- Page 1 NEO100 Lifting Hook _____________________________ User Manual elebia ® smart lifting solutions...
- Page 2 Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications.
-
Page 3: Table Of Contents
Table of Contents General Information General Precautions Restrictions Main Features Specifications Regulatory Standards Remote Control FCC, IC, CE & ARIB Battery Charger Lifting Procedure Always On/Smart Nap Modes Laser Pointer Conformity Declaration & Manufacturer’s Certificate Warranty Inspection & Maintenance Maintenance Check Disclaimer: This user manual is for information only. -
Page 4: General Information
DO NOT operate the NEO100 lifting hook nor repair it if it is damaged or lacks components. DO NOT lift more than the Working Load Limit of 100,000 kg. / 220,462 lb. indicated per NEO100 lifting hook and in the CE stamp. -
Page 5: Restrictions
The elebia NEO100 lifting hook has been designed to be used in normal atmospheric conditions and in a temperature range from -20 ºC to 60 ºC / -4 ºF to 140 ºF. The NEO100 lifting hook must not be used if these conditions are not met. -
Page 6: Main Features
High Capacity Battery High Brightness LED Status Indicator Like the rest of the NEO range, the NEO100 carries a High-Brightness LED status indicator, an additio- nal safety measure which shows the lifting hook’s status at all times with a bright 4 colour-code scheme visible from the operator’s position. -
Page 7: Specifications
70 / 2.75 185 / 7.28 mm. / in. 380 kg. / 837 lb. Regulatory Standards The NEO100 Lifting Hook certifies with the following regulatory standards EN 10204 3.1.B UNE-EN 13135:2013 Directive on Machine Safety (D2006/42/EC). ETSI EN 300 220-1 V3.1.1 UNE-EN 61000-6-4:2007 EMC Directive (2014/30/EU). -
Page 8: Remote Control
Remote Control The NEO100 lifting hook can be paired to the eMAX remote control, the eMINI remote control and/or the eINST installable remote control. eMINI Mode Button The eMINI is a small and compact remote control. With the eMINI remote control, the operator can open and... -
Page 9: Fcc, Ic, Ce & Arib
The NEO100 lifting hook can also be controlled using a free channel of the crane’s master control. The eINST remote control has to be placed in the crane relay cabinet, where only simple wiring is needed. It may be used by pairing to a free channel of the crane’s master control. -
Page 10: Battery
High capacity: 3 hour charge – 5,000 cycles / 250 hours in standby mode. For more information about the battery, please refer to the evo2 battery user manual (downloadable from https://elebia.com/downloads/) Technology Rechargeable Li-Ion Maximum Voltage 12.4 V DC Nominal Voltage 10.95 V DC... -
Page 11: Lifting Procedure
(open) to red (do not lift) and finally to blue (closed). Release Once load is safely on The release order can The NEO100 lifting hook Load is released. the ground. be given. unlocks and opens. (green colour in LED status indicator.) -
Page 12: Always On/Smart Nap Modes
The pulse of the LED status indicator takes an intermittent pattern after 10 seconds in order to save battery. Should the NEO100 carry a load cell and there is a suspended load, this intermittence is of higher frequency. Laser Pointer The NEO100 carries a Laser Pointer as an optional fea- ture. -
Page 13: Conformity Declaration & Manufacturer's Certificate
Conformity Declaration and Manufacturer’s Certificate ELEBIA AUTOHOOKS, S.L.U., with registered office at Plaça Pere Llauger Prim, naus 10-11, Polígon Indus- trial Can Misser, 08360, Canet de Mar, (Barcelona), Spain, Tax Identification Certificate B65770265, and ISO 9001 Certificate No. 9000041 DECLARES: Under its sole responsibility, that the following NEO100 Lifting Hook, with serial number _____________, with a maximum operating load of 100,000 kg., complies with the EC Machinery Directive 2006/42/EC... -
Page 14: Warranty
Inspection & Maintenance At least once a year, or in case of any damage to the NEO100 lifting hook, the hook should be inspected, tested and if necessary returned to Elebia Autohooks SLU Technical Service for review. The frequency of inspections and tests may vary according to the intensity and type of use. -
Page 15: Maintenance Check
Maintenance Check Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Disclaimer: This user manual is for information only. The manufacturer reserves the right to modify any specifications. - Page 16 Plaça Pere Llauger Prim, Naus 10-11 Polígon Industrial Can Misser 08360 Canet de Mar (Barcelona) Spain Tel. (+34) 93 543 4706 www.elebia.com info@elebia.com...
