data Specifications: Model 4300 Resolution: 10,000d in super precision mode Sensitivity: 0.5 µV min. Load Cell Capacity: 0.5 mV/V to 3.5mV/V Power Supply: 115/230 VAC 50/60 Hz Display: 6 digit LED. 0.56" high Displayed units: lb, kg, oz, g, and lb-oz Capacities: 5lb to 100,000lb Printer Interface:... - Page 32 PIN # TITLE CTS for Hardware Handshaking RTX for Software Handshaking Remote Switch High Remote Switch & RS232 Ground Table 4: Options Connections (P3) PIN # TITLE (G) Ground (N) Neutral Table 5: Power Connections (J4) PIN # TITLE Zero Switch Ground Zero Switch High Units Switch Print Switch...
- Page 33 Serial Cable Assembly DB25 Female connector w/ Software Handshaking Function Wire Color White Signal GND Black DB9 Female Connector w/ Software Handshaking White Signal GND Black Table 7: Serial Cable assembly with Software Handshaking Serial Cable Assembly DB25 Female connector w/ hardware handshaking Function Wire Color...
- Page 34 Fig. 4: Installation of EMI / RFI / ESD protection devices.
-
Page 35: Troubleshooting
Averaging to a higher setting to stabilize the reading (see Section "Setup Menus Explained). If you are still experiencing a problem with your scale, or if the problem you are having is not covered in the above list, please contact your Doran Scales authorized dealer. -
Page 36: Resetting The Scale Parameters
Resetting the Scale Parameters: - If at some point the Model 4300, user wishes to return the setup parameters to factory default, follow these steps. WARNING: Defaulting the scale will require recalibration. - Remove power. - Press and hold CAL button (S1) while power is restored. - The indicator will display "init"... -
Page 37: Scale And Error Messages
Scale Messages: Message Meaning "donE" The scale has successfully completed the Function complete. requested action. "Abort" The requested action has been canceled prior to Aborted Function. completion. "SAVEd" The scale has successfully store and verified Parameter value saved. parameter value in nonvolatile memory. "Ent. - Page 38 "Er Ad" A/D failure The scale has detected a failure in A/D circuit. Have scale serviced by a qualified scale repair technician. "Err EP" EEPROM error Calibration data and parameter data are corrupted. Reset parameters and recalibrate. "Er CAL" Calibration error Calibration data corrupted.
-
Page 39: Limited Warranty Statement
LIMITED WARRANTY STATEMENT DORAN SCALES, INC. warrants its products to be free from defects in material and workmanship for a period of two (2) years from date of shipment. Any product found to be defective within this time period may be returned to DORAN’s factory, freight prepaid, with prior return...
