- Page 1 EW-32 Owner’s Manual www.ewheelsdealers.com (888) 305-0881 Sales (888) 571-2845 Service...
-
Page 2: Table Of Contents
Table of Contents Page 2 - Feature Guide Page 3 - Technical Specifications Page 4-8 - Operation of Scooter Page 9-10 - Charging and Battery Information Page 10 - Ramps and Curbs Page 11 - General Page 11 - Use While Under Influence Page 12-13 - Safety Requirements Page 14-15 –... - Page 3 Seat Swivel Lever Seat Backrest Adjustment Lever Folding Front Tiller Basket Stabilizing Bracket Rear Basket Front Shocks...
-
Page 4: Technical Specifications
Technical Specifications Model EW-32 Weight Capacity 350LBS Speed: Up to 10mph Distance: 30-35 miles per charge (distance varies on terrain, riders weight, road surface, etc.) Front Seat: Type Adjustable Comfort Seat Front seat: Size 18” x 18” x 20” Front Windshield:... -
Page 5: Operation Of Scooter
Operation of Scooter 1. Turning on the power Insert key into ignition and turn clockwise to turn the scooter on. Turn the key one more time clockwise to activate the headlight. The battery indicator will display the current charge level when on. Turn the key counter-clockwise to power off when stopped. - Page 6 3. Headlight The headlight has multiple LED’s that are very bright. The headset can be adjusted upwards or downwards as needed to light up the path ahead. Apply light pressure to the headset, and push in the desired direction. 4. Forward/Reverse and Horn The forward/reverse and horn button are located on the left side of the handlebar assembly.
- Page 7 5. Emergency Brake The emergency brake mechanism is located on the left-hand side hand brake, and does require both hands to engage or disengage. To activate, start by pulling and holding the brake handle, then push the emergency brake pin downwards, and release the brake handle before releasing the pin.
- Page 8 7. Bluetooth Radio The Bluetooth speaker is inside the headset and will automatically start when the scooter is turned on. To connect to the Bluetooth speaker, start by turning on Bluetooth on your Bluetooth compatible device that you would like to play music from.
- Page 9 9. Swiveling Seat The swiveling seat handle is located underneath the seat on the right-hand side. Before swiveling the seat, adjust the seat all the way forward to * avoid the seat hitting the rear basket. If the seat is not adjusted forward prior to swiveling, damage to the seat may occur.
- Page 10 The smart charger included with your scooter will shut off its high current mode when the scooter is fully charged. When the light on the charger is red, the scooter is still charging. When the light turns green, this means the scooter is fully charged.
-
Page 11: Ramps And Curbs
- The useful life of a battery is quite often a reflection of the care it receives. - Always charge the batteries in a well-ventilated area. - The charger is intended for indoor use only. - Replace all batteries at the same time if weak. - Recharge the scooter at least once every month when not in use to avoid deterioration of the batteries. -
Page 12: Safety Requirements
Safety Requirements: Driving Surface The EW-32 has the best stability and performs the best under the normal driving conditions (dry, level ground with concrete or asphalt). Extra care must be taken when riding on other surfaces (grass, gravel, etc.). - Page 13 DO NOT exceed the specified climbing angle. Do not operate the scooter before you have fully read and understood the manual. • Always turn the scooter off before getting on or off the scooter. • Avoid driving in loose gravel, covered soil and sandstone. •...
- Page 14 • Never take the scooter on an escalator. • Do not operate on frozen, slippery or salty roads. • Never let the batteries freeze; do not charge when frozen. • Do not let the batteries every go completely dead. When low, do not let sit for an extended period or damage may occur.
-
Page 15: Warranty
Warranty Three Year Limited Warranty Three (3) years from the date of purchase on all structural frame components; Seat post and frame. One Year Limited Warranty One (1) Year from the date of purchase, if any part or electronic component of the scooter is found upon examination to be defective in material and/or workmanship, it will be replaced at E- Wheels’... - Page 16 Consumable items which may need replacing due to normal wear and tear (tires, tubes, belts, bulbs, upholstery and seating, throttle, brakes, motor brushes, fuses, plastic shrouds and footrest covers) Damaged caused by: battery fluid spillage or leakage, abuse, misuse, accident, negligence, improper operation, excessive loading, maintenance, storage, commercial use, or use other than normal.
- Page 17 Do not adjust your seat while the scooter is in motion or operating.
- Page 18 General Operation – Driving Outdoors Your scooter is designed to be driven on clean, even, dry surfaces. eWheels does not recommend you store your scooter outdoors. Your scooter is susceptible to damage to electronic, mechanical, or other components if exposed to water. If you are caught outside during inclement weather, seek shelter or ask someone for assistance.
- Page 19 decline.
- Page 20 vendors.
