Summary of Contents for Arec LS-410
- Page 1 LS-410 Media Station Quick Installation Guide ENGLISH AREC Inc.© All Rights Reserved 2023. l www.arec.com All information contained in this document is Proprietary...
- Page 2 Notice: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Hereby, AREC Inc., declares that this Media Station is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
- Page 3 LS-410 Quick Installation Guide CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. – the ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,table-cloths, curtains, etc.: –...
-
Page 4: Specifications
LS-410 Quick Installation Guide Introduction Featuring a compact and stand-alone design, AREC LS-410 Media Station consists of diverse features and functionality, including multi-signals capturing, recording synchronously, codec, streaming online, live broadcasting, and web-based monitor page, providing complete presentation or lecture capture solution. -
Page 5: Product Appearance
LS-410 Quick Installation Guide Product Appearance Front Panel 11 12 Rear Panel 15 17 19 20 Name Brief introduction Audio meter Audio volume bar Layout function keys Control the Layout functions Record function keys Control the Record, Pause, Stop functions Front USB ports 1. - Page 6 LS-410 Quick Installation Guide Connection projector HDMI video output projector Speaker AREC Network Camera HDMI 2 video output Audio output amplifier Power Balanced audio input RS-232 Mic audio input Line audio input HDMI video input Video output HDMI/ DP USB mouse amplifier...
- Page 7 LS-410 Quick Installation Guide Accessing the Administrator pages Connect PC to the setting port of Media Station with standard network cable.Open up the browser, and input 192.168.11.254 in the broswer page. Log in Administrator with default username admin and password admin, then entering System Administration webpages.
- Page 8 LS-410 Quick Installation Guide Setup Step 1: Set up video input name, video source, PTZ control in [ Video inputs ] of [ Media I/O The Capture source can be the video port [ ] and [ ] . If only one of the latter is connected, the system would detect and automatically switch to source of signal.
- Page 9 LS-410 Quick Installation Guide Step 2: Set up audio volume in [ Audio ] of [ Media I/O Step 3: Set up date and time of host machine in [ System settings ] of [ System Getting start a recording Start a recording from the front panel Select the layout/ background before getting start.
- Page 10 LS-410 Quick Installation Guide Start a recording via the Online director Entering the Online director webpage via [System Administration] by clicking the [ ] button and opening a new tab; or log in Online director from the initial login page with default username director and password director.
- Page 11 LS-410 Quick Installation Guide CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Important Security Policy Precautions 1.Please open the product package carefully; we commend you keep this packaging for future transport, storage or maintenance use.
- Page 12 AREC Inc.© All Rights Reserved 2023. l www.arec.com All information contained in this document is Proprietary Made in Taiwan Date : 2023.3.1 Version : 2.6...
