Summary of Contents for Elebia NEO50
- Page 2 Disclaimer: This user manual is for informational purposes only. The manufacturer reserves the right to modify its specifications without prior notice.
-
Page 3: Table Of Contents
Table of Contents General Information General Precautions Restrictions Main Features Specifications Regulatory Standards Remote Control FCC, IC, CE & ARIB Battery Charger Lifting Procedure Always On/Smart Nap Modes Laser Pointer Manual Override Conformity Declaration & Manufacturer’s Certificate Warranty Inspection & Maintenance Maintenance Check Disclaimer: This user manual is for informational purposes only. -
Page 4: General Information
This user’s manual covers the Application, Operation, Use and Maintenance of the elebia NEO50 & NEO60 lifting hook. NOTE: Disconnect power sources prior to handling. Warning Prior to operation and/or maintenance of elebia products, read and understand the information provi- ded in this user’s manual. -
Page 5: Restrictions
· Influences resulting from temperature The elebia NEO lifting hook has been designed to be used in normal atmospheric conditions and in a temperature range from -20 ºC to 60 ºC / -4 ºF to 140 ºF. The NEO lifting hook must not be used if these conditions are not met. -
Page 6: Main Features
Main Features of the NEO50/NEO60 Lifting Hook Always On/Smart Nap Button Laser Pointer Button High Capacity Battery High Brightness LED Status Indicator Green: The lifting hook is unlocked and can release load. Red: Intermediate status. Do Not Lift! Lifting hook is transitioning from unlocked to locked or vice versa. -
Page 7: Specifications
55 / 2.16 135 / 5.31 mm. / in. 135 kg. / 297.60 lb. Regulatory Standards The NEO50 & NEO60 lifting hooks certify with the following regulatory standards NEO50: NEO50 & NEO60: Directive on Machine Safety (D2006/42/EC). EMC Directive (2014/30/EU). -
Page 8: Remote Control
Remote Control The NEO50 & NEO60 lifting hook can be paired to the eMAX remote control, the eMINI remote control and/ or the eINST installable remote control. eMINI Mode Button The eMINI is a small and compact remote control. With... -
Page 9: Fcc, Ic, Ce & Arib
Dimensions: 80 x 140 x 45 mm. / 3.15 x 5.51 x 1.77 in. For more information on the eINST remote control, please refer to the eINST remote control user manual (downloadable from https://elebia.com/downloads/) eMAX The eMAX is our most advanced remote control. It displays all the info in a big high-resolution screen and a high-profile... -
Page 10: Battery
High capacity: 3 hour charge – 5.000 cycles / 250 hours in standby mode. For more information about the battery, please refer to the evo2 battery user manual (downloadable from https://elebia.com/downloads/) Technology Rechargeable Li-Ion Maximum Voltage 12.4 V DC Nominal Voltage 10.95 V DC... -
Page 11: Lifting Procedure
Lifting Procedure Engage NEO approaches the The trigger makes NEO’s sensor recognizes The load is ready to be lifting point, orients contact with the lifting the hook is in the closed lifted and transported. and positions itself point and the closing position and latches once the hook con- operation begins. -
Page 12: Always On/Smart Nap Modes
Always On / Smart Nap Always On Smart Nap With the “Always On” mode, the colour code scheme The “Smart Nap” mode reduces battery consumption of the LED status indicator will always be visible. Blue by activating the LED’s colour code scheme when the –... -
Page 13: Conformity Declaration & Manufacturer's Certificate
Member States relating to electromagnetic compatibility, and has been manufactured in accordance with the following harmonised standards: NEO50: EN 10204 3.1.B., ETSI EN 300 220-1 V3.1.1., ETSI EN 300 220-2 V3.1.1., ETSI EN 303 446-1 V1.1.0., ETSI EN 303 446-2 V1.1.0., UNE-EN 1050, UNE-EN 13135:2013, UNE-EN 60730-1:2013 NEO50 &... -
Page 14: Warranty
At least once a year, or in case of any damage to the NEO lifting hook, the hook should be inspected, tested and if necessary returned to Elebia Autohooks SLU Technical Service for review. The frequency of inspections and tests may vary according to the intensity and type of use. -
Page 15: Maintenance Check
Maintenance Check Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Date: Date: Observations: Observations: Disclaimer: This user manual is for informational purposes only. The manufacturer reserves the right to modify its specifications without prior notice. - Page 16 Plaça Pere Llauger Prim, Naus 10-11 Polígon Industrial Can Misser 08360 Canet de Mar (Barcelona) Spain Tel. (+34) 93 543 4706 www.elebia.com info@elebia.com...
