5.13 Enter setpoints

5.13.1 Enter setpoints for overload

1
Repeat step 1 - 4 of chapter 5.11.
Go into the user menu. Select 'Setpoints'.
3
Standard none of the setpoints are set.
Select 'Overload' to activate the setpoints in
case of an overload situation.
5
The selected setpoint (1) is now marked.
Click on the space next to the text to see the
different options per setpoint.
2
Enter password 123456, confirm with 'Enter'.
4
For the overload signal you can activate 2
setpoints. Select a setpoint to set up the values.
6
The options per setpoint are:
- Net/Gross
- Weight; to enter a predefined weight in kg
- Delay; see next page for more detail
- Password; option on/off only to secure the settings.
