Tolomatic MXP63PTP Quick Start Manual

MXP63P Profiled Rail Bearing
Models:
MXP63PTP MXP63PGP MXP63PNP
MXP63PST MXP63PSG MXP63PSN
Both Metric and Inch models
26
23
17
16
18
15
24 20
25
List of Parts
PART NO. or
ITEM CONFIG. CODE DESCRIPTION
1 RTBMXP63P Replacement Tube (8163-1010) Specify Stroke
2 Replacement Magnet Band (8163-1019)
NMBMXP63P
Specify Stroke
1 3 Replacement Dust Band (8163-1018)
NDBMXP63P
Specify Stroke
1 4 Replacement Seal Band (8163-1017)
NSBMXP63P
Specify Stroke
5 8163-1512 Piston Bracket (inch)
8163-1012 Piston Bracket (metric)
1
6 8163-1007 Band Ramp
1 7 8163-1006 End Cap
1 8 0925-1027 U-Cup
1
9 0925-1012 Cushion Seal
10 8163-1004 Piston
11 0603-1016 Socket Head Cap Screw
1
12 8163-1059 Wiper
13 8163-1058 Magnet
14 8163-1005 Wear Ring
15 0925-1087 Head Screw (inch)
4925-1047 Head Screw (metric)
16 8163-1011 Head Assembly, NPT
8163-1046 Head Assembly, BSPT Metric Taper
8163-1047 Head Assembly, ISO Metric Parallel
2 17 0774-1007 O-Ring
2
18 0920-1029 Pipe Fitting Plug, 3/8 NPT
4920-1029 Pipe Fitting Plug, 3/8-19
5920-1006 Pipe Fitting Plug, G 3/8
19 4910-1004 Socket Head Cap Screw
2 20 8163-1039 Band Clamp
2 21 0915-1044 Set Screw
Tolomatic • URL: http://www.tolomatic.com • Email: help@tolomatic.com • Fax: (763) 478-8080 • Toll Free: 1-800-328-2174
36
35
30b
19
13
9
6
14
10
8
80
21
22
Single-end Porting Head
QTY.
2A/R
63mm (2- 1 ⁄ inch) Bore
2
5
34
32
29
27
12
30a
31
28
1
PART NO. or
ITEM CONFIG. CODE DESCRIPTION
A/R
2 22 0920-1024 Flat Head Cap Screw
2
23 8163-1038 Band Wedge
2 24 0720-1003 O-Ring
A/R
2 25 8163-1065 Needle Screw
2
26 0925-1158 Cushion
A/R
1 27 8163-1028 Bearing
28
1
NNRMXP63P
2 29 4415-1001 Socket Head Cap Screw
2 4 30a
NPRMXP63P
2
4 30b
2
31 8163-1034 Carrier Adjustment Plate
2
32 8163-1076 Bearing
4
33
2
34 2324-1014 Socket Head Cap Screw (inch)
1
8163-1070 Socket Head Cap Screw (metric)
2
35 4415-1000 Socket Head Cap Screw
8
36 8163-1521 Carrier (inch)
8163-1021 Carrier (metric)
3 80 8163-9002 Head Assy, NPT, Single-end Porting
2
8163-9008 Head Assy, BSPT Metric Taper, Single-end Porting
8163-9009 Head Assy, ISO Metric Parallel, Single-end Porting
2
3 81 8163-9003 Head Assembly, Return, Single-end Porting
1 Parts included in Repair Kits RKMXP63PSK (inch), indicate stroke length in inches
6
RKMXP63PSM (millimeters), indicate stroke length in millimeters
2 Parts included in Head Assemblies (16)
4
3 Part is exclusive to single-end porting option
2
4 Bearing Blocks and/or Bearing Rail purchased before Oct. 1, 2014 are NOT com-
4
patible with current Bearing Blocks and Bearing Rails purchased after Oct. 1, 2014.
Parts Sheet
8100-4117_05_MXP6
11
7
2
Return Single-end Porting Head
4
3
Replacement Nut Rail (8163-1053)
Specify Stroke
Replacement Bearing Rail (Specify stroke)
add DW for Dual Carrier
add BB for optional Bearing Blocks
Number is not used
81
QTY.
4
2
2
2
2
2
A/R
A/R
A/R
2
2
8
12
1
1
1
