5.12 Debug mode for user
The 5200 indicator has the possibility to check the input values of the load cells and the angle
position. This could be helpful information in case of problems.
1
Repeat step 1 till 4 of chapter 5.11.
Go into the user menu.
Select 'Service help'.
3
Check the load cell signals [mV] and the
level sensor [grades].
2
Select 'Debug'.
4
USER MANUAL – ProLine 5200-Li
31
