NX PRO PelletS
USeR MANUAl
ÍNDEX
Printer Specifications ................................... 2
Main parts of the printer ................................ 3
Elements included in the printer .................... 3
Installation and set up ................................... 4
Quick guide ................................................... 6
Adjust the Pellet extrusion.............................7
Head cleaning................................................8
Simplify 3D Printing Software ........................ 8
Simplify 3D loading profiles............................8
Security .......................................................10
Basic recomendations .................................10
Warranty.......................................................11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tumaker NX PRO PelletS
Summary of Contents for Tumaker NX PRO PelletS
-
Page 1: Table Of Contents
NX PRO PelletS USeR MANUAl ÍNDEX Printer Specifications ........2 Main parts of the printer ........ 3 Elements included in the printer ....3 Installation and set up ........4 Quick guide ........... 6 Adjust the Pellet extrusion......7 Head cleaning..........8 Simplify 3D Printing Software ...... -
Page 2: Printer Specifications
printer specifications Printer Volume: 295x185x200 mm Nozzle Diameter: 0.4 - 0.6 - 0.8 - 2.0 - 4.0 - 5.0 mm Printer Size: 550x440x460 mm Nozzle temperature: 350ºC Package Size: 605x501x500 mm Two temperature control points Package Weight: 24 kg Files: STL,OBJ, AMF Printer Weight: 22 kg Connected to the Internet Materials: Materials in pellet format. -
Page 3: Main Parts Of The Printer
Main parts of the printer Main parts of the printer Display Layer fan Frontal fan Nozzle Hotend Hopper HOTEND It moves in the X and Y axes by melting the pellet of material and depositing it on the platform or heated bed. It has a nozzle that heats up to the required temperature according to the corresponding printing material PLATFORM OR HEATED BED... -
Page 4: Installation And Set Up
Installation and set up WIRING DISPLAY To start with the installation and set up, connect the The light indicator will stay on while the printer is on. power cable to the slot on the back of the printer and plug it into the power socket. Switch onthe printer by pressing the button. - Page 5 • If you have not entered the IP by command in the console, it is recommended to do so, so that the router does not change it: M587 S ”Wifi name ” P ” Password” I192.168.X.XXX • If you have not obtained the IP or have any other problem, do not hesitate to consult at: https://tumaker.com/tumaker-en/ support/...
-
Page 6: Quick Guide
quick guide Level the Build Plate • Heat the base to the temperature you want to print at • Make sure you have a clean tip • Execute the calibration process found in the Macros “Calibration” section and follow the steps •... -
Page 7: Adjust The Pellet Extrusion
Adjus the Pellet extrusion Open the material config.g In config.g you can change the flow rate, the temperature of the two measurement points and the bed New Material Once created, copy the config.g from a previous material and edit the necessary parameters In file manager / Macros / Extrusion calibration / Select the model you want to print. -
Page 8: Head Cleaning
250º. temperature to 210º. Simplify 3D printing sOFtWARe Tumaker 3D printing stations include the Simplify3D™ You will be able to repair the imported designs in professional manufacturing suite, a software with all the Simplify3D itself and you will love the intelligent support advanced and optimized characteristics to create the most option. - Page 9 Click on Import Select the .frm file In File go to Import FFF profile Click save It will show a message like this Select the .fff file you want to import In the Process select the imported profile Make sure that the imported .frm appears in the G-Code tab...
-
Page 10: Security
Place the printer on a firm surface Use materials recommended by periodically, every time you change without vibration. Tumaker to ensure proper printer spools or material. Write us and we operation. will provide them to you. Place the printer in a draft-free... -
Page 11: Warranty
This Limited Warranty shall only be valid and enforceable in the country in which you purchased the Product as long as Tumaker has intended the Product for sale in that country. However, if you purchased the Product in a member state of the European Union, this Limited Warranty is valid and in force. - Page 12 Responsability Tumaker shall not be liable to the Buyer for the failure or inability of Tumaker products to function properly. Nor for any loss, damage, injury or expense of any kind or nature caused directly or indirectly by Tumaker’s products. If for any reason it is necessary to ship the Product to Tumaker facilities, it is recommended that the Product be shipped under insurance to cover possible loss or damage.
