- Page 1 KS-CC1 Media Station User Manual English AREC Inc.© All Rights Reser ved 2022. l www.arec.com All information contained in this document is Pr oprietary...
-
Page 2: Table Of Contents
KS-CC1 User Manual Table of Contents Introduction Specifications Package Contents Product Appearance Connection Function key and the indicator Getting start Overview of the Web Interface Chapter 1 Administrator 1.1 Media I/O 1.1.1 Video inputs 1.1.1.1 Content 1.1.2 Network device manager 1.1.3 Audio... - Page 3 KS-CC1 Use r Manual Table of Contents chapter 3 Video Manager 3.1 Video Management 3.1.1 Download the recording 3.1.2 Delete the recording 3.1.3 Playback the recording Table of On Screen Disaplay Icons...
-
Page 4: Introduction
KS-CC1 Use r Manual Introduction KS-CC1 can output instant transcription on monitors automatically in a speech event. It also can show the speech script or the translation on audience mobile device. Supporting recording, streaming, and exporting the transcription text file benefit the event host to provide various services for the attendees. -
Page 5: Product Appearance
Reset button Long press to reset the device to default settings Power Indicator LED Indicator for device boot status NOTE: The KS-CC1 can detect and r ecord to USB storage devices using FAT32, NTFS, exFAT, Ext3, Ext4 file systems. www.arec.com... -
Page 6: Connection
KS-CC1 Use r Manual Connection microphone projector Mic audio input Line audio input HDMI video output notebook HDMI video input Micro SD card Power HDMI video output network AREC Network Camera USB mouse external hard disk Speakerphone notebook USB Keyboard... -
Page 7: Function Key And The Indicator
KS-CC1 Use r Manual Function key and the indicator Button/Indicator Display method of indicator Product status Speech-to-text r ecognition in progress. Red light glows continuously *Along with translating, recording, and streaming Service Button if enabled. Power indicator Green and red light flash alternately . -
Page 8: Getting Start
KS-CC1 Use r Manual Getting start Connecting to network Connect KS-CC1 to a router or switch and please ensure that it is accessible to the internet. On the KS-CC1’ s first bootup, it will register to AREC server and receiving a 10-hour service time for live transcription. - Page 9 KS-CC1 Use r Manual 3. Configure your video source • HDMI & USB video source Please select “Video port” in Signal type, and select the corresponding option in “Video source”. And click Apply to take effect. • Network camera First, go to the Network device manager page and click scan to find y our network camera.
- Page 10 Audio Input KS-CC1 suppor t multiple audio input types: Line-in/Min-in/HDMI/USB audio input. Connect your audio input source to the KS-C C1 and go to web administrator → Media I/O → Audio page to configure the volume level.
- Page 11 Configure the live caption preview KS-CC1 provides a web page for the audience to view the subtitle in live. You can configure a QR code for the audiences to use their smartphone to scan and it will r edirect them to the subtitle page.
- Page 12 KS-CC1 Use r Manual 2. Insert the IP address of KS-CC1. If y ou’re using port forwarding on KS-CC1 or setting it with a public IP , please insert the external IP address or domain name along with the external por t number.
- Page 13 KS-CC1 Use r Manual Configure recording 1. Insert a storage device (USB driv e/Micro SD card) 2. Go to the web administrator → Storage page. 3. Find the storage device on the list and click Format 4. Select the storage in the Recor d disk settings section and click “ Apply”...
-
Page 14: Overview Of The Web Interface
KS-CC1 Use r Manual Overview of the Web Interface KS-CC1 web inter face has two user types, Administrator and Video Manager , described as below : To setup the device, log in Administrator with default username admin and password Administrator admin, then entering System Administrator webpages. -
Page 15: Chapter 1 Administrator
KS-CC1 Use r Manual Chapter 1 Administrator The Administrator web pages provide a system administration interface of the KS-CC1: it can perform Media I/O, Video, Live Transcription, Storage, Account, System settings and confirm operations. The Media I/O contains configurations of video and audio input sour ces as well as of video/audio outputs. - Page 16 Camera, or source. Under “Video por t”, KS-CC1 lists HDMI input 1 & 2 and all the USB video sour ces connected to it. You may select one as video source and configure its profile. The available options are: format*, resolution(max.), and FPS(max.)**...
