Project Source PSWS-B7-20 Instructions Manual page 18

OPERATING INSTRUCTIONS
Filling the Reservoir Water
1. Fill the water reservoir with clean tap water to the max
fill line.
Note: The overflow drain prevents overfilling.
To Change Reservoir Water
1. Unplug the saw.
2. Remove the overflow drain and empty waste water
into a bucket. DO NOT allow the water to splash onto
the ground or around the machine.
3. Rinse the machine thoroughly.
Note: Make sure there is no debris inside the water level
component compartment.
4. Discard the waste water in accordance with local
regulations.
5. Replace with clean water.
Using the Extension Table
The extension table can be used on either side of the
tile saw to support large format tile.
• Simply slide extension table (K) out for the best support
for the size of the tile you are cutting.
• Return the extension table (K) to the inner position after
finishing the cutting.
1
2
18
L
K
kobalttools.com
