Model HHC-980/983
Henny Penny
Humidified Holding Cabinets
Model HHC-980
Model HHC-983
OPERATOR'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HHC-983 and is the answer not in the manual?

Questions and answers

Related Manuals for Henny Penny HHC-983

Summary of Contents for Henny Penny HHC-983

  • Page 1 Model HHC-980/983 Henny Penny Humidified Holding Cabinets Model HHC-980 Model HHC-983 OPERATOR’S MANUAL...
  • Page 3 During this time, any frypot that fails due to manufacturing or workmanship issues will be replaced at no charge for parts, labor, or freight. Henny Penny will either install a new frypot at no cost or provide a new or reconditioned replacement fryer at no cost.

  • Page 4: Table Of Contents

    Model HHC-980/983 TABLE OF CONTENTS Section Page Section 1. INTRODUCTION 1-1. Humidified Holding Cabinet ..................1-2. Features ........................1-3. Proper Care ......................... 1-4. Assistance ........................1-5. Safety .......................... Section 2. INSTALLATION 2-1. Introduction ........................2-2. Unpacking ........................2-3. Location ........................2-4.

  • Page 5: Section 1. Introduction

    • Easy access to electrical controls • Automatic water-fill As in any unit of food service equipment, the Henny Penny humidi- 1-3. PROPER CARE fied holding cabinet does require care and maintenance. Require- ments for the maintenance and cleaning are contained in this manual and must become a regular part of the operation of the unit at all times.

  • Page 6: Safety

    Model HHC-980/983 1-5. SAFETY The Henny Penny humidified holding cabinet has safety features incorporated. However, to ensure a safe operation, read and fully understand the proper installation, operation, and maintenance procedures. The instructions in this manual have been prepared to aid you in learning the proper proce- dures.

  • Page 7: Section 2. Installation

    2-2. UNPACKING The Henny Penny humidified holding cabinet has been tested, inspected, and expertly packed to ensure arrival at its desti- nation in the best possible condition. Any shipping damage should be noted in the presence of the delivery agent and signed prior to his or her departure.

  • Page 8: Location

    Refer to the table below for the electrical ratings for the HHC-980 and 983. Model Volts Phase Amps Watts HHC-980 13.8 2880 12.0 2876 220-240-CE 11.6 2792 HHC-983 17.3 2080 220-240-CE 1992 1004...

  • Page 9: Water Supply Connection

    Model HHC-980/983 2-5. WATER SUPPLY The automatic water-fill system requires a 1/4 inch, maximum CONNECTION 100 psi (690 kPa), water connection. A water conditioner or filter, and a shut-off valve in the supply line is recommended. Follow these steps when making the water supply connection: 1.

  • Page 10: Cabinet Dimensions And Weights

    24-3/4” (806 mm) (628 mm) 24-3/4” (628 mm) 72-1/4” (1835 mm) 31-3/4” (806 mm) 38” (965 mm) HHC-980 HHC-983 Unit Height Width Depth Shipping Weight HHC-983 38” (965 mm) 24-3/4” (628 mm) 31-3/4” (806 mm) 220 lbs (100 kg) HHC-980 72-1/4”...

  • Page 11: Section 3. Operation

    Model HHC-980/983 SECTION 3. OPERATION This section provides operating procedures for the humidfied 3-1. INTRODUCTION holding cabinet. Read the Introduction, Installation, and Operation Sections before operating the unit. This section also contains explanations of all controls, along with operating procedures and daily maintenance. 3-2.
  • Page 12 Model HHC-980/983 3-2. OPERATING CONTROLS (Continued) Control Decal Figure 3-1...

  • Page 13: Start-Up

    2. Connect or turn on water supply. 3. Turn the Power Switch to ON, and the display shows “HHC-983” or “HHC-980”. 4. Press the Temperature button to set the desired cabinet temperature. While the LED is flashing, press the UP and DOWN buttons until the desired temperature shows in the display.

  • Page 14: Operation With Product

    Model HHC-980/983 3-4. OPERATION WITH The LEDs above the Temperature and Humidity PRODUCT buttons go out when the desired temperature and humidity are reached inside the cabinet. The minimum holding temperature for potentially hazardous product is 150 F (66 C). Also, the cabinet product load capacity for the full size units is 375 lbs.
  • Page 15 Model HHC-980/983 3-5. CLEANING Wipe the control panel with a damp cloth. Do not PROCEDURES (Continued) splash water around controls. Reinstall racks, and leave a door partially open over night to allow interior cabinet to thoroughly dry. Weekly: Remove pans and racks from cabinet. Disconnect water supply at side of cabinet.

