- Page 1 Software included PELLETS 3D printer First steps Warranty Declaration of conformity...
-
Page 2: Table Of Contents
INDEX INDEX Printer Specifications..................p.3 Main parts of the printer................p.4 Elements included in the printer..............p.5 Installation and set up...................p.6 Load of material..................p.7 Printer calibration..................p.8 Head cleaning....................p.11 Simplify Printing Software................p.11 Door sensor....................p.12 Safety Measures..................p.13 Basic recommendations ................p.13 WARRANTY.....................p.14 DECLARATION OF CONFORMITY..............p.17... -
Page 3: Printer Specifications
PRINTER SPECIFICATIONS Printer Volume: 270x190y200z Nozzle Diameter: 0.8 Printer Size: 45x41x41 Nozzle Temperature: 180ºC - 350ºC Package Size: 50x50x61 Nozzle Heat Up Time: Package Weight: 26 kg 20ºC: 200ºC - 1’15” / 250ºC - 1’50” Printer Weight: 24 kg / 300ºC - 2’35” Materials: Pellet format materials Conectivity: USB, Ethernet / Wifi Printing Speed: Depends on parameters... -
Page 4: Main Parts Of The Printer
MAIN PARTS OF THE PRINTER PELLET FEEDER Once the material has been fed into the hopper, it melts inside the pellet feeder. It passes through the head to the nozzle, and it is extruded on the surface of the heated bed. NOTE: The head moves on the X and Y axes. -
Page 5: Elements Included In The Printer
ELEMENTS INCLUDED IN THE PRINTER Make sure that the following items have been delivered with the printer, otherwise please contact us. FIXING SPATULA GLASS POWER CORD LACQUER CABLE WIRING LIGHT INDICATIONS The light indicator will stay on while the printer is on. To start with the installation and set up, connect the power cable to the slot on the back of the printer and plug it into the power socket. -
Page 6: Installation And Set Up
INSTALLATION AND SET UP Connect the printer to the network in two steps: 3. Open the Settings tab - Connectivity 4. Connect via Ethernet or WiFi always selecting the STATIC 1. Use a computer to connect to the Wifi of your printer with the option password “tumakerLS”. -
Page 7: Load Of Material
LOAD OF MATERIAL The 3D printing of pellets is an FDM process different to the 3D printing with filament spools. First, manually insert the pellets into the hopper. The pellets will begin to fall through the hopper and will melt inside the extruder. The molten material will be expelled through the nozzle and will begin to adhere to the printing base. - Page 8 CALIBRACIÓN DE LA IMPRESORA PRINTER CALIBRATION The calibration of the Pellet 3D printer is essential to achieve quality prints and to ensure optimum performance. The distance between the head nozzle and the bed has to be perfect. 1. Head Heating: Heat up the head to the recommended fusion temperature.
-
Page 9: Printer Calibration
PRINTER CALIBRATION 3. Multiplicator values: 3.1. Design a fully solid 40x40x10 cube and enter the parameters shown in the following image. 3.2. Once created, measure one of the walls and change the multiplier proportionally until the value corresponds to the Ø of the nozzle. IMPORTANT NOTE •... - Page 10 PRINTER CALIBRATION CALIBRACIÓN DE LA IMPRESORA 3.3. Print a 26 mm diameter, 2 mm high disc with normal parameters and 100% fill. Make sure that the amount of extruded material is adequate. • If the part is not completely closed, the extrusion level will be low.
-
Page 11: Head Cleaning
210 degrees. temperature to 250°. SIMPLIFY 3D PROFESSIONAL SOFTWARE Tumaker’s 3D printing stations include the Simplify3D™ You will be able to repair the imported designs in professional manufacturing suite, a software with all the Simplify3D itself and you will love the intelligent support advanced and optimized characteristics to create the option;... -
Page 12: Door Sensor
DOOR SENSOR The door sensor is a new feature of the Pellet 3D Printer If the door is suddenly opened while the machine is printing, the printer will pause the printing to avoid any alterations or damages that may occur. When the door is correctly closed, the printing process will start again from where it was left. -
Page 13: Safety Measures
It is advisable to change the Follow maintenance environment with an ambient nozzle periodically. recommendations for optimal temperature between 15ºC - printer operation and durability. 25ºC. materials recommended by Tumaker to ensure proper Follow the printer installation printer operation. and power-up instructions. -
Page 14: Warranty
Tumaker offers a warranty period of 1 year valid only if it Product in accordance with this Limited Warranty (except has not been misused or if the maintenance and periodic as otherwise provided by law). - Page 15 What is not covered by the Limited Warranty? a third-party printing material (one that has not been supplied by Tumaker) or from the use of a consumable in 1. User manuals or third party software, content, data an unsuitable condition (with adhering elements, grease or links, configuration, included in or downloaded from residues or other similar incidents).
- Page 16 Responsibility You have 7 business days to return a Tumaker product. Tumaker shall not be liable to the Buyer for the failure or This period applies from the day you receive the order inability of Tumaker products to function properly. Nor for and the postmark or transport company’s stamp will be...
-
Page 17: Declaration Of Conformity
De acuerdo con las disposiciones de la Directiva 99/05/CE del Parlamento Europeo Jon Bengoetxea Zurriarain y del Consejo de 9 de marzo de 1999, transpuesta a la legislación española CEO Tumaker S.L mediante el Real Decreto 1890/2000, de 20 de noviembre de 2000. - Page 19 Tumaker S.L. cuentanos@tumaker.com Ihurreta bidea, 13 www.tumaker.com Hall 25, 2º 20180 Oiartzun 943 49 12 44 Gipuzkoa...
