INSTRUCTION MANUAL
OIL-FREE SCROLL TANK MOUNT AIR
COMPRESSOR
SLT-2/3/5/10D
SLT-2H/3H/5H/10DH
SLT-2/3/5/10D-FM
SLT-2H/3H/5H/10DH-FM
SLT-5-FRD
Thank you for purchasing our oil-free scroll air compressor.
●Before operation, be sure to read this instruction manual thoroughly for safe
and efficient use for a long operating lifetime.
●After reading it, store in a convenient place for immediate and future
reading.
Before use, be sure to fill in the blank spaces below for future repair and after service.
MODEL
SERIAL No.
Purchased from
Date of purchase
Date of use
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Anest Iwata SLT-2D
Summary of Contents for Anest Iwata SLT-2D
- Page 1 INSTRUCTION MANUAL OIL-FREE SCROLL TANK MOUNT AIR COMPRESSOR SLT-2/3/5/10D SLT-2H/3H/5H/10DH SLT-2/3/5/10D-FM SLT-2H/3H/5H/10DH-FM SLT-5-FRD Thank you for purchasing our oil-free scroll air compressor. ●Before operation, be sure to read this instruction manual thoroughly for safe and efficient use for a long operating lifetime. ●After reading it, store in a convenient place for immediate and future reading.
-
Page 2: Important Information-Safety Precautions
Important information-Safety precautions ▪ Important information Be sure to read and understand this instruction manual. The operator shall be fully conversant with the requirements stated within this instruction manual including important warnings, cautions and operation. The marks and symbols have the following meanings. Keep this booklet in an appropriate place for immediate reference. -
Page 3: Safety Precautions
Important information-Safety precautions ▪ Safety precautions WARNING Install in a safe area. Install in an area which is free of volatile, flammable gases or organic solvents. They can cause explosion or fire. Never install outdoors. Do not install outdoors (This compressor is not water-proof) If water splashes on electric equipment, it can cause electric shock or fire. - Page 4 Important information-Safety precautions WARNING Never use with equipment which is directly concerned with human life. If done, it can cause serious bodily injury. Never touch Never touch turning parts (fan, pulley and belts) while main electric source is turned on. If done, it can cause serious injury including entanglement of fingers or hands.
- Page 5 Important information-Safety precautions CAUTION Use at ambient temperature of 36 degree F to 104 degree F Drain will freeze at less than 36 degree F and cause failure. More than 104 degree F will cause shorter lifetime or damage to unit. Use in an area which is free of dirt or dust.
-
Page 6: Table Of Contents
Contents Important information-Safety precautions Appendix ▪ Important information ------------------------------1 ▪ Outer dimensions ------------------------------------------- 23 ▪ Safety precautions------------------------------------2 ▪ Circuit diagram -----------------------------------------------26 Contents Warranty ▪ Contents ------------------------------------------------5 ▪ Warranty and remedies -----------------------------------30 Before use ▪ Inspect the product ----------------------------------6 Installation ▪ Precautions about installation ----------------------7 ▪... -
Page 7: Before Use
Before use ▪ Inspect the product • Check that model name of the product is as you ordered. Model name description; • Check that there is no deformity or damage which occurred during shipment. Any shipping damage must be immediately filed with the freight carrier. •... -
Page 8: Installation
Installation ▪ Precautions about installation WARNING Do not use in an area which is exposed to rain, steam or high humidity. High Humidity can cause electric shock or fire. Do not install in an area with corrosive gas (ammonia, acid, salinity, ozone gas and sulfur dioxide). If done, it can cause shorter lifespan. -
Page 9: Piping
Installation • Installation space Secure the space around compressor for safe, inspection and maintenance. Installation space (inch) Above Each Side • Ventilation When using in totally closed room, install fan for ventilation. British Thermal Unit Model (BTU) SLT-2**-*** 5120 SLT-3*-*** 7680 SLT-5*-*** 12800... -
Page 10: Electrical Wiring
Installation ▪ Electrical wiring • Precautions about wiring Turn off main electric source. Be sure to turn off main electric source before inspection or wiring job. If not, it can cause electric shock or serious bodily injury. Ask qualified electrician. Ask qualified electrician to perform electric wiring job. - Page 11 Installation o 208V-230V/460V, 3PH, 60Hz Motor Motor Non-time Time Delay Inverse-time Power Size Load Delay Fuse Fuse circuit breaker (V/PH) (HP) (FLA) 208/3 230/3 460/3 208/3 10.6 230/3 460/3 208/3 16.7 230/3 15.2 460/3 208/3 33.4 10 (5HP x 2) 230/3 30.4 460/3...
-
Page 12: Operation
Operation ▪ Before start up • Make sure all safety warnings, labels, and instructions have been read and understood before continuing. • Make sure any shipping materials, brackets, etc. are removed. • Check that the electric power source and ground have been firmly connected. •... - Page 13 Operation • Check the discharge pressure. Also make sure the compressor stops at the setting pressure as below. Model Cut-out pressure (psi) SLT-2*, 3 and 5-*** Lead pump SLT-10D-** Second pump SLT-2*H, 3H and 5H-*** Lead pump SLT-10DH-** Second pump •...
