Tolomatic MXP25PTP Instructions

MXP25P Profiled Rail Bearing
Models:
MXP25PTP MXP25PGP
MXP25PST MXP25PSG
Both Metric and Inch models
30

List of Parts

PART NO. or
ITEM CONFIG. CODE DESCRIPTION
1 RTBMXP25P Replacement Tube (8125-1010) Specify Stroke
2 NMBMXP25P Replacement Magnet Band (8125-1019) Specify Stroke 2 A/R
3 1 NDBMXP25P Replacement Dust Band (8125-1018) Specify Stroke A/R
4 1 NSBMXP25P Replacement Seal Band (8125-1017) Specify Stroke A/R
8125-1012 Piston Bracket (metric)
5
8125-1512 Piston Bracket (inch)
6 8125-1005 Piston
7 1 8125-1006 End Cap
8 1 8125-1007 Band Ramp
9 0601-1038 Socket Head Cap Screw
10 1 8125-1059 Wiper
11 8125-1072 Lock Washer
12 2100-1050 Magnet
13 1 0910-1184 Cushion Seal
14 1 0910-1206 U-Cup
8125-9001 Head Assy, NPT
15 8125-9006 Head Assy, BSPT Metric Taper
8125-9007 Head Assy, ISO Metric Parallel
16 2 2212-1111 Socket Head Cap Screw
17 2 8125-1039 Band Clamp
1014-1065 Pipe Fitting Plug, 1/8-27 NPT
18 2 4910-1002 Pipe Fitting Plug, 1/8-28
5910-1006 Pipe Fitting Plug, G 1/8
1,2
19 0910-1160 O-Ring
4910-1344 Head Screw (metric)
20
0910-1344 Head Screw (inch)
Tolomatic • URL: http://www.tolomatic.com • Email: help@tolomatic.com • Fax: (763) 478-8080 • Toll Free: 1-800-328-2174
MXP52PNP
MXP25PSN
28
24
29b
31
29a
14
7
9
17
23
16
20
19
18
15
25mm (1 inch) Bore
25
26
5
8
10
11
12
6
13
21
Single-end Porting Head
QTY.
A/R
PART NO. or
ITEM CONFIG. CODE DESCRIPTION
8125-9002 Head Assy, NPT, Single-end Porting
Head Assy, BSPT Metric Taper, Single-end
8125-9008
21 3 Porting
1
Head Assy, ISO Metric Parallel, Single-end
8125-9009
2
Porting
2
22 3 8125-9003 Return Head Assy, Single-end Porting
2
23 8125-1038 Band Tab
4
8125-1021 Carrier (metric)
24
2
8125-1521 Carrier (inch)
1
25 1 8125-1034 Carrier Adjustment Plate
1
8125-1070 Low Head Cap Screw (metric)
26
2
8125-1572 Low Head Cap Screw (inch)
2
28 8125-1022 Low Head Cap Screw
Replacement Bearing Rail (Specify stroke)
29a 4
2
NPRMXP25P add DW for Dual Carrier
29b 4
add BB for optional Bearing Blocks
NNRMXP25P Replacement Nut Rail (8125-1053)
2
30
(Specify Stroke)
2
31 8125-1023 Screw
1 Parts included in Repair Kits RKMXP25PSK (inch), RKMXP25PSM (metric).
6
2 Parts included in Head Assemblies (15).
3 Part is exclusive to single-end porting option
2
4 Bearing Blocks and/or Bearing Rail purchased before Oct. 1, 2014
are NOT compatible with current Bearing Blocks and Bearing Rails
8
purchased after Oct. 1, 2014.
Parts Sheet
8100-4106_06_MXP2
3
4
2
22
1
Return Single-end Porting Head
A/R = As Required
QTY.
1
1
2
1
2
8
8
A/R
