Gebrauchs- und Montageanleitung
Instructions for installation and use
Instructions de montage et d'emploi
Wichtig: Unbedingt lesen und aufbewahren!
Important: Read these instructions carefully and then store them in a safe place
Important: Lire attentivement et ranger soigneusemnt ce mode d'emploi
Integrierte Kühl-Gefriergerät
Integrated Fridge -Freezers
Réfrigérateur - Congélateurs à intégrer
Modell: IKE 318-7
F
GB
p.: 13-22
23-33
2223 077-42
Advertisement
Table of Contents
Related Manuals for Kuppersbusch IKE 318-7
Summary of Contents for Kuppersbusch IKE 318-7
- Page 1 Important: Read these instructions carefully and then store them in a safe place Important: Lire attentivement et ranger soigneusemnt ce mode d’emploi Integrierte Kühl-Gefriergerät Integrated Fridge -Freezers Réfrigérateur - Congélateurs à intégrer Modell: IKE 318-7 p.: 13-22 23-33 2223 077-42...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Environment Protection
• Do not place carbonated or fizzy drinks in the connecting the appliance to allow tl¦e oil to flow freezer as it creates pressure on the container, back in the compressor. which may cause it to explode, resulting in damage to the appliance. Environment Protection Installation This appliance does not contain gasses which... - Page 4 this condition, the refrigerator compartment Temperature regulation temperature might drop below 0°C. If this oocurs The temperature is automatically regulated and can reset the thermostat knob to a warmer setting. be increased to achieve a higher temperature Place the food to be frozen on the glass shelf of the (warmer) by rotating the thermostat knob toward freezer compartment as this is the coldest part.
-
Page 5: Movable Shelves
Movable shelves The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. D338 Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be placed at different heights. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required. -
Page 6: Maintenance
Hints for storage of frozen food To obtain the best performance from this appliance, • not open the door frequently or leave it open you should: longer than absolutely necessary. • Once defrosted, food deteriorates rapidly and • make sure that the commercially frozen foodstuffs were adequately stored by the retailer;... -
Page 7: Customer Service And Spare Parts
The freezer compartment, however, will become 4. when defrosting is completed, dry the interior progressively covered with frost. This should be thoroughly and refit the plug; removed with the special plastic scraper provided, 5. turn the thermostat knob back to the required whenever the thickness of the frost exceeds 4 mm. -
Page 8: Door Reversibility
Door reversibility The appliance’s door have been locked in position for transport by means of pins on both sides. According to the door opening direction, remove relevant pins at the top and at the bottom. Reversibility of the freezer door 180°... - Page 9 Drill the unit using a Ø 2.5 mm drill (10 mm max. 13mm penetration); Ø 2,5 Fix the square fitting (1) to the appliance D740 Fit the appliance in the niche by making sure that it stands against the interior surface of the unit on the side where the door hinges of the appliances are fitted.
- Page 10 Apply covers (C-D) on joint cover lugs and into hinge holes. Snap vent grille (B) and hinge cover (E) into position. Separate parts Ha, Hb, Hc, Hd as shown in the figure. PR266 Place guide (Ha) on the inside part of the furniture ca.
- Page 11 Should the lining up of the furniture door be necessary, use the clearance of slots. At the end of operations, it is necessary to check if the door of the furniture closes properly. PR168 Fix cover (Hd) on guide (Hb) until it clips into place. PR167/1...
- Page 12 KÜPPERSBUSCH HAUSGERÄTE AG Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de Küppersbusch Ges. m. b. H. Eitnergasse 13, 1231 Wien, Telefon: 01 / 8 66 80-0, Telefax: 01 / 8 66 80 72 www.kueppersbusch.at ·...