-
Page 17: Network Device Manager
1.1.2 Network device manager By clicking the “Scan ” button, KS-CC1 will sear ch all the ONVIF network cameras that ar e connected on the same subnet. The system automatically scans and lists the network cameras connected to the Media Station once entering the [ Network device manager ] page. -
Page 18: Audio
HDMI input 2 has its individual audio contr ol. If the KS-CC1 is using an IP video source and it contains audio codec that KS-CC1 supports, you will see the IP audio control UI here. In the USB Audio (UAC) settings, you can select one USB audio source connected to KS-CC1 from the drop- down menu. After selecting the USB audio source, the audio control interface will be appeared and allowing volume and mute control. -
Page 19: Display
KS-CC1 Use r Manual 1.1.4 Display Set the KS-CC1 on scr een display language. On-scr een language: Change the GUI menu language. www.arec.com... -
Page 20: Video
KS-CC1 Use r Manual 1.2 Video The pages within Video contains settings r elated to streaming and recording. Recording Encoder settings (of recording), Recording file name setting, and Audio shift for recording. Streaming Encoder settings (of streaming) and streaming settings. -
Page 21: Recording
* When “Record to USB” is enabled and KS-CC1 r ecords video to an USB driv e, the recording files will be saved only on the USB driv e and will not have another copy on KS-CC1’ s local storage. - Page 22 KS-CC1 Use r Manual Profile name Video Resolution/ Bitrate Application description Full HD 1080p/ 4Mbps Dynamic scene and lar ge local hard disk recording. Internet Full HD 1080p/ 3Mbps General scene and medium local har d disk recording. 720p/ 2Mbps Static scene and small local har d disk recording.
-
Page 23: Streaming
KS-CC1 Use r Manual 1.2.2 Streaming AREC Media Station supports two streaming addresses with same video compression. The page provides user to change streaming settings. It is essential that the configurations follow the streaming protocol and recommended settings your server system suppor ts. - Page 24 Click Save button to make the option change. The available protocol on the KS-CC1 ar e RTP and RTMP, the URL format is as follows : In the protocol setting field, copy and paste the Server or Stream URL and Stream name provided by you CDN RTMP or server administrator in the format r tmp://serverurl/streamname.
- Page 25 Followings are some popular examples for streaming settings. Str eaming to Facebook Live 1. Select “Streaming Software” for the video source. 2. Copy the server URL and str eam key, paste and combine them in the KS-CC1 str eaming protocol setting field. - Ser ver URL = r tmps://live-api-s.facebook.com:443/r tmp/ - Str eam key = abcdefgh12345678 - Str eam URL paste on the KS-CC1 = r tmps://live-api-s.facebook.com:443/r tmp/abcdefgh12345678...
- Page 26 First go to the YouTube Studio → Stream page. Combine the contents of both fields: Str eam URL and Str eam key, insert a slash between them. Paste this string into the KS-CC1 str eaming protocol setting field. - Str eam URL = rtmp://a.rtmp.youtube.com/live2...
- Page 27 KS-CC1 Use r Manual Streaming RTP KS-CC1 can do R TP unicast and multicast str eaming. Unicast: For a single point connection. There can be only one client to receive the stream at the same time. The stream receiver must be accessible to KS-CC1.
-
Page 28: Live Transcription
You can find the live transcription service remain time in this section as well as to add more service time by the value code purchased from your AREC vendor. Stored value code Insert the license key here. This key can be purchased from your AREC vendor. Remaining service time The remain service time(balance) available for live transcription of the KS-CC1. -
Page 29: Live Caption Preview
KS-CC1 Use r Manual 1.3.2 Live Caption preview In this section, you can configure everything about the live subtitle, including the subtitle’s font properties and the URL of its web view page. Display Output Configure the subtitle to be displa yed live on the HDMI output and str eaming. The subtitle set her e will also be mixed(embedded) with the recording video. - Page 30 Insert the IP address or domain name that used to connect the web page of subtitle view . If you’re using port forwarding on KS-CC1, please inser t the external IP addr ess or domain name along with the external por t number.
-
Page 31: Storage
NAS Settings You can set NAS as the local storage of KS-CC1, so the video and subtitles can be sa ved directly to the network storage. Fill in necessary information for y our NAS and click apply. If the NAS is correctly mounted, y ou will get a “Applied successfully”... - Page 32 It lists all the storage de vices connected to the KS-CC1 along with their information, a vailable storage space, and total capacity. Any storage that ar e going to be mounted as the local storage of KS-CC1 must be formatted b y KS-CC1 befor e mounting.
