Poly CCX 500 and CCX 505 Phone Hardware Feature Descriptions
Reference Number
1
2
3
4
5, 6
7
8
9
10
11

Poly CCX 600 Business Media Phone Hardware

The following figure displays the hardware features on Poly CCX 600 business media phones. The table lists each feature
numbered in the figure.
Feature
Reversible tab
Message waiting indicator
Teams button
Touchscreen
Volume keys
USB port(s)
Headset indicator
Speakerphone indicator
Speaker
Mute key
Feature Description
Secures the handset in the cradle when you position your phone
stand at a high angle. To secure the handset, remove the tab,
reverse it so the protrusion points up, and reinsert it. Position the
handset so the protrusion on the tab fits into the slot on the
handset.
Flashes red to indicate you have an incoming call or new
messages.
Glows and is active when the phone is set to the Teams base
profile.
Navigates to the Home screen. If the Home screen is disabled, the
button navigates to the Calls screen.
Select items and navigate menus on the touch-sensitive screen.
Adjust the volume of the handset, headset, speaker, and ringer.
Poly CCX 500 and CCX 505 phones include one USB-A port and
one USB-C port.
Attach a USB flash drive or USB headset.
Displays when the phone is powered on. The icon glows green or
blue when a headset is connected and activated.
Displays when the phone is powered on. The icon glows green
when activated.
Provides ringer and speakerphone audio output.
Mute or unmute the microphone during an active call.
