INSTRUCTION MANUAL
OIL-FREE SCROLL TANK MOUNT
ENCLOSURE AIR COMPRESSOR
SLTE-7.5/10/15D/20D
SLTE-7.5/10-FM
Thank you for purchasing our oil-free scroll air compressor.
●Before operation, be sure to read this instruction manual thoroughly for safe
and efficient use for a long operating lifetime.
●After reading it, store in a convenient place for immediate and future
reading.
Before use, be sure to fill in the blank spaces below for future repair and after service.
MODEL
SERIAL No.
Purchased from
Date of purchase
Date of use
Advertisement
Table of Contents
Related Manuals for Anest Iwata SLTE-7.5
Summary of Contents for Anest Iwata SLTE-7.5
- Page 1 INSTRUCTION MANUAL OIL-FREE SCROLL TANK MOUNT ENCLOSURE AIR COMPRESSOR SLTE-7.5/10/15D/20D SLTE-7.5/10-FM Thank you for purchasing our oil-free scroll air compressor. ●Before operation, be sure to read this instruction manual thoroughly for safe and efficient use for a long operating lifetime.
-
Page 2: Important Information And Safety Precautions
Important information and Safety precautions ▪ Important information Read all important information and safety precautions before use. The operator shall be fully knowledgeable of the requirements stated within this instruction manual, including important warnings, cautions and operation. Read manual before performing any maintenance. Keep this booklet in an appropriate place for immediate reference. -
Page 3: Safety Precautions
Important information and Safety precautions ▪ Safety precautions WARNING Install in a safe area. To prevent a fire or explosion, install in an area free of flammable gases or organic solvents. Never install outdoors. To prevent fire or electric shock, never install outdoors. Turn off the main electric source. - Page 4 Important information and Safety precautions WARNING Not for use as life support. Serious bodily injury and/or death may occur. Unit must only be used to compress air. Do not touch. Keep hands and fingers away from fans, pulleys and belts while the power is on. Serious injury, including entanglement of fingers or hands can occur.
- Page 5 Important information and Safety precautions CAUTION Use at ambient temperatures of 36°F to 104°F. Drain will freeze at less than 36°F and will cause unit failure. Using over 104°F will cause a shorter lifespan or unit damage. Use in an area free of dirt and dust. Failure to do so may result in equipment failure.
-
Page 6: Table Of Contents
Contents Important information and Safety precautions ■Important information ----------------------------- ■Safety precautions ---------------------------------- ■Contents ----------------------------------------------- Before use ■Inspect the product --------------------------------- Installation ■Precaution about installation ----------------------- ■Piping --------------------------------------------------- ■Electrical wiring -------------------------------------- Operation ■Before start up ---------------------------------------- ■Start-up and operation --------------------------------- Maintenance ■Standard maintenance period ------------------------ ■How to carry out maintenance ----------------------- Troubleshooting Guide... -
Page 7: Before Use
Before use ▪ Inspect the product • Inspect the product to be sure you have the model you ordered. Scroll 80GAL Tank 208; 208V 120; 120GAL Tank 230; 230V Tank mount (Duplex only) 460; 460V Enclosure N/A; Without filter & membrane dryer Three phase With filter &... -
Page 8: Installation
Installation ▪ Precautions about installation WARNING! Do not use in an area which is exposed to rain, steam or high humidity. High humidity can cause electric shock or fire. Do not install in an area with corrosive gas (ammonia, acid, salinity, ozone gas and sulfur dioxide) preventing a shorter lifespan of the unit. -
Page 9: Piping
Installation space (inch) Above Other Sides • Ventilation When using in an enclosed closed room, install a fan for ventilation. British Thermal Unit Model (BTU) SLTE-7.5/SLT-7.5-FM 19,200 SLTE-10/SLT-10-FM 25,600 SLTE-15D 38,400 SLTE-20D 51,200 ▪ Piping • Do not use a steel pipe or smaller size than the compressor outlet connection. -
Page 10: Electrical Wiring
Installation ▪ Electrical wiring • Precautions about wiring Turn off main electric source. Be sure to turn off main electric source before inspection or wiring job. If not, it can cause electric shock or serious bodily injury. Ask qualified electrician. Ask qualified electrician to perform electric wiring job. - Page 11 Installation • Wiring Be sure to use the fork, pin or blade terminal to firmly connect the electric source to the designated place of the magnetic switch or terminal in the control box. Please refer to the circuit diagram shown in the Appendix. o 208V-230V/460V, 3PH, 60Hz Inverse-time Motor...
