Poly CCX 500 and CCX 505 Business Media Phone Hardware

The following figure displays the hardware features on Poly CCX 500 and CCX 505 business media phones. The table lists
each feature numbered in the figure.
Figure 3: Poly CCX 500 and CCX 505 phone hardware features
Feature
Speakerphone indicator
Speaker
Mute key
Feature Description
Displays when the phone is powered on. The icon glows green
when activated.
Provides ringer and speakerphone audio output.
Mute or unmute the microphone during an active call.
