- Page 1 EW-54 Owner’s Manual www.ewheelsdealers.com (888) 305-0881 Customer Service (888) 571-2845 Service...
-
Page 2: Table Of Contents
Table of Contents Instrument Panel………………………………………………. Music system operation……………………………………. Before you operate your scooter…………………..….. Scooter initial operation………………………….…...….. Technical specification……………………………….…….. Cruise Control…………………………………………………… Mirror Assembly……………………………………………….. Variable Speed Control……………………………………… Twist Throttle……………………………………………………. Emergency Brake handle ………………………………….. Seat Latch Release ……………………………………………. General /Safety Instruction…………….………………… Environment Condition……………………………………… Seat Adjustment……………………………………………….. -
Page 3: Instrument Panel
Turn Signal Indicator Hazard lights Clock Function Speed (KPH) Turn Signal Indicator Temperature Battery Indicator Cruise Control Reverse Bright Light Indicator Left Turn Signal Horn High Bean Light Horn Right Turn Signal Drive 1 Drive 2 Slow Speed Low Beam Drive 3... -
Page 4: Music System Operation
LED Indicator indicating Radio is on Volume up Power Volume Down Previous Song / Previous Station Play / Pause Song Next song or station... -
Page 5: Before You Operate Your Scooter
Before you operate the scooter Locate the below listed materials in rear cargo box: Set of mirrors Electric charger Scooter Key (Key #2 is located underneath seat in storage compartment) Owner’s manual IT IS VERY IMPORTANT TO READ OWNER’S MANUAL BEFORE SCOOTER OPERATION Scooter Initial Operation ... -
Page 6: Technical Specification
Technical Specifications Model EW-54 Scooter Weight Capacity 500Lbs. Speed: Up to 15mph Distance: 43 miles per charge (distance varies on terrain, riders weight and road surface etc.) Front Seat: Type Adjustable chair with backrest Front seat: Size 22 ½”x17 ½”x23” (LxWxH) Front Seat: 27”... -
Page 7: Cruise Control
Cruise Control The Cruise control is located just under the digital dash, indicated by the “Cruise” button. Simply reach your desired speed while driving the scooter and press the “Cruise” button and the scooter speed will be fixed at your current speed until the brake pedal is pressed. Mirror Assembly Your power scooter is shipped partially disassembled for protection during shipping. -
Page 8: Twist Throttle
Press once for D1: Slow speed function Press twice for D2: Moderate speed function Press three times for D3: Fastest speed function 3. Always check you have selected the correct forward or reverse button when about to drive. The reverse button is located below the dash. When the reverse button is pressed the reverse light will iluminate and the scooter will sound. -
Page 9: Emergency Brake Handle
Emergency Brake Handle To activate the emergency brake, first start by depressing the foot pedal to alleviate tension from the brake lines. Keep the brake pedal depressed while activating or releasing the emergency brake. Pull the handle out towards you while the handle is in the vertical position to activate. To deactivate, push the foot brake down again, and follow the instructions on the handle "Push Button and Turn"... -
Page 10: General /Safety Instruction
General 1. Always use a seatbelt, and keep your feet on the scooter all the time. 2. Do not exceed maximum weight capacity of 500lbs. (including accessories and carry on) 3. Do not attempt to lift or move a power scooter by any of its removable parts. Personal injury and damage to the power chair may result. -
Page 11: Seat Adjustment
Warranty For valid warranty claims E-Wheels will, at their discretion, replace/repair/refund items mutually agreed to be defective. E-Wheels warranty as following: 1. Frame: (2) Year limited warranty 2. Electronic component: (1) Year limited warranty 3. Controllers: (3) Year limited warranty 4. -
Page 12: Trunk
Trunk To open trunk simply insert ignition key while turning the key counter clockwise, place your hand on the seat back and pull seat forward. You must keep key turned while pulling seat forward and back. Be sure to not push in on the key) Key Fob Press once to deactivate alarm... -
Page 13: Clock Adjustment
Clock Adjustment Press the “reset button” and this function will change from hours to minutes. Once at the desired location press the “select” button to change the digits. Once the digit is changed simply press “reset” button once again and the function will change to the next digit in line. -
Page 14: Charger Use
Charger Use 1. Plug charger into Electric wall outlet 2. Insert charger port into scooter charging plug which is located on the front/side of scooter main body directly under seat. 3. Red charger light indicates scooter is charging 4. Green charger light indicated scooter is fully charged. 5.