-
Page 12: Operation
Operation ▪ Before start up: • Make sure all safety warning labels and instructions have been read and understood before continuing. • Make sure any shipping materials and brackets are removed. • Be sure the electric power source has been firmly connected and grounded. •... - Page 13 Operation • Check the discharge pressure. Be sure the compressor stops at the setting pressure indicated below. Model Cut-out pressure (psi) SLTE-7.5 SLTE-10 SLTE-7.5-FM SLTE-10-FM SLTE-15D Lead pump SLTE-20D Second pump • Check the discharge pressure. Be sure the compressor starts at the setting pressure indicated below.
-
Page 14: Maintenance
Standard maintenance period is not our warranty period. ▪ Standard maintenance period • For 115psi models (SLTE-7.5, SLTE-10, SLTE-15D and SLTE-20D) Maintenance is to be done according to operating hours, or period, whichever comes first. Maintenance period (every hours or periods) -
Page 15: How To Carry Out Maintenance
An exclusive tool is necessary to measure belt tension. Ask our distributor to readjust belt tension when needed. Readjustment Replacement new belt Readjustment Model target load / Hz target load / Hz standard load / Hz Tolerance ±5 Tolerance ±5 SLTE-7.5 SLTE-7.5-FM SLTE-15D SLTE-10 SLTE-10-FM SLTE-20D... -
Page 16: Troubleshooting Guide
Troubleshooting Guide If you have any problems, please refer to the chart below. If the (*) marked items are difficult for you to fix, please contact the shop you purchased it from. ▪ Compressor Problem Cause Corrective action Electric source is not ON. Turn on electric source Compressor unit does Electric source is not connected... -
Page 17: Specifications
Specifications ▪ Compressor specifications • 7.5 / 10HP Item SLTE-7.5-80 SLTE-10-80 Operating pressure 85 - 115 Air delivery (*1) 22.6 29.7 Tank size Noise level (*2) dB(A) Air outlet NPT 3/4” Operating voltage 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*3) 64 x 29 x 49 Approx. - Page 18 Specifications • 15 / 20HP Item SLTE-15D-120 SLTE-20D-120 85 - 115 (Lead pump) Operating pressure 75 - 105 (Second pump) Air delivery (*1) 45.2 59.4 Tank size Noise level (*2) dB(A) Air outlet NPT 1” Operating voltage 3Phase, 208-230/460V, 60Hz Dimensions (L×W×H) (*3) 70 x 43 x 52 Approx.
-
Page 19: Appendix
Appendix ▪ Outer dimensions • SLTE-7.5/10-80 • SLTE-7.5/10-FM-80... - Page 20 Appendix ▪ Outer dimensions • SLTE-15D/20D-120...
-
Page 21: Circuit Diagram
Appendix ▪ Circuit diagram • SLTE-7.5 / SLTE-10... - Page 22 Appendix • SLTE-15D / SLTE-20D...
-
Page 23: Warranty
Claims. Claims pertaining to the products, with the exception of warranty claims, must be filed with Anest Iwata Air Engineering within 6 months of the invoice date, or they will not be honored. - Page 24 www.anestiwata.com inquiry@anestiwata.com Toll Free (800)440-0282 No.SLTE20D-99 _rev2.0...