-
Page 33: System
KS-CC1 Use r Manual 1.5 System The pages within System include the following: General settings Contains device identification, date and time configuration, and booting settings. Network The device IP assignment in the networking. Displays the current firmware version, and provides web-based wa y to update firmware for Firmware the device. -
Page 34: General Settings
KS-CC1 Use r Manual 1.5.1 General settings The basic information and initial date/time of this de vice are configured here. Device identification Set the name (device description) for this de vice. Date and Time Set the device date, time, and time zone manually/ be synchr onized to PC, or with an external NTP (network time protocol) server. - Page 35 KS-CC1 Use r Manual Power settings Auto power off: select power off via daily scheduler or power button pushing. Please notice the scheduling and auto upload time before settings. Auto power on: select power on via daily scheduler or power button pushing.
-
Page 36: Network
KS-CC1 Use r Manual 1.5.2 Network By default, KS-CC1 uses DHCP to obtain an IP Address via a router or any DHCP server. To use a static IP address for your device, configure the network settings in this webpage. Network settings IP assignment –... -
Page 37: Firmware
KS-CC1 Use r Manual 1.5.3 Firmware This page displays the device firmware version. To update the firmware, click “Update" and select the firmware file of KS- CC1. Click “Open”, the dialog box closes and the file name appears underneath. Click “Apply” to start firmware update or click “Cancel”... -
Page 38: Configuration
Reset the device to factory default. Check if you want to keep your network settings, and click “Reset”. System will automatically r eboot after reset. * This only reset the configurations of KS-CC1. It doesn ’t delete the recording in the local storage and the transcription service time. -
Page 39: Account
KS-CC1 Use r Manual 1.6 Account Users can set the system account passwor d etc. Changing username and passwor d with Administration / Video Manager : (1) Username: Enter a new username for different account role (2) New Password: Enter the user login passwor d. -
Page 40: Live Subtitle Web View
1.7 Live Subtitle Web View KS-CC1 has a live subtitle web view page that allow all the audience to view the live subtitle in the language of their preference. Each audience can select the language of the subtitle he pr efers without inter fere others. -
Page 41: Chapter 2 Gui
You can also show audience the QR code of the web page link for the live subtitle. Simply connect a USB mouse to KS-CC1 and click the GUI menu icon in the bottom-right corner of the scr een. The menu bar will pop up, and y ou should see three buttons in it. -
Page 42: System Information
In the live caption tab, it lists all thr ee subtitles languages that curr ently set. They can be changed in web admin when KS-CC1 isn’t doing live transcription. To change the live transcription ’s/subtitles’ languages, please see Web Administrator → Live Transcription → Live Caption settings for more detail. -
Page 43: Network
KS-CC1 Use r Manual 2.1.1.3 Network In the network tab, the KS-CC1’ s network can be set to DHCP or to fixed IP with a USB k eyboard connected. 2.1.2 Subtitle Click the subtitle button to change the language of the subtitle shown on the GUI displa y or to disable it. -
Page 44: Qr Code
KS-CC1 Use r Manual 2.1.3 QR Code Clicking the QR code button it shows the QR code image that links to the liv e subtitle web page. *Note: The QR code link needs to be pre- edited in the web admin page. -
Page 45: Chapter 3 Video Manager
KS-CC1 Use r Manual Chapter 3 Video Manager The KS-CC1 embedded Video Manager provides access to recordings produced by KS-CC1 itself and stored in the USB. The video and Snapshot lists ar e in descending order by the time of occurrence. -
Page 46: Playback The Recording
KS-CC1 Use r Manual 3.1.3 Playback the recording Click on the recording and you will be directed to the video preview page. Use the player controls at the bottom of the window to watch the video. 1. Recording date and time 2. -
Page 47: Table Of On Screen Disaplay Icons
KS-CC1 Use r Manual Table of On-Screen Display Icons The KS-CC1 pr ovides HDMI output for GUI contr ol and preview. Under certain circumstances, there will be event icons shown in the top-right corner of the display or pop- up message to indicate the different status of the device. - Page 48 KS-CC1 Use r Manual Firmware update failure Firmware updating Shutdown confirmation www.arec.com...
- Page 49 All information contained in this document is Pr oprietary Made in Taiwan Date : 2022.08.01 AREC have the right to change or impr ove product specifications, without obligation to notify any user . Go to www.arec.com get the latest information r elated to the product or additional information.
