Tolomatic TC07SS Repair Parts Sheet

Track Cable Cylinder
TC07SS 3/4" Bore

Parts Listing

ITEM PART NO. DESCRIPTION
1. Pneumatic Repair Kit, 3/64
1075-9013
cable, specify stroke
1a. Pneumatic Cable Assembly,
1001-9099
3/64 cable, specify stroke
2. 0100-1306 Thrust Race
3. 1001-1205 Rulon Bearing
4. 1050-1051 Pulley
5. Head Assembly (includes gland
1001-9104
insert) single port
6. 1001-1092 Stainless Steel Pulley Shaft
7. 1001-1056 External Retaining Ring
*8. 1001-1276 Cushion Spear
9. 1076-1000 Clamp Plate
10. 1085-1075 Socket Head Cap Screw
Tolomatic • URL: http://www.tolomatic.com • Email: help@tolomatic.com • Fax: (763) 478-8080 • Toll Free: 1-800-328-2174
(with Stainless Steel Guide Shafts)
Quantity ITEM
11.
1
12.
2
*13.
4
14.
2
15.
2
16.
2
17.
2
18.
8
19.
2
*20.
2
*21.
8
22.
*Available only as part of Repair Kit 1075-9013.
PART NO. DESCRIPTION
Machined Aluminum Tube,
1076-1001
specify stroke
1075-1017 Piston
1075-1016 Piston U-Cup
1001-1194 Piston Spacer
Guide Shaft, Stainless Steel,
1076-1002
specify stroke
1001-1199 Internal Retaining Ring
1001-1233 Bearing Block
1001-1236 Linear Rulon Bearing
1004-1188 Jam Nut
1001-1013 Piston Washer
1001-1021 O-Ring
1075-1015 External Retaining Ring
Parts Sheet
1001-0243_01_TC07S
MODEL: TC07SS
Quantity
1
2
2
1
2
4
1
2
2
2
2
2
