INSTRUCTION MANUAL
OIL-FREE SCROLL BASE MOUNT
ENCLOSURE AIR COMPRESSOR
SLBE-2/3/5
SLBE-2H/3H/5H
Thank you for purchasing our oil-free scroll air compressor.
●Before operation, be sure to read this instruction manual thoroughly for safe
and efficient use for a long operating lifetime.
●After reading it, store in a convenient place for immediate and future
reading.
Before use, be sure to fill in the blank spaces below for future repair and after service.
MODEL
SERIAL No.
Purchased from
Date of purchase
Date of use
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Anest Iwata SLBE-2
Summary of Contents for Anest Iwata SLBE-2
- Page 1 INSTRUCTION MANUAL OIL-FREE SCROLL BASE MOUNT ENCLOSURE AIR COMPRESSOR SLBE-2/3/5 SLBE-2H/3H/5H Thank you for purchasing our oil-free scroll air compressor. ●Before operation, be sure to read this instruction manual thoroughly for safe and efficient use for a long operating lifetime.
-
Page 2: Important Information-Safety Precautions
Important information-Safety precautions ▪ Important information Be sure to read and understand this instruction manual. The operator shall be fully conversant with the requirements stated within this instruction manual including important warnings, cautions and operation. The marks and symbols have the following meanings. Keep this booklet in an appropriate place for immediate reference. -
Page 3: Safety Precautions
Important information - Safety precautions ▪ Safety precautions WARNING Install in a safe area. Install in an area which is free of volatile, flammable gases or organic solvents. They can cause explosion or fire. Never install outdoors. Do not install outdoors (This compressor is not water-proof) If water splashes on electric equipment, it can cause electric shock or fire. - Page 4 Important information - Safety precautions WARNING Never use with equipment which is directly concerned with human life. If done, it can cause serious bodily injury. Never touch Never touch turning section (fan, pulley and belts) while main electric source is turned on. If done, it can cause serious injury including entanglement of fingers or hands.
- Page 5 Important information - Safety precautions CAUTION Use at ambient temperature of 36 degree F to 104 degree F (during operation) Drain will freeze at less than 36 degree F and cause failure. More than 104 degree F will cause shorter lifetime or damage. Use at an area which is free of dirt or dust.
-
Page 6: Table Of Contents
Contents Important information-Safety precautions Appendix ▪ Important information ------------------------------1 ▪ Outer dimensions -------------------------------------------18 ▪ Safety precautions------------------------------------2 ▪ Circuit diagram -----------------------------------------------19 Contents Warranty ▪ Contents ------------------------------------------------5 ▪ Warranty and remedies -----------------------------------22 Before use ▪ Check the product -----------------------------------6 Installation ▪ Precaution about installation ------------------------7 ▪... -
Page 7: Before Use
Before use ▪ Inspect the product • Check that model name of the product is as you ordered. Model name description; Scroll 208; 208V 230; 230V Base mount 460; 460V Enclosure Single phase Three phase N/A; 115psi (Maximum pressure) 145psi (Maximum pressure) •... -
Page 8: Installation
Installation ▪ Precautions about installation WARNING Do not use in an area which is exposed to rain, steam or high humidity. High Humidity can cause electric shock or fire. Do not install in an area with corrosive gas (ammonia, acid, salinity, ozone gas and sulfur dioxide). If done, it can cause shorter lifetime. -
Page 9: Piping
24 inches Each Side 20 inches • Ventilation When using in totally closed room, install fan for ventilation. British Thermal Unit Model SLBE-2** 5160 SLBE-3* 7570 SLBE-5* 12730 ▪ Piping • Do not use any steel pipe and a smaller size than the compressor outlet connection. -
Page 10: Electrical Wiring
Installation ▪ Electrical wiring • Precautions about wiring Turn off main electric source. Be sure to turn off main electric source before inspection or wiring job. If not, it can cause electric shock or serious bodily injury. Ask qualified electrician. Ask qualified electrician to perform electric wiring job. - Page 11 Installation o 208V-230V/460V, 3PH, 60Hz Motor Motor Non-time Time Delay Inverse-time Power Size Load Delay Fuse Fuse circuit breaker V/PH 208V/3PH 230V/3PH 460V/3PH 208V/3PH 10.6 230V/3PH 460V/3PH 208V/3PH 16.7 230V/3PH 15.2 460V/3PH...
-
Page 12: Operation
Operation ▪ Before start up • Make sure all safety warnings, labels, and instructions have been read and understood before continuing. • Make sure any shipping materials, brackets, etc. are removed. • Check that the electric power source and ground have been firmly connected. •... - Page 13 • Check the discharge pressure. Also make sure the compressor stops at the setting pressure as below. Model Cut-out pressure (psi) SLBE-2, SLBE-3, SLBE-5 SLBE-2H, SLBE-3H, SLBE-5H • Check the discharge pressure. Also make sure the compressor starts as pressure drops.
-
Page 14: Maintenance Standards
If warmer shorten the period approx. 30% from our recommendation at every 9 degree F. Standard maintenance period is not our warranty period. ▪ Standard maintenance period • For 115psi models (SLBE-2*, SLBE-3 and SLBE-5) Maintenance is to be done according to operating hours or period whichever comes first. Maintenance period (every hours or periods) - Page 15 Maintenance • For 145psi models (SLBE-2*H, SLBE-3H and SLBE-5H) Maintenance is to be done according to operating hours or period whichever comes first. Maintenance period (every hours or period) Every Every Every Every Every Item Detail 5,000 10,000 20,000 30,000...
-
Page 16: How To Carry Out Maintenance
An exclusive tool is necessary to measure belt tension. Ask our distributor to readjust belt tension when you need to readjust it. Readjustment Replacement new belt Readjustment Model target load / Hz target load / Hz standard load / Hz Tolerance ±5 Tolerance ±5 SLBE-2* SLBE-3* SLBE-5*... -
Page 17: Troubleshooting Guide
Troubleshooting guide If you have any problems, please refer to the below chart and remedy it. As * marked items are difficult for you to remedy, please contact the shop you have purchased it from. ▪ Compressor Problem Cause Corrective action Electric source is not ON. -
Page 18: Specifications
Specifications ▪ Compressor specifications • 2HP Item SLBE-2 SLBE-2H Max. discharge pressure Air delivery (*1) Air outlet NPT 1/2” Operating voltage (1Phase, 115/208-230V, 60Hz) 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*2) 43 x 22 x 21 43 x 22 x 21 Approx. -
Page 19: Appendix
Appendix ▪ Outer dimensions • SLBE-2**, SLBE-3* and SLBE-5*... -
Page 20: Circuit Diagram
Appendix ▪ Circuit diagram • SLBE-2-S115 and SLBE-2H-S115... - Page 21 Appendix • SLBE-2-S208-230, SLBE-3-S208-230 and SLBE-5-S208-230...
- Page 22 Appendix • SLBE-2-T208-230/460, SLBE-3-T208-230/460 and SLBE-5-T208-230/460...
-
Page 23: Warranty
Anest Iwata Air Engineering, or such claim shall be barred. Upon timely receipt of a claim, Anest Iwata Air Engineering shall inspect the product claimed to have a defect, and Anest Iwata Air Engineering shall repair, or, at its option, replace, free of charge, any product which it determines to have had a defect at the time of shipment from Anest Iwata Air Engineering;... - Page 24 ANEST IWATA AIR ENGINEERING, Inc. www.anestiwata.com inquiry@anestiwata.com Toll Free (800)440-0282 No.SLBE5-99 _rev3.0...