-
Page 14: Maintenance
Maintenance Following maintenance is required at certain interval. These intervals are based on condition where ambient temperature is around 86 degree F. If your location is warmer or running condition is more sever, maintain within a shorter period. If warmer shorten the period approx. 30% from our recommendation at every 9 degree F. Standard maintenance period is not our warranty period. - Page 15 Maintenance • For 145psi models (SLT-2*H,3H,5H and 10DH-***) Maintenance is to be done according to operating hours or period whichever comes first. Maintenance period (every hours or period) Every Every Every Every Every 5,000 Item Detail Every 2,500 10,000 15,000 20,000 Daily Every 2...
- Page 16 Inspect with eyes. Record and keep the results of maintenance until disposal and transfer of the product. Request repairing promptly when oil leakage is discovered from refrigerating compressor. Repairing request inform authorized distributor by ANEST IWATA Air Engineering, Inc. • Replace the mainline filter, final filter and membrane dryer. (-FRD*).
-
Page 17: How To Carry Out Maintenance
Maintenance ▪ How to carry out maintenance • Intake filter Blow dust off of it with air gun and replace if it is too dirty. • Safety valve Lift up stem of safety valve at around max pressure and check if air blows out. •... -
Page 18: Troubleshooting Guide
Troubleshooting guide If you have any problems, please refer to the below chart. As * marked items are difficult for you to remedy, please contact the shop you have purchased it from. ▪ Compressor Problem Cause Corrective action Electric source is not ON. Turn on electric source Compressor unit does Electric source is not connected... -
Page 19: Specifications
Specifications ▪ Compressor specifications • 2HP Item SLT-2-30 SLT-2-60 SLT-2-80 SLT-2H-30 SLT-2H-60 SLT-2H-80 Operating pressure 85 – 115 115 - 145 Air delivery (*1) Tank size Noise level (*2) dB(A) Air outlet NPT 1/2” (1Phase, 115/208-230V, 60Hz) Operating voltage 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*3) In. - Page 20 Specifications • 3HP Item SLT-3-30 SLT-3-60 SLT-3-80 SLT-3H-30 SLT-3H-60 SLT-3H-80 Operating pressure 85 - 115 115 - 145 Air delivery (*1) Tank size Noise level (*2) dB(A) Air outlet NPT 1/2” Operating voltage 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*3) In. 42 x 29 x 38 49 x 29 x 44 64 x 29 x 44 42 x 29 x 38 49 x 29 x 44 64 x 29 x 44 Approx.
- Page 21 Specifications • 5HP Item SLT-5-30 SLT-5-60 SLT-5-80 SLT-5H-30 SLT-5H-60 SLT-5H-80 Operating pressure 85 - 115 115 - 145 Air delivery (*1) 14.8 11.7 Tank size Noise level (*2) dB(A) Air outlet NPT 1/2” Operating voltage 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*3) In. 42 x 29 x 38 49 x 29 x 44 64 x 29 x 44 42 x 29 x 38 49 x 29 x 44 64 x 29 x 44 Approx.
- Page 22 Specifications • 10HP Item SLT-10D SLT-10DH 85 - 115 (Lead pump) 115 - 145 (Lead pump) Operating pressure 75 - 105 (Second pump) 105 - 135 (Second pump) Air delivery (*1) 29.6 23.4 Tank size Noise level (*2) dB(A) Air outlet NPT 3/4”...
- Page 23 Specifications • 5HP with Refrigerated Dryer Item SLT-5-FRD Operating pressure 85-115 Air delivery (*1) 14.8 Tank size Noise level (*2) dB(A) Air outlet NPT 1/2” Operating voltage 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*3) 68 x 32 x 47 Approx. mass Lbs.
-
Page 24: Appendix
Appendix ▪ Outer dimensions • SLT-2-30, SLT-3 and SLT-5-30, (SLT-2H-30, SLT-3H-30 and SLT-5H-30) • SLT-2-FM-30, SLT-3*-FM-30 and SLT-5*-FM-30, (SLT-2H-FM-30, SLT-3H-FM-30 and SLT-5H-FM-30) - Page 25 Appendix • SLT-5-FRD-60 • SLT-10D and SLT-10DH...
- Page 26 Appendix • SLT-10D and SLT-10DH...
-
Page 27: Circuit Diagram
Appendix ▪ Circuit diagram • SLT-2(H)-S115... - Page 28 Appendix ▪ Circuit diagram • SLT-2(H)/3(H)/5(H)-S208/230...
- Page 29 Appendix • SLT- 2(H) / 3(H) / 5(H) – T208/230/460...
- Page 30 Appendix • SLT - 10D(H) – T208/230/460...
-
Page 31: Warranty
Anest Iwata Air Engineering, or such claim shall be barred. Upon timely receipt of a claim, Anest Iwata Air Engineering shall inspect the product claimed to have a defect, and Anest Iwata Air Engineering shall repair, or, at its option, replace, free of charge, any product which it determines to have had a defect at the time of shipment from Anest Iwata Air Engineering;... - Page 32 ANEST IWATA AIR ENGINEERING, Inc. www.anestiwata.com inquiry@anestiwata.com Toll Free (800)440-0282 No. SLT10D-99 rev 5.0...
