Summary of Contents for Elebia NEO20
- Page 2 Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any speci cations.
-
Page 3: Table Of Contents
Table of Contents General Information General Precautions Restrictions Main Features Speci cations Regulatory Standards Remote Control FCC, IC, CE & ARIB Battery Charger Lifting Procedure Manual Override Conformity Declaration & Manufacturer’s Certi cate Warranty Inspection & Maintenance Maintenance Check Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any speci cations. -
Page 4: General Information
This user’s manual covers the Application, Operation, Use and Maintenance of the elebia NEO lifting hook. NOTE: disconnect power sources prior to handling. Warning Prior to operation and/or maintenance of elebia products, read and understand the information provi- ded in this user’s manual. -
Page 5: Restrictions
· In uences resulting from temperature The elebia NEO lifting hook has been designed to be used in normal atmospheric conditions and in a temperature range from -20 ºC to 60 ºC / -4 ºF to 140 ºF. The NEO lifting hook must not be used if these conditions are not met. -
Page 6: Main Features
Main Features of the NEO lifting hook Swivel with Bearings High Brightness LED Status Indicator* Green: The lifting hook is unlocked and can release load. Red: Intermediate status. Do Not Lift! Lifting hook is transitioning from unlocked to locked or vice versa. Blue: The lifting hook is securely locked and can lift load. -
Page 7: Speci Cations
Speci cations 390 / 15.35 148,5 / 5.85 115 / 4.53 93 / 3.66 100 / 3.93 mm. / in. 54 kg. / 119.05 lb. Regulatory Standards Our Products certify with the following regulatory standards: ASME B30.20-2010 UNE-EN 1050 Directive on Machine Safety (D2006/42/EC) ASME BTH-1-2017 UNE-EN 13135:2013 EN 10204 3.1.B... -
Page 8: Remote Control
Battery level of the NEO lifting hook Low battery level of the eMINI remote control > ‘One button’ mode: Maintenance review of the NEO lifting hook ‘elebia’ button: locks and unlocks the NEO lifting One button mode hook. Two buttons mode >... -
Page 9: Fcc, Ic, Ce & Arib
18.725 For more information on the eMAX remote control, please refer to the eMAX remote control user manual (downloadable from https://elebia.com/downloads/) FCC, IC, CE & ARIB This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. -
Page 10: Battery
Battery The battery status is indicated by a 14 segment Eink display. The battery is fully charged when the 14 Eink segments are black, and as the battery discharges the segments turn white. The battery is completely discharged when all 14 Eink segments are white. -
Page 11: Lifting Procedure
Lifting Procedure Engage Approach Orient and Position Descend Make sure lifting hook is open. NEO Lifting hook orients and po- (Visual con rmation with GREEN sitions itself automatically when colour in LED status indicator) nger contacts lifting point. Close and Lock Lift Sensor detects contact and NEO lifting hook closes Once closure system is con rmed locked, lifting of... -
Page 12: Manual Override
Release USER 12:42 USER 12:42 ºC ºC OPENING Once load is safely The release order The NEO lifting hook Load is released. on the ground. can be given. unlocks and opens. (RED (GREEN colour in LED colour in LED status status indicator) indicator. -
Page 13: Conformity Declaration & Manufacturer's Certi Cate
Conformity Declaration and Manufacturer’s Certi cate ELEBIA AUTOHOOKS, S.L.U., with registered o ce at Plaça Pere Llauger Prim, naus 10-11, Polígon Indus- trial Can Misser, 08360, Canet de Mar, (Barcelona), Spain, Tax Identi cation Certi cate B65770265, and ISO 9001 Certi cate No. 9000041... -
Page 14: Warranty
At least once a year, or in case of any damage to the NEO lifting hook, the hook should be inspected, tested and if necessary returned to Elebia Autohooks SLU Technical Service for review. The frequency of inspections and tests may vary according to the intensity and type of use. -
Page 15: Maintenance Check
Maintenance Check Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any speci cations. - Page 16 Plaça Pere Llauger Prim, Naus 10-11 Polígon Industrial Can Misser 08360 Canet de Mar (Barcelona) Spain Tel. (+34) 93 543 4706 www.elebia.com info@elebia.com...