  • Page 16: Section 4. Programming

    Model HHC-980/983 SECTION 4. PROGRAMMING 4-1. INTRODUCTION This section explains the following programming functions. • Clock-Set • Special Programming 4-2. “HIDDEN BUTTONS” To program the following features, 5 hidden buttons must be pressed. See Figure 3-7 before continuing in this section. 4-3.
  • Page 17 Model HHC-980/983 4-3. CLOCK SET Press and “CS-2, SET, MINUTE” shows in the (Continued) display, with the minutes flashing. Press to change the minutes. Press and “CS-3, SET, MONTH” shows in the display, along with the date (month flashing). Press to change the month.

  • Page 18: Special Programming

    Model HHC-980/983 4-4. SPECIAL PROGRAMMING This mode allows you to program the following: SP-1 • Fahrenheit/Celsius SP-2 • Lock/Unlock SP-3 • Air Temperature Setpoint SP-4 • Humidity Setpoint SP-5 • Out of Water Trip Point SP-6 • Clean Water Pan Setpoint SP-7 •...
  • Page 19 Model HHC-980/983 4-4. SPECIAL PROGRAMMING (Continued) SP-3 Air Temperature Setpoint 9. Press and “SP-3, AIRTEMP SETPOINT,” and the preset cabinet temperature shows in display. 10. Press to change the air temperature setpoint, F (60 C) minimum, 210 F (99 C) maximum. SP-4 Humidity Setpoint 11.
  • Page 20 Model HHC-980/983 4-4. SPECIAL PROGRAMMING (Continued) SP-8 Audio Volume 19. Press and “SP-10, AUDIO VOLUME,” and the volume setting (1 to 10) shows in display. Press hidden button to test volume. See Section 4-2. 20. Press to change the volume. SP-9 Audio Tone 21.
  • Page 21 32. Press and hold the button anytime during programming to exit the Special Programming mode. For more information on the other settings of Special Programming, call your local Henny Penny Distributor or the Corporate Headquarters at 1-800-417-8405, or 937-456-8405.

  • Page 22: Section 5. Troubleshooting

    Model HHC-980/983 SECTION 5. TROUBLESHOOTING 5-1. TROUBLESHOOTING GUIDE PROBLEM CAUSE CORRECTION Product not • Doors left open • Keep doors closed except holding temperature to load and serve product • Product held too long • Hold product only for recom- mended times •...

  • Page 23: Error Codes And Warnings

    Model HHC-980/983 5-2. ERROR CODES AND The display shows the following error codes and warnings when a WARNINGS fault is detected, along with an alarm sound. Both the heat and humidity systems shut down, except when specified otherwise. Display Cause Panel Board Correction “E-4 CPU TOO HOT”...
  • Page 24 Model HHC-980/983 5-2. ERROR CODES AND WARNINGS (Continued) Display Cause Panel Board Correction • Turn switch to OFF position, then back to “ E-6B AIR TEMP SENSOR • Faulty air temperature ON; if the display shows “E-6”, the FAILED SHORTED” probe temperature probe should be checked;...
  • Page 25 Model HHC-980/983 5-2. ERROR CODES AND WARNINGS (Continued) Display Cause Panel Board Correction • Turn switch to OFF position, then back to “E-41 SYSTEM DATA LOST” • Memory Scrambled ON; if the display shows “E-41”, the control should be re-initialized (see Pro- gramming Section);...

  • Page 26: Glossary

    Model HHC-980/983 G L O S S A R Y HENNY PENNY HOLDING CABINETS air temperature probe a round device located inside the cabinet that measures the inside air temperature and sends that information to the control panel concentration ring assembly...
  • Page 27 Model HHC-980/983 probe clip a metal holder that attaches to the outside of the control panel to hold the food probe when not in use; the clip is an optional accessory product load capacity the highest recommended number of pounds/kilograms of food product that can be safely held in the cabinet proof function a program used for allowing bread to rise...
